GDI -Troubleshooting 13A-91
Inspection procedure 15
The feeling of impact when decelerating
Probable cause
The cause is probably insufficient intake air due to a faulty electronic-controlled throttle
valve system.DMalfunction of the electronic-controlled throttle valve
system
MUT-
IISelf-Diag code
Is a diagnosis code displayed?Ye s(Refer to P.13A-15, INSPECTION CHART FOR DIAGNOSIS
CODES.)
No
MUT-
IIData list
79 Throttle position sensor (1st channel) (Refer to P.13A-105.)NGCheck the throttle valve position feedback system. (Refer to
P.13A-65, code No. P1221.)
OK
MUT-
IIData list
26 Acceleratorpedal positionswitch (Refer to P.13A-105.)NGCheck the acceleratorpedal positionswitch system. (Refer to
P.13A-100, Inspection procedure 28.)
OK
Clean around the throttle valve. (Refer to P.13A-220.)
Inspection procedure 16
Knocking
Probable cause
The cause is probably incorrect detonation control or improper heat range of the
spark plugs.DMalfunction of the detonation sensor
DImproper heat range of the spark plugs
MUT-
IISelf-Diag code
Is a diagnosis code displayed?Ye s(Refer to P.13A-15, INSPECTION CHART FOR DIAGNOSIS
CODES.)
No
Does knocking occur when the vehicle is driven with the detonation
sensor disconnected?
(At this time, use the MUT-IIto check whether the ignitiontiming
is retarded from when the detonation sensor connector is con-
nected.)NoCheck the detonation sensor system. (Refer to P.13A-56, code
No. P0325.)
Ye s
Check all the following items:
DSparkplug
DForeign material (such as water or kerosine) entered the fuel
lines
Inspection procedure 17
Run-on (dieseling)
Probable cause
The cause is probably fuel leak from injector(s)DMalfunction of the injector
Replace the injector.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-92
Inspection procedure 18
Too high CO and HC concentration when idling
Probable cause
The cause is probably an incorrect air/fuel ratioDMalfunction of air/fuel ratio control system
DDeterioration of the catalyst
MUT-
IISelf-Diag code
Is a diagnosis code displayed?Ye s(Refer to P.13A-15, INSPECTION CHART FOR DIAGNOSIS
CODES.)
No
Check ignition timing. (Refer to GROUP 11A - Engine Adjustment.)NGCheck that the crankanglesensor andtiming beltcover are properly
installed.
OK
MUT-
IIData list
21 Engine coolant temperature sensor (Refer to P.13A-105.)NGCheck theengine coolant temperaturesensor. (Refer to P.13A-22,
code No. P0115.)
OK
MUT-
IIData list
13 Intake air temperature sensor (Refer to P.13A-105.)NGCheck the intake air temperature sensor. (Refer to P.13A-21, code
No. P0110.)
OK
MUT-
IIData list
25 Barometric pressure sensor (Refer to P.13A-105.)NGCheck the barometric pressure sensor. (Refer to P.13A-19, code
No. P0105.)
OK
NG
Check the oxygen sensor (front) system. (Refer to P.13A-31, code
No. P0130.)
OK
MUT-
IIData list
11 Oxygen sensor (front)
OK:
0 - 400 mV and 600 - 1,000 mV alternates when the
engine is idling(wait for four minutes after theengine
started).OKReplace the oxygen sensor (front).
Check trouble symptom.
NGNG
Measure fuel high-pressure between the fuel pump (highpressure)
and injector. (Refer to P.13A-224.)NG
Repair
OK
Check ignition coil spark for each cylinder.
(1) Remove the ignition coil.
(2) Install a new sparkplug to the removed ignitioncoil.
(3) Disconnect the injector intermediate connector.
Caution
Never touch the connector terminal as approx. 100 V is applied to the injector, or you are seriously injured.
(4) Earth the sparkplug electrodesecurely.
(5) Check that the sparkplug igniteswhen theengine iscranked.
NG
Replace the ignition coil.
OK
Check all the following items:
DSparkplug
DEGR system
DCompression pressure
DClogged fuel filter or line
OK
To the nextpage
OK
MUT-
IIData list
59 Oxygen sensor (rear) (Refer to P.13A-78.)
DTransmission: 2nd gear
DDriving with throttle widelyopen
OK:
600 - 1,000 mVNGCheck the oxygen sensor (rear) system. (Refer to P.13A-31, code
No. P0136.)
MUT-
IIData list
11 Oxygen sensor (front)
OK:
600 - 1,000 mV when theengine is suddenlyraced


