SWS -Troubleshooting54B-35
Inspection Procedure K-2
Headlamp, tail lamp: Headlamps (low-beam) do not
illuminate.Probable cause
The column switch or the front-ECU may be defective.DMalfunction of column switch
DMalfunction of front-ECU
DMalfunction of harness wire or connector
OK
Replace the front-ECU.
No
NG
Check theheadlampswitch input circuit. (Refer to P.54B-49, Inspec-
tion Procedure P-13.)
Ye sCarry out troubleshooting while referring to the Diagnosis Code
Chart on P.54B-9.
NG
Repair
NG
Check the harness wire between front-ECU and battery.
OK
Check trouble symptoms.
OK
NG
Check the following connector:
A-07XMeasure at front-ECU connector A-07X.
DDisconnect connector and measure at relay box side.
DVoltage between terminal 3 and body earth.
OK:System voltage
DVoltage between terminal 4 and body earth.
OK:System voltage
MUT-
IIinput signal check
DHeadlamp switch
Is a diagnosis code output when the ignition switch is at the
OFF (LOCK) position?
NOTE
If only one of the headlamps (low-beam) does not illuminate, the harness wire between the headlamp
and front-ECU may be defective or the headlamp bulb may be burned out. In this case, check the headlamp
circuit.
Inspection Procedure K-3
Headlamp, tail lamp: Headlamps (high-beam) do not
illuminate.Probable cause
The column switch or the front-ECU is suspected to be defective.DMalfunction of column switch
DMalfunction of front-ECU
DMalfunction of harness wire or connector
OK
Replace the front-ECU.
Is the headlamps (low-beam) operated normally?NoCheck theheadlamp (low-beam)circuit. (Refer to P.54B-35, Inspec-
tion Procedure K-2.)
Ye s
MUT-
IIinput signal check
DDimmer switchNGCheck the dimmer switch input circuit. (Refer to P.54B-49, Inspection
Procedure P-13.)
NOTE
If only one of the headlamps (high-beam) does not illuminate, the harness wire between the headlamp
and front-ECU may be defective or the headlamp bulb may be burned out. In this case, check the headlamp
circuit.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

SWS -Troubleshooting54B-36
Inspection Procedure K-4
Headlamp, tail lamp: Headlamps do not illuminate when
the passing switch is operated.Probable cause
If the headlamps (low-beam and high-beam) are defective, the column switch or
the front-ECU is suspected to be defective.DMalfunction of column switch
DMalfunction of front-ECU
DMalfunction of harness wire or connector
OK
Replace the front-ECU.
Is the headlamps (low-beam and high-beam) operated normally?NoCheck the defective circuit. (Refer to P.54B-13, Trouble Symptom
Chart.)
Ye s
MUT-
IIinput signal check
DPassing switchNGCheck the passing switch input circuit. (Refer to P.54B-49, Inspec-
tion Procedure P-13.)
Inspection Procedure K-5
Headlamp, tail lamp: The headlamp automatic shutdown
function does not work normally.Probable cause
The ETACS-ECU operates theheadlamp automatic shutdown function,based on
the signals from the following switches
DIgnition switch (IG1)
DDriver’s door switch
DHeadlamp switch
If the head lamp automatic shutdown functiondoes work normally, a defect on
relevant input circuits, the ETACS-ECU or the front-ECU is suspected.DMalfunction of driver’s door switch
DMalfunction of column switch.
DMalfunction of front-ECU
DMalfunction of harness wire or connector
No
NG
Check the defective input circuit. (Refer to P.54B-15, Defects Found
by Input Signal Check.)
Ye sCarry out troubleshooting while referring to the Diagnosis Code
Chart on P.54B-9.
NG
Replace the front-ECU.
OK
Replace the ETACS-ECU.Check trouble symptoms.
MUT-
IIinput signal check
DIgnition switch (IG1)
DDriver’s door
DHeadlamp switch
Is a diagnosis code output when the ignition switch is at the
OFF (LOCK) position?


