GDI -TroubleshootingGDI -Troubleshooting13A-4
INSPECTION PROCEDURE CLASSIFIED BY DIAGNOSIS CODE
Code No. P1603 Battery backup line malfunctionProbable cause
Range of Check
DStarting sequence was completed.
DThe battery voltage is 10 V or more.
Set Condition
DBattery backup line voltage is less than 2 V.DOpen or short circuit in the battery back-up line or
loose connector contact
DMalfunction of engine-ECU
DMalfunction of engine-A/T-ECU
NOTE: If the engine is started while the ignition-off
current draw connector has been pulled off, the
engine - ECU or the engine-A/T-ECU
judges that the battery backup line is open, and
illuminates the engine warning lamp and stores this
diagnosis code.
NG
Replace the engine-ECU or engine-A/T-ECU .
Check the trouble symptoms.
OKNG
Repair
Check the harness wire between the battery and the engine-ECU
or engine-A/T-ECU, and repair if necessary.
OKNG
Repair
Check the harness wire between the battery and the engine-ECU
or engine-A/T-ECU , and repair if necessary.
OK
NG
Repair
MUT-IISelf-Diag Code
Is code No. P1603 set?
Check the following connector:D-117 , D-120 OKNO
Check the following connectors:E-13, D-27, D-31 drive vehicles>, D-223 YESMeasure at engine-ECU connector D-117 or engine-A/T-ECU
connector D-120 .
DDisconnect the connector, and measure at the harness
side.
DThe voltage between terminal No.60 or 66
and earth
OK:System voltageNG
Intermittent malfunction (Refer to GROUP 00 - Points to Notes
for Intermittent Malfunction).


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting13A-5
DATA LIST REFERENCE TABLE
The data list has been changed as the engine-ECU and the engine-A/T-ECU have been changed. The
other items are the same as for M/T.
Item
No.Inspection
itemInspection contentsNormal conditionInspec-
tion pro-
cedure
No.Refer-
ence
page
22Crank angle
sensorDEngine: Cranking
DTachometer:
ConnectedCompare the engine
speed readings on
the tachometer and
the MUT-II.AccordCode
No.
P033513A-56*
DEngine: Idling
DIdle position
switch: ONWhen engine
coolant temperature
is - 20_C1,300 - 1,500
r/min
When engine
coolant temperature
is 0_C1,300 - 1,500
r/min
When engine
coolant temperature
is 20_C1,250 - 1,450
r/min
When engine
coolant temperature
is 40_C1,100 - 1,300
r/min
When engine
coolant temperature
is 80_C (more than
four minutes later
after engine has
started)600 - 800 r/min
A1LOxygen
sensorEngine: After having
warmed up. (Air/fuel
mixture is made
leaner when deceler-When at 4,000
r/min, engine is
decelerated200 mV or lessCode
No.
P013013A-28*
leanerwhendeceler
ating, and is made
richer when racing.)Rev the engine.600 - 1000 mV
Engine: After having
warmed up (The
oxygen sensor signal
is used to check the
air/fuel mixture ratio,
and control condition
isalsocheckbythe
Engine is idling
(more than 4
minutes later after
engine has started)Voltage should
alternate between
400 mV or less
and 600 - 1,200
mV (more than 4
minutes after the
enginehasisalso checkbythe
engine-ECU
or engine-A/T-ECU
.)
2,500 r/min
enginehas
started).
24LVehicle
speed sen-
sorDrive at 40 km/hApproximately 40
km/hCode
No.
P050013A-63*


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting13A-6
Item
No.Refer-
ence
page Inspec-
tion pro-
cedure
No. Normal condition Inspection contents Inspection
item
81LLearned
valueEngine: Warm, 2,500 r/min without any load
(during closed loop lambda control)- 10 - 10 %Code
No.
P017013A-34*
82LClosed loop
controlEngine: Warm, 2,500 r/min without any load
(during closed loop lambda control)- 25 - 25 %Code
No.
P017013A-34*
87LEngine loadEngine: After having
warmed upIdling (more than 4
minutes later after
the engine has
started)20 - 40 %--
2,500 r/min10 - 30 %
8ALThrottle
position
sensor(1st
DEngine: After hav-
ing warmed up
DIgnitionswitch:ON
Release the
accelerator pedal.0 - 20 %Code
No.
P0120
13A-25*
sensor(1st
channel)
(throttle
valve angle)DIgnition switch:ON
(Engine: stopped)Depress the
accelerator pedal.Increase in
proportion to the
pedal strokeP0120
Depress the
accelerator pedal
fully.80 - 100 %
NOTE
L: will not displayed if service data is selected on the check mode.
*: Refer to the 2001 PAJERO Workshop Manual (Pub.No. PWJE0001)


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting/On-vehicle Service13A-7
CHECK AT THE ENGINE-ECU TERMINALS
TERMINAL VOLTAGE CHECK CHART
Engine-A/T-ECU Connector Terminal Arrangement
The terminals below have been changed as the engine-A/T-ECU has been changed. The other terminals
are the same as before.
Terminal No.Check itemCheck requirements (Engine condition)Normal condition
3Oxygen sensor heat-
er(front)
Engine: Idling0-3V
er(front)
Engine: 3,500 r/minSystem voltage
26Oxygen sensor heat-
er(rear)
Engine: Idling0-3V
er(rear)
Engine: 3,500 r/minSystem voltage
71Oxygen sensor (front)Engine: Warmed up, and then hold the engine
speed at 2,500 r/min (Use a digital voltmeter)0 and 0.8 V alternate.
73Oxygen sensor (rear)DTransmission: 2nd gear
DEngine speed: 3,500 r/min or more
DDriving with the throttle valve widely open0.6 - 1.0 V
Engine-A/T-ECU Harness-side Connector Terminal Arrangement
The terminals below have been changed as the engine-A/T-ECU has been changed. The other terminals
are the same as before.
Terminal No.Check itemStandard value, normal condition (check conditions)
3-41Oxygen sensor heater (front)11 - 1 8Ω(at 20_C)
26 - 41Oxygen sensor heater (rear)11 - 1 8Ω(at 20_C)
ON-VEHICLE SERVICE
OXYGEN SENSOR CHECK
On A/T, a dual oxygen sensor has been adopted. Its service
procedure is the same as for the previous M/T.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

NOTES


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk
