2000 MITSUBISHI MONTERO Service Repair Manual

GDI -Troubleshooting 13A-43
OK
Check the harness wire between
No.3 injector and the intermediate
connector.NG
Repair
From the previouspage
OK
Check the trouble symptoms.NGReplace the injector driver.
Replace the No.3 injector.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-44
Code No.P0204 No.4 injector systemProbable cause
Range of Check
DThe enginespeed is 4,000 r/min or less.
DThe battery voltage is 10 V or more.
DThe fuel cut operation or the injector operation (by carrying out the Actuator
Test) is not in progress.
Set Conditions
DThe injector driver is not transmitting a injectoropencircuit check signal for
four seconds.DMalfunction of No.4 injector
DOpen or short circuit in the No.4 injector circuit or
loose connector contact
DMalfunction of engine-ECU
NG
Check the following connector:
B-105NG
Repair
OK
NG
Repair
MUT-
IIActuator Test
04 No.4 injector
OK:
The idling condition should
change.OKCheck the trouble symptoms.OKTransient malfunction
(Refer to GROUP 00 - Points to
Note for Intermittent Malfunctions.)
NG
Replace the injector driver.
Check the trouble symptoms.NGReplace the engine-ECU.
OK
Measure at intermediate connector
B-105.
DDisconnect the connector and
measure at the harness side.
DResistance between terminals 3
and 4
OK:
0.9 - 1.1WNGCheck the following connector:
B-115NG
Repair
OK
Replace the No.4 injector.
OK
Check the following connector:
B-121NG
Repair
OK
Check the harness wire between the
injector driver and the intermediate
connector.NG
Repair
OK
Check the following connector:
D-116NG
Repair
OK
Check the harness wire between the
injector driver and the engine-ECU.NG
Repair
OK
Use an analyzer to measure the
signal waveform at engine-ECU
connectors D-116 and D-118.
DEngine: Idling
DVoltage between terminal 2 and
earth
OK:
A normal waveform should
be displayed as described
on P.13A-121 (INSPEC-
TION PROCEDURE US-
ING AN ANALYZER).NGCheck the following connector:
B-115
OK
Check the following connector:
B-115NG
Repair
OK
To the nextpageNG
OK
OK
Check the harness wire between the
No.4 injector and the intermediate
connector.NG
Replace the engine-ECU.
Repair
Repair
Check the harness wire between
No.4 injector and the intermediate
connector.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-45
OK
Check the harness wire between
No.4 injector and the intermediate
connector.NG
Repair
From the previouspage
OK
Check the trouble symptoms.NGReplace the injector driver.
Replace the No.4 injector.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-46
Code No.P0205 No.5 injector systemProbable cause
Range of Check
DThe enginespeed is 4,000 r/min or less.
DThe battery voltage is 10 V or more.
DThe fuel cut operation or the injector operation (by carrying out the Actuator
Test) is not in progress.
Set Conditions
DThe injector driver is not transmitting a injectoropencircuit check signal for
four seconds.DMalfunction of No.5 injector
DOpen or short circuit in the No.5 injector circuit or
loose connector contact
DMalfunction of engine-ECU
NG
Check the following connector:
B-105NG
Repair
OK
NG
Repair
MUT-
IIActuator Test
05 No.5 injector
OK:
The idling condition should
change.OKCheck the trouble symptoms.OKTransient malfunction
(Refer to GROUP 00 - Points to
Note for Intermittent Malfunctions.)
NG
Replace the injector driver.
Check the trouble symptoms.NGReplace the engine-ECU.
OK
Measure at intermediate connector
B-105.
DDisconnect the connector and
measure at the harness side.
DResistance between terminals 7
and 8
OK:
0.9 - 1.1WNGCheck the following connector:
B-103NG
Repair
OK
Replace the No.5 injector.
OK
Check the following connector:
B-121NG
Repair
OK
Check the harness wire between the
injector driver and the intermediate
connector.NG
Repair
OK
Check the following connector:
D-116NG
Repair
OK
Check the harness wire between the
injector driver and the engine-ECU.NG
Repair
OK
Use an analyzer to measure the
signal waveform at engine-ECU
connectors D-116 and D-118.
DEngine: Idling
DVoltage between terminal 10 and
earth
OK:
A normal waveform should
be displayed as described
on P.13A-121 (INSPEC-
TION PROCEDURE US-
ING AN ANALYZER).NGCheck the following connector:
B-103
OK
Check the following connector:
B-103NG
Repair
OK
To the nextpageNG
OK
OK
Check the harness wire between the
No.5 injector and the intermediate
connector.NG
Replace the engine-ECU.
Repair
Repair
Check the harness wire between
No.5 injector and the intermediate
connector.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-47
OK
Check the harness wire between
No.5 injector and the intermediate
connector.NG
Repair
From the previouspage
OK
Check the trouble symptoms.NGReplace the injector driver.
Replace the No.5 injector.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-48
Code No.P0206 No.6 injector systemProbable cause
Range of Check
DThe enginespeed is 4,000 r/min or less.
DThe battery voltage is 10 V or more.
DThe fuel cut operation or the injector operation (by carrying out the Actuator
Test) is not in progress.
