Page 201 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: NO CAN COMMUNICATION WITH ABS POSSIBLE CAUSES DTC PRESENT OPEN CAN CIRCUITS AT INSTRUMENT CLUSTER INSTRUMENT CLUSTER CHECK POWERS AND GROUNDS TO THE AFFECTED MODULE OPEN CAN CIRCUITS AT CAB C

Page 202 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 5 Turn the ignition off to the lock position. Disconnect the Instrument Cluster C1 harness connector. Measure the resistance between the CAN C Bus (+) circuit and the CAN C B

Page 203 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: NO CAN COMMUNICATION WITH ECM POSSIBLE CAUSES DTC PRESENT OPEN CAN CIRCUITS AT INSTRUMENT CLUSTER INSTRUMENT CLUSTER CHECK POWERS AND GROUNDS TO THE AFFECTED MODULE OPEN CAN CIRCUITS AT ECM E

Page 204 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 5 Turn the ignition off to the lock position. Disconnect the Instrument Cluster C1 harness connector. Reconnect the ECM harness connector. Measure the resistance between the

Page 205 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: NO CAN COMMUNICATION WITH TCM POSSIBLE CAUSES DTC PRESENT OPEN CAN CIRCUITS AT INSTRUMENT CLUSTER INSTRUMENT CLUSTER CHECK POWERS AND GROUNDS TO THE AFFECTED MODULE OPEN CAN CIRCUITS AT TCM T

Page 206 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 5 Turn the ignition off to the lock position. Disconnect the Instrument Cluster C1 harness connector. Measure the resistance between the CAN C Bus (+) circuit and the CAN C B

Page 207 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: PREGLOW INDICATOR LAMP FAILURE POSSIBLE CAUSES INSTRUMENT CLUSTER TEST ACTION APPLICABILITY 1NOTE: The Instrument Cluster performs internal tests on the indicators during each ignition cycle.

Page 208 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: SRS INDICATOR LAMP FAILURE POSSIBLE CAUSES INSTRUMENT CLUSTER TEST ACTION APPLICABILITY 1 If this fault is present, interrogate the Airbag Control Module for any SRS Indicator faults. NOTE: T