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-93
From the previouspage
OK
MUT-
IIData list
68 EGR valve (Refer to P.13A-105.)NGCheck the EGR valve system. (Refer to P.13A-60, code No. P0403.)
OK
MUT-
IIActuator test
08 Purge control solenoid valve (Refer to P.13A-110.)NGCheck purge control solenoid valve system. (Refer to P.13A-62,
code No. P0443.)
OK
Check trouble symptom.NGReplace the injector.
Check trouble symptom.
NG
Replace the three-way catalytic converter.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-94
Inspection procedure 19
Low alternator output voltage (approx.12.3 V)
Probable cause
The cause is probably a malfunction of the alternator or one of the problems
listed at right.DMalfunction of the charging system
DOpen circuit between the alternator G terminal and
the engine-ECU
DMalfunction of the engine-ECU
NG
Repair
OK
Replace the engine-ECU.
OK
Check the alternator. (Refer to GROUP
16 - Charging System.)
OK
Check the following connectors:
B-41, B-59, D-119
Measure at the alternator connector
B-59.
DConnect the connector. (Use the
test harness MB991519)
DVoltage between 1 (black clip)
and earth
(Engine: Idling)
(Radiator fan: Not operating)
(Headlamp: OFF®ON)
(Stoplamp: OFF®ON)
(Rear defogger switch: OFF®
ON)
OK:
Voltage increased by
0.2 - 3.5 V.NGMeasure at the alternator connector
B-59.
DDisconnect the connector, and
measure at the harness side.
DDisconnect the engine-ECU
connector.
DContinuity between 1 and earth
OK:
No continuityNGCheck the harness wire between the
alternator and the engine-ECU, and
repair if necessary.
Inspection procedure 20
Idling speed is improper when A/C is operating
Probable cause
If the engine-ECU detects that the air conditioner is on, it activates the throttle control
servo to control idle-up operation.
The A/C-ECU judges if theloadcaused by air conditioner operation ishigh or low,
and converts it to voltage signal (high or low voltage) and inputs the signal to the
engine-ECU.
Based on this voltage signal, the engine-ECU controls the idle-up speed (forhigh
or low load).DMalfunction of the A/C control system
DImproper connector contact,opencircuit or
short-circuited harness wire
DMalfunction of the engine-ECU
NG
Repair
Measure at the engine-ECU connector D-117.
DConnect the connector.
DVoltage between 65 and earth (Engine: at idle, outside air
temperature: 25_C or more)
OK:
0 - 3 V [When A/C is MAX. COOL condition (when the
load by A/C is high)]
System voltage [When A/C is MAX. HOT condition (when
the load by A/C islow)]OKCheck the following connector:
D-117
OK
Check trouble symptom.
NG
Replace the engine-ECU.
NG
Check the A/C system. (Refer to GROUP 55 - On-vehicle Service.)


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-95
Inspection procedure 21
A/C condenser fan is inoperative
Probable cause
The fan motor relay is controlled by turning on and off the power transistor in
the engine-ECU.DMalfunction of the A/C condenser fan relay.
DMalfunction of the condenser fan motor.
DImproper connector contact,opencircuit or
short-circuited harness wire
DMalfunction of the engine-ECU
OK
Replace the engine-ECU.NG
Repair
OK
Check the trouble symptoms.
Check the following connector:
D-116
Measure at the engine-ECU connector D-116.
DDisconnect the connector, and measure at the harness side.
DCheck condition of the condenser fan.
(Ignition switch: ON)
OK:
Fan stops.
DThe voltage between 18 and earth
(Ignition switch: ON)
OK:
System voltage
DConnect a jumper cable between 18 and earth.
(Ignition switch: ON)
OK:
A/C condenser fan rotates.NGCheck the condenser fan circuit. (Refer to ELECTRICAL WIRING)
NG


