Page 1489 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual ROOF A/C CONTROL MODULE - BLACK CAV CIRCUIT FUNCTION 1 12BR GROUND 2 12RD FUSED B(+) 3 16YL 12V A/C FAN MOTOR CONTROL-LOW SPEED 4 16VT 12V A/C FAN MOTOR CONTROL-HIGH SPEED 5 16BK TEMPERATURE SENSOR SI

Page 1490 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual ROOF FAN MOTOR CAV CIRCUIT FUNCTION 1 16WT MOTOR (+/-) 2 16BK MOTOR (+/-) ROOF FAN SWITCH CAV CIRCUIT FUNCTION 1 16GY/DG/RD LAMP DRIVER 2- - 3 16BK/BL/WT FUSED OPTIONAL EQUIPMENT RELAY OUTPUT 4 16WT M

Page 1491 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual SEAT BELT SWITCH CAV CIRCUIT FUNCTION 1 16BR GROUND 2 20YL/RD SEAT BELT SWITCH SIGNAL 3- - 4- - 5- - 6- - 7- - 8- - 9- - 10 - - SEAT BELT TENSIONER-DRIVER - YELLOW CAV CIRCUIT FUNCTION 1 20BL DRIVER S

Page 1492 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual SECURITY SYSTEM MODULE C1 - BROWN CAV CIRCUIT FUNCTION 1 16BK/WT LEFT TURN SIGNAL 2- - 3- - 4 16BK/DG RIGHT TURN SIGNAL 5 16BK/VT FAN STAGE 1 RELAY 6 16WT/RD WARM AIR AUXILIARY HEATER CONTROL 7 16RD/G

Page 1493 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual SENTRY KEY REMOTE ENTRY MODULE (SKREEM) CAV CIRCUIT FUNCTION 1 18YL RKE ANTENNA 2 16BR GROUND 3 16RD/YL FUSED B(+) 4 16BK/WT LEFT TURN SIGNAL 5 20DG/WT CAN C BUS (+) 6 20DG CAN C BUS (-) 7 16BK/YL FUS

Page 1494 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual SKREEM TRANSPONDER CAV CIRCUIT FUNCTION 1 20BR TRANSPONDER COIL (+) 2 - TRANSPONDER COIL (-) SPEAKER-LEFT FRONT DOOR ASSEMBLY C1 CAV CIRCUIT FUNCTION 1 18BL/YL SPEAKER-LEFT FRONT (+) CTEL 2 18BL/DG SP

Page 1495 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual SPEAKER-RIGHT REAR CAV CIRCUIT FUNCTION 1 16BR/GY SPEAKER-RIGHT REAR 2 16WT/GY SPEAKER-RIGHT REAR SPEED CONTROL SWITCH CAV CIRCUIT FUNCTION 1 18GY OFF SIGNAL 2 18BK VERIFICATION SIGNAL 3 18BL RESUME S

Page 1496 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TAIL LAMP ASSEMBLY-RIGHT - BLACK CAV CIRCUIT FUNCTION 1- - 2 16GY/RD RIGHT LAMP RELAY OUTPUT 3 16BK/RD BRAKE LAMP SWITCH OUTPUT 4 16WT/RD BACK-UP LAMP 5 16BK/DG RIGHT TURN SIGNAL 6 16BR GROUND TCS SWI