Set Conditions
DThe injector driver is not transmitting a injectoropencircuit check signal for
four seconds.DMalfunction of No.6 injector
DOpen or short circuit in the No.6 injector circuit or
loose connector contact
DMalfunction of engine-ECU
NG
Check the following connector:
B-105NG
Repair
OK
NG
Repair
MUT-
IIActuator Test
06 No.6 injector
OK:
The idling condition should
change.OKCheck the trouble symptoms.OKTransient malfunction
(Refer to GROUP 00 - Points to
Note for Intermittent Malfunctions.)
NG
Replace the injector driver.
Check the trouble symptoms.NGReplace the engine-ECU.
OK
Measure at intermediate connector
B-105.
DDisconnect the connector and
measure at the harness side.
DResistance between terminals 1
and 2
OK:
0.9 - 1.1WNGCheck the following connector:
B-104NG
Repair
OK
Replace the No.6 injector.
OK
Check the following connector:
B-121NG
Repair
OK
Check the harness wire between the
injector driver and the intermediate
connector.NG
Repair
OK
Check the following connector:
D-116NG
Repair
OK
Check the harness wire between the
injector driver and the engine-ECU.NG
Repair
OK
Use an analyzer to measure the
signal waveform at engine-ECU
connectors D-116 and D-118.
DEngine: Idling
DVoltage between terminal 25 and
earth
OK:
A normal waveform should
be displayed as described
on P.13A-121 (INSPEC-
TION PROCEDURE US-
ING AN ANALYZER).NGCheck the following connector:
B-104
OK
Check the following connector:
B-104NG
Repair
OK
To the nextpageNG
OK
OK
Check the harness wire between the
No.6 injector and the intermediate
connector.NG
Replace the engine-ECU.
Repair
Repair
Check the harness wire between
No.6 injector and the intermediate
connector.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-49
OK
Check the harness wire between
No.6 injector and the intermediate
connector.NG
Repair
From the previouspage
OK
Check the trouble symptoms.NGReplace the injector driver.
Replace the No.6 injector.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-50
Code No.P0220 Accelerator pedal position sensor (1st
channel) systemProbable cause
Range of Check
DAcceleratorpedal positionsensor (2nd channel) is normal.
DCommunication between the engine-ECU and the throttle valve controller is
normal.
Set Conditions
DThe output voltage of accelerator pedal positionsensor (1st channel) is 0.2 V
or less for one second.
or
DThe output voltage of accelerator pedal positionsensor (2nd channel) is 2.5
V or less, and that of acceleratorpedal positionsensor (1st channel) is 4.5
V or more for one second
or
DThe difference between accelerator pedal positionsensor (1st channel) and
accelerator pedal positionsensor (2nd channel) output voltages is 1.0 V or
more (i.e. the throttle opening anglechanges slightly).
or
DThe output voltage of accelerator pedal positionsensor (1st channel) is 1.1 V
or more for one second when the acceleratorpedal positionswitch is turned
on.DMalfunction of accelerator pedal positionsensor
(1st channel)
DOpen or short circuit in the acceleratorpedal
position sensor (1st channel) circuit or loose
connector contact
DAcceleratorpedal positionswitch seized ON
DMalfunction of throttle valve controller
DMalfunction of engine-ECU
OK
Check the harness wire between
accelerator pedal positionsensor
(1st channel) and the engine-ECU,
and repair if necessary.
NG
Check Acceleratorpedal position
sensor (1st channel) (Refer to
P.13A-229).NG
Replace
OK
Check the trouble symptoms.NGReplace the engine-ECU.(2) NGMeasure at engine-ECU connector
D-117.
DMeasure the voltage at the
engine-ECU terminal.
DIgnition switch: ON
DVoltage between terminal 42 and
earth
OK:
4.8 - 5.2 VOK
OK
MUT-
IIData list
78 Acceleratorpedal positionsensor
(1st channel) (Refer to 13A-105,
DATA LIST REFERENCE
TABLE.)OKTransient malfunction
(Refer to GROUP 00 - Points to
Note for Intermittent Malfunctions.)
OK
Check the trouble symptoms.NGReplace the engine-ECU.
MUT-
IIData list
26 Acceleratorpedal positionswitch
(Refer to 13A-105, DATA LIST
REFERENCE TABLE.)NGCheck the acceleratorpedal position
switch system. (Refer to P.13A-100,
Inspection Procedure 28).
OK
Measure at accelerator pedal position
sensor connector D-135.
DDisconnect the connector and
measure at the harness side.
(1) Resistance between terminal 1
and earth
OK:
2Wor less
(2) Voltage between terminal 2 and
earth
(Ignition switch: ON)
OK:
4.8 - 5.2 V(1) NGCheck the following connector:
D-117NGRepair
NG
Repair
NG
Check the following connector:
D-117NG
Repair
OK
Check the following connector:
D-135NG
Repair
OK
Check the harness wire between
accelerator pedal positionsensor
(1st channel) and the engine-ECU.NG
Repair
OK
Check the harness wire between
accelerator pedal positionsensor
(1st channel) and the engine-ECU.NG
RepairOK
To the nextpage
Check the following connector:
D-117
OK