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-96
Inspection procedure 22
Clutch switch system malfunction
Probable cause
The clutchpedalswitch sends a signal indicating clutchpedal depression to the
engine-ECU. The engine-ECU controls the fuel injection properly according to this
signal, thus prevents the fluctuation of theenginespeed during shift change.DMalfunction of the clutch switch
DOpen circuit or short-circuited harness wire in the clutch
switch circuit
DMalfunction of the engine-ECU
NG
Repair
NG
Repair
OK
Replace the engine-ECU.
(2) NG
OK
Check the trouble symptoms.
NG
Replace the engine-ECU.
OK
Check the following connector:
D-137
Check the harness wire between the
clutch switch connector and the earth,
and repair if necessary.
Check the trouble symptoms.
Check the harness wire between the
engine-ECU and the clutch switch con-
nector.
Measure at the clutch switch connector
D-137.
DDisconnect the connector, and
measure at the harness side.
(1) Voltage between 2 and earth
(Ignition switch: ON)
OK:
System voltage
(2) Continuity between 1 and earth
OK:
Continuity(1) NGCheck the following connector:
D-26 , D-124 , D-117,
E-10OK NG
Replace
Repair
OK
Check the clutch switch. (Refer to
P.13A-233.)
NG
NG
Inspection procedure 23
GDI ECO indicator lamp does not illuminate.
Probable cause
If the GDI ECO indicator lampdoes notilluminate after turningswitch, the causes
listed in the right column are suspected.DBurned-out GDI ECO indicator lamp bulb
DOpen circuit or short-circuited harness wire in the GDI
ECO indicator lampcircuit
DMalfunction of the engine-ECU
DMalfunction of the GDI ECO indicator lamp-ECU
NG
Repair
Measure at the engine-ECU connector D-116.
DDisconnect the connector, and measure at the harness side.
DEarth terminal 14 (Ignition switch: ON)
OK:
The GDI ECO indicator lamp illuminates.OKCheck the following connector:
D-116
OK
Check trouble symptom.
NG
Replace the engine-ECU.
NG
Check the following connectors:
E-13, E-112
Check trouble symptom.
Check the harness wire between the GDI ECO indicator lamp-ECU
and engine-ECU.
Check the relative circuit of GDI ECO indicatorlamp.(Refer to
GROUP 54A - Troubleshooting.)NG OK
OK NG
NG
Repair
Repair


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-97
Inspection procedure 24
GDI ECO indicator lamp remains illuminated and does
not go off.
Probable cause
If the GDI ECO indicator lampdoes not go off duringhigh load operation, thecauses
listed in the right column are suspected.DShort circuit between the GDI ECO indicatorlamp and
engine-ECU
DMalfunction of the engine-ECU
DMalfunction of the GDI ECO indicator lamp-ECU
OK
Replace the engine-ECU.
Measure at GDI ECO indicator lamp-ECU connector E-112.
DDisconnect the connector, and measure at the harness side.
DDisconnect the engine-ECU connector.
DContinuity between terminal 3 and earth
OK:
No continuityNGCheck the harness wire between the GDI ECO indicator
lamp-ECU and engine-ECU, and repair if necessary.
OK
Check the relative circuit of GDI ECO indicatorlamp.(Refer to
GROUP 54A - Troubleshooting.)


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

GDI -Troubleshooting 13A-98
Inspection procedure 25
Engine-ECU power supply and earth circuit system
Probable cause
The cause is probably a malfunction of the engine-ECU or one of the problems
listed at right.DOpen circuit or short-circuited harness wire in the
engine-ECU power supply circuit
DOpen circuit or short-circuited harness wire in the
engine-ECU earth circuit
DMalfunction of the engine-ECU
NG
RepairOK
Check the ignition switch. (Refer to
GROUP 54.)
(2), (3) NGCheck the harness wire between the
engine-ECU and engine controlrelay,
and repair if necessary.
(4) NG
Check the harness wire between the
engine-ECU and earth, and repair if nec-
essary.
(5) NG
NG
Repair
OK
Check the trouble symptoms.NGCheck the harness wire between the
engine-ECU and the battery, and repair
if necessary.
NG
Repair
NG
Replace the engine-ECU.
OK
Check the trouble symptoms.
OK
Check the following connectors:
D-117, D-118
Check the following connectors:
D-27, D-31 , E-13OK
Check the trouble symptoms.NGCheck the harness wire between the
engine-ECU and ignition switch, and re-
pair if necessary.
Measure at the engine-ECU connectors
D-117, D-118.
DDisconnect the connector, and
measure at the harness side.
(1) Voltage between 99 and earth
(Ignition switch: ON)
OK:
System voltage
(2) Voltage between 57 and earth
OK:
System voltage
(3) Voltage between 47, 59 and
earth (Ignition switch: ON)
OK:
System voltage (When ter-
minal 57 is shorted to
earth)
(4) Continuity between 46, 58 and
earth
OK:
Continuity
(5) Voltage between 60 and earth
OK:
System voltage(1) NGCheck the following connector:
D-208, D-223, E-13NG
Repair
Check the following connector:
D-14NG
Repair
Check the trouble symptoms.OK
NG


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk
