Page 193 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 4 Turn the ignition off. Disconnect the Instrument Cluster C1 harness connector. Disconnect the Ambient Temperature Sensor harness connector. Measure the resistance of the Am

Page 194 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: AMBIENT TEMP SENSOR SHORT TO GROUND POSSIBLE CAUSES AMBIENT TEMPERATURE SENSOR AMBIENT TEMPERATURE SENSOR SIGNAL (+) CIRCUIT SHORT TO GROUND AMBIENT TEMPERATURE SENSOR SIGNAL (+) CIRCUIT SHOR

Page 195 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: FUEL LEVEL SENSOR OPEN/SHORT TO BATTERY POSSIBLE CAUSES FUEL LEVEL SENSOR FUEL LEVEL SENSOR SIGNAL (+) CIRCUIT SHORT TO VOLTAGE FUEL LEVEL SENSOR SIGNAL RETURN CIRCUIT OPEN FUEL LEVEL SENSOR

Page 196 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 4 Turn the ignition off. Disconnect the Fuel Pump Module harness connector. Disconnect the Instrument Cluster C1 harness connector. Measure the resistance of the Fuel Level S

Page 197 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: FUEL LEVEL SENSOR SHORT TO GROUND POSSIBLE CAUSES FUEL LEVEL SENSOR FUEL LEVEL SENSOR CIRCUITS SHORTED TOGETHER INSTRUMENT CLUSTER FUEL LEVEL SENSOR SIGNAL (+) SHORT TO GROUND TEST ACTION APP

Page 198 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: INSTRUMENT CLUSTER INTERNAL FAILURE B1043 POSSIBLE CAUSES CAN BUS FAILURE INSTRUMENT CLUSTER TEST ACTION APPLICABILITY 1 If this fault is present, scan the Engine Control Module and/or Transm

Page 199 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: INSTRUMENT CLUSTER INTERNAL FAILURE B1053 POSSIBLE CAUSES CAN BUS FAILURE INSTRUMENT CLUSTER TEST ACTION APPLICABILITY 1 If this fault is present, scan the Engine Control Module and/or Transm

Page 200 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: INSTRUMENT CLUSTER OVERVOLTAGE POSSIBLE CAUSES CHARGING SYSTEM OVERCHARGE INSTRUMENT CLUSTER TEST ACTION APPLICABILITY 1 Check the Charging System for proper operation in accordance with the
