Page 2217 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 10 Turn the ignition off to the lock position. Disconnect the ECM harness connector. Measure the resistance between the CAN C Bus (+) and CAN C Bus (-) circuits in the ECM ha

Page 2218 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: CAN MESSAGE FROM ECM FROM SLA When Monitored and Set Condition: CAN MESSAGE FROM ECM FROM SLA When Monitored: Set Condition: CAN Bus message received from the Shift Lever Assembly are incorre

Page 2219 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 3 Ignition on, engine not running. With the DRBIIIt, read Shift Lever DTCs. Are there any Shift Lever DTCs present?All Ye s!Refer to the Shift Lever category and perform the

Page 2220 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: CONTROL MODULE TCM IS NOT CODED POSSIBLE CAUSES TRANSMISSION CONTROL MODULE FLASH TEST ACTION APPLICABILITY 1 View repair.All Repair Flash the Transmission Control Module to the proper level.

Page 2221 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: ENGINE CAN MESSAGE INCORRECT When Monitored and Set Condition: ENGINE CAN MESSAGE INCORRECT When Monitored: CAN-ID received at least once and CAN Bus Circuit DTC is not active. Set Condition:

Page 2222 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 3 Replace and program the ECM per the Service Information. With the DRBIIIt, erase Transmission DTCs. Start the engine. With the brakes firmly applied, shift the gear selecto

Page 2223 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: ENGINE CAN MESSAGE MISSING When Monitored and Set Condition: ENGINE CAN MESSAGE MISSING When Monitored: CAN Bus circuit error not present, 1 second after ignition on and not in Park or Neutra

Page 2224 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 2 Ignition on, engine not running. With the DRBIIIt, read Transmission DTCs. NOTE: If the DTC, CAN BUS CIRCUIT, is present, perform diagnostics on that symptom first. Is the
