MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: *NO RESPONSE FROM TRANSMISSION CONTROL MODULE POSSIBLE CAUSES CHECK POWERS AND GROUNDS TO THE TRANSMISSION CONTROL MODULE K-TCM CIRCUIT SHORTED TO GROUND K-TCM CIRCUIT SHORTED TO VOLTAGE K-TC

Page 2178 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 4 Turn the ignition off. Disconnect the TCM harness connectors. Disconnect the DRBIIItfrom the DLC. Measure the resistance of the K-TCM circuit between the TCM connector and

Page 2179 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: BACKUP LAMP CKT SHORT TO GROUND POSSIBLE CAUSES BACKUP LAMP CIRCUIT SHORT TO GROUND SHIFT LEVER ASSEMBLY TEST ACTION APPLICABILITY 1 Turn the ignition off to the lock position. Disconnect the

Page 2180 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: BACKUP LAMP CKT SHORT TO VOLTAGE OR OPEN POSSIBLE CAUSES BACKUP LAMP CIRCUIT OPEN BACKUP LAMP CIRCUIT SHORT TO VOLTAGE SHIFT LEVER ASSEMBLY TEST ACTION APPLICABILITY 1 Start the engine. While

Page 2181 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: BACKUP LAMP SUPPLY CIRCUIT OPEN POSSIBLE CAUSES FUSED IGNITION SWITCH OUTPUT OPEN SHIFT LEVER ASSEMBLY TEST ACTION APPLICABILITY 1 Turn the ignition off to the lock position. Disconnect the S

Page 2182 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: CAN BUS CIRCUIT POSSIBLE CAUSES CAN COMMUNICATION FAILURE CAN BUS (+) OR (-) OPEN SHIFT LEVER ASSEMBLY TEST ACTION APPLICABILITY 1 With the DRBIIIt, read the stored and active DTCs for all mo

Page 2183 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: INCORRECT CAN MESSAGE FROM ABS POSSIBLE CAUSES ABS - INTERNAL SLA - INTERNAL TEST ACTION APPLICABILITY 1 Turn the ignition off to the lock position. Replace the ABS Control Module per the Ser

Page 2184 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: INTERNAL CONTROLLER POSSIBLE CAUSES INTERNAL CONTROLLER Repair Instructions: INTERNAL CONTROLLER The Shift Lever Assembly has detected an internal fault. Replace the Shift Lever Assembly. 19