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

SWS -Troubleshooting54B-37
Inspection Procedure K-6
Headlamp, tail lamp: Headlamps dimmer switch automat-
ic reset function does not work normally.Probable cause
The headlamp dimmerswitch automatic reset function is controlled by the
front-ECU. If a defect appears, the front-ECU may be defective.DMalfunction of front-ECU
Replace the front-ECU.
Inspection Procedure K-7
Headlamp, tail lamp: Daytime running lamp (DRL) function
does not work.Probable cause
The headlamp dimmerswitch auto-reset function is controlled by the front-ECU.
If a defect appears, the front-ECU may be defective.DMalfunction of ETACS-ECU
DMalfunction of front-ECU
DMalfunction of harness wire or connector.
NoCheck the defective device. (Refer to P.54B-13, Trouble Symptom
Chart.)
Ye s
NG
NG
Repair
NG
Check the harness wire between ETACS-ECU and body earth.
OK
Replace the ETACS-ECU or front-ECU.
OK
Check trouble symptoms.
Check the following connectors:
D-226, D-27Measure at ETACS-ECU connector D-226.
DDisconnect connector and measure at harness side.
DContinuity between terminal 29 and body earth.
OK:Continuity
Are the tail lamp and headlamps operated normally?
Inspection Procedure L-1
Flasher timer: Turn-signal lamp do not flash when the
turn-signal lamp switch is turned on.Probable cause
The ETACS-ECU makes the turn-signal lamps flash, based on the input signals
from the following switches:
DIgnition switch (IG1)
DTurn-signal lampswitch
If the turn-signal lamps do not flash normally, a defect on the relevant circuits or
the ETACS-ECU may be suspected.
If the hazard warning lamps also do not flash, a defect in the ETACS-ECU
power supply line specific to the turn-signal lamps is suspected.DMalfunction of column switch
DMalfunction of ETACS-ECU
DMalfunction of harness wire or connector.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

SWS -Troubleshooting54B-38
No
NG
OK
Replace the ETACS-
ECU.
NG
Check the defective input
circuit. (P.54B-15, De-
fects Found by Input Sig-
nal Check.)
NG
Repair
NG
Check the harness wire between ETACS-ECU and battery.
OK
NG
Repair
OK
Replace the ETACS-ECU.
NG
Check the harness wire between ETACS-ECU and turn-signal
lamps.NG
Repair
OK
Check trouble symptoms.
Check the following connectors:
D-224, D-213, D-210, D-218 , D-219 drive vehicles>
OK
Check trouble symptoms.
Check the following connectors:
D-224, D-223, D-27Measure at ETACS-ECU connector D-224.
DDisconnect connector and measure at J/B side.
DVoltage between terminal 11 and body earth.
OK:System voltage.
Is the hazard warninglamp operated normally?Ye sMUT-
IIinput signal check
DIgnition switch (IG1)
DTurn-signal lampswitch
NOTE
If only one of the turn-signal lamp does not flash, the harness wire between the lamp and ETACS-ECU
may be defective or the lamp bulb may be burned out. In this case, check the turn-signal lamp and
hazard warning lamp circuit.
Inspection Procedure L-2
Flasher timer: Hazard warning lamp do not flash when the
hazard warning lamp switch is turned on.Probable cause
The ETACS-ECU makes the turn-signal lamps flash, base on the input signals
from the hazard warninglampswitch.
If the turn-signal lamps do not flash normally, the hazard warninglampswitch
input circuit or the ETACS-ECU may be defective.DMalfunction of hazard warninglampswitch
DMalfunction of ETACS-ECU
DMalfunction of harness wire or connector.
OK
Replace the ETACS-ECU.
NoCheck the turn-signallampcircuit. (Refer to P.54B-37, Inspection
Procedure L-1.)
Ye s
NG
Check the ETACS-ECU battery circuit. (Refer to P.54B-53, Inspec-
tion Procedure Q-1.)
OK
NG
Check the hazard warninglampswitch input circuit. (Refer to
P.54B-43, Inspection Procedure P-4.)MUT-
IIinput signal check
DHazard warninglampswitch
Do all of the following functions operate when the ignition key
is at the LOCK (OFF) position?
DLight reminder warning function
DRoom lamp
Is the turn-signal lamp operated normally?


