2004 NISSAN TERRANO Service Repair Manual

YBT132
EXTERIOR
Removal and Installation (Cont'd)BT-32
http://vnx.su/

YBT075
EXTERIOR
Removal and Installation (Cont'd)BT-33
http://vnx.su/

Removal and Installation
IWhen removing or installing the seat trim, carefully handle it to keep dirt out and avoid damage.
CAUTION:
I Before removing the front seat, turn the ignition switch off, disconnect both battery cables and wait
at least 3 minutes (models with side air bag).
I Do not drop, tilt, or bump the side air bag module installed in the seat. Always handle it with care.
I Disconnect the side air bag harness connector and heated seat harness connector from under the
seat before removing the seat.
I Disconnect the side air bag harness connector before removing the seatback. Refer to RS-29,
ªFront Side Air Bag Moduleº for details.
FRONT SEAT
BT-34
http://vnx.su/

YBT133
FRONT SEAT
Removal and Installation (Cont'd)BT-35
http://vnx.su/

Heated Seat
HFor Wiring Diagram, refer to EL-151, ªHEATED SEATº for details.
Active Head Restraint
The active head restraint system is designed so that the headrest
instantaneously moves towards the front upper direction by utiliz-
ing the force at the seatback during a rear-end collision.
As a result, the occupant's head is protected from being
overextended, reducing the chance for neck injury as much as
possible.
Seat with active head restraint have the labels shown in figures at
left.
OPERATION OUTLINE
When the seatback receives a sharp backward force during a rear-
end collision, the input plate moves with the link rotating center as
a pivot. The headrest will then move towards the front upper direc-
tion with the center of the sliding roller as a pivot.
As the backward force on the seatback is eliminated, spring tension
returns the headrest to its original position.
SBT014A
SBT888
FRONT SEAT
BT-36
http://vnx.su/

Removal and Installation
IWhen removing or installing the seat trim, handle carefully to keep dirt out and avoid damage.
TYPE 1 (HARDTOP)
EBF024
SECOND SEAT
BT-37
http://vnx.su/

TYPE 2 (WAGON)
EBF025
SECOND SEAT
Removal and Installation (Cont'd)BT-38
http://vnx.su/

Removal and Installation
YBT126
THIRD SEAT
BT-39
