2004 NISSAN TERRANO Service Repair Manual

TD27Ti ENGINE MODELS
YEL732E
HEADLAMP Ð Daytime Light System Ð
Wiring Diagram Ð DTRL Ð (Cont'd)EL-36
http://vnx.su/

ZD30DDTi ENGINE MODELS
YEL981E
HEADLAMP Ð Daytime Light System Ð
Wiring Diagram Ð DTRL Ð (Cont'd)EL-37
http://vnx.su/

ZD30DDTi ENGINE MODELS
YEL733E
HEADLAMP Ð Daytime Light System Ð
Wiring Diagram Ð DTRL Ð (Cont'd)EL-38
http://vnx.su/

ZD30DDTi ENGINE MODELS
YEL734E
HEADLAMP Ð Daytime Light System Ð
Wiring Diagram Ð DTRL Ð (Cont'd)EL-39
http://vnx.su/

Trouble Diagnoses
DAYTIME LIGHT UNIT INSPECTION TABLE
Terminal No. Wire color ConnectionsOperated conditionVoltage (V) (Approxi-
mate values)
1 LG/RPower source for illu-
mination & tail lamp Ð1
2
2 GY/L Alternator ªLº terminal EngineRunning
12
Stopped 0
3 R/L Lighting switch 1ST×2ND position
12
OFF 0
5 GY/LPower source for head-
lamp LH Ð1
2
6 R/L Illumination & tail lamp ON (daytime light operating*)
12
OFF 0
7R Power source for head-
lamp RH Ð1
2
8 B/W Start signal Ignition switchSTART
12
ON, ACC or OFF 0
9 R/Y Headlamp LH ON (daytime light operating*)
12
OFF 0
10 B Ground Ð0
11 G Headlamp RH ON (daytime light operating*)
12
OFF 0
12 B/W Power source Ignition switchON or START
12
ACC or OFF 0
*: Daytime light operating: Lighting switch in ªOFFº position with engine running.
HEADLAMP Ð Daytime Light System Ð
EL-40
http://vnx.su/

Description
IThe vertical direction of the headlamp projection can be adjusted from inside the vehicle to prevent the
headlamp beam axis from facing upward due to a change in the number of occupants and load conditions
in the vehicle.
I A little Electronic Control Unit (ECU) is incorporated in each actuator (one for each headlamp), which
compares a signal voltage (V
signal), coming from the headlamp aiming switch, with battery voltage (12V).
The signal voltage varies with the position of the switch.
Related to the difference in voltage the actuator rod will move more or less and adjust the headlamp beam
angle accordingly.
EEL018
HEADLAMP Ð Headlamp Aiming Control Ð
EL-41
http://vnx.su/

Replacing Headlamp Aiming Actuator
Headlamp aiming actuator can not be disassembled.
To remove aiming actuator, turn it 90É to the center of the vehicle
(left and right symmetrical) and pull outward.
EEL017
EEL019
HEADLAMP Ð Headlamp Aiming Control Ð
Description (Cont'd)EL-42
http://vnx.su/

Wiring Diagram Ð H/AIM Ð
YEL068D
HEADLAMP Ð Headlamp Aiming Control Ð
EL-43