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

SWS -TroubleshootingSWS -Troubleshooting54B-39
Inspection Procedure M-1
Front fog lamp: Front fog lamps do not illuminate when the
front fog lamp switch is turned on.Probable cause
If the tail lamps and headlamps illuminate normally, the front fog lampswitch, the
front fog lamprelay, the front-ECU or the ETACS-ECU may be defective.DMalfunction of front fog lampswitch
DMalfunction of front fog lamprelay
DMalfunction of front-ECU
DMalfunction of ETACS-ECU
DMalfunction of harness wire or connector.
OK
Replace the front-ECU.Check trouble symptoms.
NGCheck the defective circuit. (Refer to P.54B-13, Trouble Symptom
Chart.)
OK
NG
Check the front foglampswitch input circuit. (Refer to P.54B-44,
Inspection Procedure P-5.)
OK
NG
NG
Repair
NG
Check the harness wire between front foglamprelay and battery.
OK
NG
Repair
NG
Check the harness wire between front foglamprelay and front-ECU,
front fog lamprelay and front fog lamps.NG
Repair
OK
Check trouble symptoms.
Check the following connectors:
A-09X, A-07X, A-15, A-26, A-22, A-33
OK
Check trouble symptoms.
Check the following connector:
A-09XMeasure at front fog lamprelay connector A-09X.
DDisconnect connector and measure at relay box side.
DVoltage between terminal 3 and body earth.
OK:System voltage
DVoltage between terminal 4 and body earth.
OK:System voltage
OK
Check the front foglamprelay. (Refer to GROUP 54A – Fog Lamp.)NG
Replace
MUT-
IIinput signal check
DFront fog lampswitch
Is the tail lamps and headlamps operated normally?
NG
Replace the ETACS-ECU.
NOTE
If only one of the front fog lamp or front fog lamp indicator lamp does not illuminate, the harness wire
between the lamp and front fog lamp relay may be defective or the lamp bulb may be burned out. In
this case, check the front fog lamp circuit.
Inspection Procedure M-2
Front fog lamp: Front fog lamp do not go out when the tail
lamps are turned off while the fog lamps are on.Probable cause
If the malfunction above occurs, the ETACS-ECU may be defective.DMalfunction of ETACS-ECU
Replace the ETACS-ECU.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

SWS -Troubleshooting54B-40
Inspection Procedure N-1
Rear fog lamp: Rear fog lamps do not illuminate when the
rear fog lamp switch is turned on.Probable cause
If the headlamps and rear fog lamps illuminate normally, the rear foglamp
switch, the rear foglamprelay or the ETACS-ECU may be defective.DMalfunction of rear foglampswitch
DMalfunction of rear foglamprelay
DMalfunction of ETACS-ECU
DMalfunction of harness wire or connector.
NoCheck the defective device. (Refer to P.54B-13, Trouble Symptom
Chart.)
Ye s
NG
Check the Rear foglampswitch input circuit. (Refer to P.54B-45,
Inspection Procedure P-6.)
OK
NG
Replace
OK
NG
NG
Repair
NG
Check the harness wire between rearlamprelay and fusible link
(1).
OK
NG
Repair
OK
Check trouble symptoms.
Check the following connectors:
D-212, D-226, D-26, D-124, G-02, G-07
OK
Check trouble symptoms.
Check the following connectors:
D-212, D-210, D-211, D-27Measure at rear foglamprelay connector D-212.
DDisconnect connector and measure at relay box side.
DVoltage between terminal 3 and body earth.
OK:System voltage
DVoltage between terminal 5 and body earth.
OK:System voltage
Check the rear foglamprelay. (Refer to GROUP 54A – Fog Lamp.)
MUT-
IIinput signal check
DRear foglampswitch
Are the headlamps and front fog lamps operated normally?
OK
Replace the ETACS-ECU.
NG
Check the harness wire between rear foglamprelay and ETACS-
ECU, rear foglamprelay and rear combination lamps.NG
Repair
NOTE
If only one of the rear fog lamp or rear fog lamp indicator lamp does not illuminate, the harness wire
between the lamp and rear fog lamp relay may be defective or the lamp bulb may be burned out. In
this case, check the rear fog lamp circuit.
Inspection Procedure N-2
Rear fog lamp: Rear fog lamp do not go out when the
headlamps and front fog lamps are turned off while the fog
lamps are on.Probable cause
If the malfunction above occurs, the ETACS-ECU may be defective.DMalfunction of ETACS-ECU
Replace the ETACS-ECU.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

