2004 NISSAN TERRANO Service Repair Manual

Removal and Installation
CAUTION:
Be careful not to scratch door rearview mirror body.
HFor Wiring Diagram, refer to EL-275, ªDOOR MIRRORº for details.
1. Remove door trim. Refer to ªDOOR TRIMº, BT-19.
2. Remove inner cover front corner of door.
3. Disconnect door mirror harness connector.
4. Remove harness clips.
5. Remove bolts securing door mirror assembly.
YBT135
DOOR MIRROR
BT-48
http://vnx.su/

Alignment
IAll dimensions indicated in figures are actual ones.
I When using a tracking gauge, adjust both pointers to equal length. Then check the pointers and gauge
itself to make sure there is no free play.
I When a measuring tape is used, check to be sure there is no elongation, twisting or bending.
I Measurements should be taken at the center of the mounting holes.
I An asterisk (*) following the value at the measuring point indicates that the measuring point on the other
side is symmetrically the same value.
I The coordinates of the measurement points are the distances measured from the standard line of ªXº, ªYº
and ªZº.
YBT089
BODY (ALIGNMENT)
BT-49
http://vnx.su/

ENGINE COMPARTMENT
Measurement
Unit: mm (in)
NBF021
BODY (ALIGNMENT)
Alignment (Cont'd)BT-50
http://vnx.su/

Detailed Measurement Points
PointsHole dia.
mm (in) Detailed points Coordinates mm (in)
ªXº ªYº ªZº
q
A8 (0.32)
NBF022
Cowl top hole at
vehicle center 0.0
(0.00) 250.0
(9.84) 760.9
(29.96)
q
Bqb11 (0.43)
NBF023
Cowl top side
hole 698.5
(27.50) þ110.1
(þ4.34) 624.7
(24.59)
q
Dqd8 (0.32)
NBF024
Upper radiator
core support
location hole 691.0
(27.20) þ459.5
(þ18.09) 548.0
(21.58)
q
Hqh16 (0.63) Side radiator
core support
location hole680.0
(26.77) þ551.7
(þ21.72) 400.0
(15.75)
q
1: Coordinate indicated isLH,RHcoordinate is -LHcoordinate.
E.g. ifLHcoordinate is: 698.5,RHcoordinate is: þ698.5.
BODY (ALIGNMENT)
Alignment (Cont'd)
BT-51
http://vnx.su/

PointsHole dia.
mm (in) Detailed points Coordinates mm (in)
ªXº ªYº ªZº
q
E9 (0.35)
NBF025
Hood lock stay
mounting hole
on upper radia-
tor core support 37.0
(1.46) þ589.0
(þ23.19) 494.0
(19.45)
q
I
Lower radiator
core support
mounting hole 0.0
(0.00) þ581.1
(þ22.88) þ54.1
(þ2.13)
q
Gqg12 (0.47) Lower radiator
core support
location hole280.0
(11.02) þ608.9
(þ23.97) þ23.0
(þ0.91)
q
Cqc7.2 (0.28)
NBF027
Front fender
mounting hole
on hoodledge 698.5
(27.50) þ110.1
(þ4.34) 624.7
(24.59)
q
1: Coordinate indicated isLH,RHcoordinate is -LHcoordinate.
E.g. ifLHcoordinate is: 698.5,RHcoordinate is: þ698.5.
BODY (ALIGNMENT)
Alignment (Cont'd)
BT-52
http://vnx.su/

UNDERBODY
Measurement (Hardtop model)
NBF028
BODY (ALIGNMENT)
Alignment (Cont'd)BT-53
http://vnx.su/

NBF029
BODY (ALIGNMENT)
Alignment (Cont'd)BT-54
http://vnx.su/

UNDERBODY
Measurement (Wagon model)
NBF030
BODY (ALIGNMENT)
Alignment (Cont'd)BT-55
http://vnx.su/
