Page 1425 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual AUTOMATIC TEMPERATURE CONTROL MODULE C2 CAV CIRCUIT FUNCTION 1 14BK/VT FAN STAGE 1 RELAY OUTPUT 1 12YL BLOWER MOTOR LOW DRIVER 2 12WT BLOWER MOTOR HIGH DRIVER 3 12WT/BK BLOWER MOTOR M1 DRIVER 4 12YL/B

Page 1426 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual BLOWER MOTOR RESISTOR BLOCK C2 CAV CIRCUIT FUNCTION 1 12YL/BK BLOWER MOTOR (+) SELECT 3 2 12YL BLOWER MOTOR (+) SELECT 1 3 12WT/BK BLOWER MOTOR (+) SELECT 2 BLOWER MOTOR RESISTOR BLOCK C3 CAV CIRCUIT

Page 1427 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual BOOST PRESSURE SENSOR (OBD) CAV CIRCUIT FUNCTION 1 18BR/WT SENSOR GROUND 2 18WT/DG BOOST PRESSURE SENSOR SIGNAL 3 18WT/RD BOOST PRESSURE SENSOR 5 VOLT SUPPLY BOOST PRESSURE SERVOMOTOR (OBD) CAV CIRCUI

Page 1428 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual BRAKE LAMP SWITCH 4 POLE (ESP) CAV CIRCUIT FUNCTION 1 16RD/BK FUSED IGNITION SWITCH OUTPUT (RUN-START) 2 20WT BRAKE SWITCH OUTPUT 3 16BK/BL/WT FUSED IGNITION SWITCH OUTPUT (RUN-START) 4 16BK/RD BRAKE

Page 1429 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual BRAKE WEAR SENSOR-LEFT FRONT CAV CIRCUIT FUNCTION 1 16BR GROUND 2 16BR/WT BRAKE WEAR SENSOR SIGNAL BRAKE WEAR SENSOR-LEFT REAR CAV CIRCUIT FUNCTION 1 16BR GROUND 2 16BR/WT BRAKE WEAR SENSOR SIGNAL BRA

Page 1430 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C100 - BLACK (MAIN BODY) CAV CIRCUIT 1 18BK/BL 2 18RD/DG 3 16WT/BL/RD 4- 5 16RD 6 16BK 7 16BK/BL 8 14BK/VT 9- 10 - C101 - YELLOW (ENGINE SIDE) CAV CIRCUIT 1 16WT/BL 2 14BK/YL 3 16BL/DG 4 16BK/RD C101

Page 1431 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C102 (EXCEPT OBD) - (GENERATOR SIDE) CAV CIRCUIT A 18WT/BL B- C103 (OBD) - (GENERATOR SIDE) CAV CIRCUIT 1 18WT/BL 2 14BK/YL 3- 4- 5- 6 16YL/RD C103 (OBD) - (MAIN BODY) CAV CIRCUIT 1 20BL 2 12BK/YL 3-

Page 1432 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C200 - BLACK (MAIN BODY SIDE) CAV CIRCUIT 1 16GY 2 16GY/DG 3 16BK/YL 4 16DG/BL/WT 5 16YL/BL 6 16BL/RD 7 16BK/RD 8 16WT/BK 9 16WT/DG 10 16WT/YL 11 16WT/RD 12 16BK/RD 13 18VT/YL 14 16BR/BK 15 16YL 16 16