SWS -Troubleshooting54B-41
Inspection Procedure O-1
Room lamp: Room lamp does not illuminate.Probable cause
If the room lampdoes not illuminate at all, the roomlamp bulb may be burned
out, or the power supply circuit or the ETACS-ECU may be defective.DMalfunction of room lamp
DMalfunction of ETACS-ECU
DMalfunction of harness wire or connector
Ye s
NG
Repair
NG
No
NG
OK
Replace the room lamp.
NG
Repair
NG
Check the harness wire between roomlamp and fusiblelink (2).
OK
Replace the ETACS-
ECU.
NG
Repair
OK
Check trouble symptoms.
Check the following connectors:
F-07, D-29, D-207, D-223, D-27Measure at room lampconnector F-07.
DDisconnect connector and measure at harness side.
DVoltage between terminal 1 and body earth.
OK:System voltage
Check the harness wire between roomlamp and ETACS-ECU.
OK
Check trouble symptoms.
Check the following connectors:
F-07, D-29, D-207, D-224Does the roomlampturn on when the roomlampswitch is
set to the ON position?
Inspection Procedure O-2
Room lamp: Room lamp dimming function does not work
normally.Probable cause
The ETACS-ECU dims the roomlamp according to the inputsignals from the
following switches:
DIgnition switch (IG1)
DKey reminder switch
DDoor switches
DDriver’s door lock actuator switch
If the room lampdoes not bedimmed normally, the relevant input signalcircuit
or the ETACS-ECU may be defective.DMalfunction of key reminder switch
DMalfunction of driver’s door switch
DMalfunction of door switches
DMalfunction of driver’s door lock actuator switch
DMalfunction of ETACS-ECU
DMalfunction of harness wire or connector
NGCheck the ETACS-ECU battery circuit. (Refer to P.54B-53, Inspec-
tion Procedure Q-1.)
OK
NG
Check the defective input circuit. (Refer to P.54B-15, Defects Found
by Input Signal Check.)
OK
Replace the ETACS-ECU.
MUT-
IIinput signal check
DIgnition switch (IG1)
DKey reminder switch
DDoor switches
DDriver’s door lock actuator switch
Do all of the following functions operate when the ignition key
is at the LOCK (OFF) position?
DLight reminder warning function
DCentral door locking system
DHazard warninglamp


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

SWS -Troubleshooting54B-42
Inspection Procedure P-1
Ignition switch (ACC) signal is not sent to the ETACS-ECU.Probable cause
The ignition switch (ACC) input signal is used to operate the following devices. If
the signal fails, these devices will not work normally.
DWindshield wiper and washer
DRear wiper and washer
DHeadlamp washerDMalfunction of ETACS-ECU
DMalfunction of harness wire or connector
NG
NG
Repair
NG
Check the harness wire between ETACS-ECU and ignition switch
(ACC).
OK
Check trouble symptoms.OK
Replace the ETACS-ECU.
Check the following connectors:
D-224, D-208Measure at ETACS-ECU connector D-224.
DDisconnect connector and measure at J/B side.
DTurn the ignition switch to ACC position.
DVoltage between terminal 2 and body earth.
OK:System voltage
Inspection Procedure P-2
Ignition switch (IG1) signal is not sent to the ETACS-ECU.Probable cause
The ignition switch (IG1) input signal is used to operate the following devices. If
the signal fails, these devices will not work normally.
DLight reminder warning buzzer function
DPower window timer function
DSunroof timer function
DIgnition key hole illumination lamp
DHeadlamp automatic shutdown function
DTurn-signal lamp
DRoom lamp dimming functionDMalfunction of ETACS-ECU
DMalfunction of harness wire or connector
NG
NG
Repair
NG
Check the harness wire between ETACS-ECU and ignition switch
(IG1).
OK
Check trouble symptoms.OK
Replace the ETACS-ECU.
Check the following connectors:
D-224, D-208Measure at ETACS-ECU connector D-224.
DDisconnect connector and measure at J/B side.
DTurn the ignition switch to ON position.
DVoltage between terminal 16 and body earth.
OK:System voltage


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk
