Page 689 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C O N N E C T O R P I N O U T S 266 CONNECTOR PINOUTS

Page 690 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual FUSES (FUSE BLOCK NO. 2)FUSE NO.AMPS FUSED CIRCUIT FUNCTION 1 10A 16RD/GY FUSED B(+) 2 10A 16RD FUSED B(+) 3 15A 16RD FUSED B(+) 4 7.5A 16RD/YL FUSED B(+) 5 25A 14RD/WT FUSED B(+) 6 7.5A 18RD/YL FUSED

Page 691 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C O N N E C T O R P I N O U T S 268 CONNECTOR PINOUTS

Page 692 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual FUSES (FUSE/RELAY BLOCK)FUSE NO.AMPS FUSED CIRCUIT FUNCTION 1 30A 14BL/YL FUSED B(+) 2- - - 3- - - 4- - - 5 10A 16RD/YL FUSED B(+) 6 7.5A 18BK/RD FUSED OPTIONAL EQUIPMENT RELAY OUTPUT 7 25A 14RD FUSED

Page 693 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual GLOW PLUG CONTROL MODULE C1 - BLACKCAV CIRCUIT FUNCTION 1 18BR GROUND 2 18BK/RD GLOW PLUG MODULE CONTROL 3- - GLOW PLUG CONTROL MODULE C2 - BLACKCAV CIRCUIT FUNCTION 1 14BK/DG GLOW PLUG NO. 5 SUPPLY V

Page 694 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual KICK DOWN SWITCH - BLACKCAV CIRCUIT FUNCTION 1 18BR/DG KICKDOWN SWITCH SIGNAL 2 18BR (EXCEPT OBD) SENSOR GROUND 2 18BR (OBD) GROUND MASS AIR FLOW SENSOR - BLACKCAV CIRCUIT FUNCTION 1 16YL/RD (OBD) FUS

Page 695 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C O N N E C T O R P I N O U T S 272 CONNECTOR PINOUTS

Page 696 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual FUSED IGNITION SWITCH RUN-START RELAY (RELAY BLOCK)CAV CIRCUIT FUNCTION 30 14RD FUSED B(+) 85 18BK FUSED IGNITION SWITCH OUTPUT (RUN-START) 86 16BR GROUND 87 14BK/YL FUSED IGNITION SWITCH RUN-START RE
