2000 MITSUBISHI MONTERO Service Repair Manual

AUTOMATIC TRANSMISSION -Troublehshooting II>23-84
Code No. 41 Shift actuator system (open circuit or
short-circuit)Probable cause
Code No. 41 is output to indicate anopencircuit or short-circuit in the shift
actuator if the transfer-ECU terminal voltage is higher than themainrelay
voltage (90% of the rated voltage), or lower than themainrelay voltage (10% of
the rated voltage) when shift operation is notbeingcarried out.DMalfunction of shift actuator
DMalfunction of harness or connector
DMalfunction of transfer-ECU
LRefer to the Transmission Workshop Manual.
NG
NG
NG
MUT-
IIData List
DNo. 12 Shift actuator voltage
OK:Refer to P.23-87 (Data List Chart).Transient malfunction (Refer to GROUP 00 - Points to Note
for Transient Malfunctions.) OK
OK NG
Check the harness between the shift actuator and the
transfer-ECU, and repair if necessary.Repair
OKOK
OK
OK
NG
NG
Replace the transfer-ECU.
Check the following connectors:C-11, E-105Measure at shift actuator connector C-11.
DDisconnect the connector and measure at the harness
side.
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 2.
DVoltage between terminals 2 and earth
OK:System voltage
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 3.
DVoltage between terminal 1 and earth
OK:System voltage
Measure at transfer-ECU connector E-105
DMeasure at ECU terminals.
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 2.
DVoltage between terminal 1 and earth
OK:System voltage
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 3.
DVoltage between terminals 3 and earth
OK:System voltage
Repair NG
Check the following connector:C-11Repair
Replace the shift actuator.
L
Check the following connector:E-105
Check the trouble symptoms.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

AUTOMATIC TRANSMISSION -Troublehshooting II>23-85
Code No. 42 Shift actuator system (short-circuit)Probable cause
Code No. 43 Shift actuator system (open circuit)
Code No. 42 is output to indicate a short-circuit in the shift actuator if the shift
actuator current is +1 A greater than the target value while the actuator isbeing
driven.
Code No. 43 is output to indicate anopencircuit in the shift actuator if themain
relay voltage is lower than 6 V, or the shift actuator current is 0.1 A lower than
the actual value while the actuator isbeing driven.DMalfunction of shift actuator
DMalfunction of harness or connector
DMalfunction of transfer-ECU
LRefer to the Transmission Workshop Manual.
NG
NG
MUT-
IIData List
DNo. 10 Shift actuator voltage
OK:Refer to P.23-87 (Data List Chart).Transient malfunction (Refer to GROUP 00 - Points to Note
for Transient Malfunctions.) OK
OK NG
Check the harness between the shift actuator and the
transfer-ECU, and repair if necessary.Repair
Check the following connector:E-105
OK OK
NG
OK
OK
NG
NG
Check the trouble symptoms.
Replace the transfer-ECU.
Check the following connectors:C-11, E-105Measure at shift actuator connector C-11.
DDisconnect the connector and measure at the harness
side.
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 2.
DVoltage between terminals 2 and earth
OK:System voltage
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 3.
DVoltage between terminal 1 and earth
OK:System voltage
Measure at transfer-ECU connector E-105
DMeasure at ECU terminals.
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 2.
DVoltage between terminal 1 and earth
OK:System voltage
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 3.
DVoltage between terminals 3 and earth
OK:System voltage
Repair NG
Check the following connector:C-11Repair
Replace the shift actuator.
L


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

AUTOMATIC TRANSMISSION -Troublehshooting II>AUTOMATIC TRANSMISSION -Troublehshooting II>23-86
Code No. 44 Shift actuator system (overload)Probable cause
Code No. 44 is output to indicate an overload of the shift actuator when the
total time calculated for driving the shift actuator exceeds 5 minutes.DMalfunction of shift actuator
DMalfunction of harness or connector
DMalfunction of transfer-ECU
DMalfunction of transfer shift mechanism
LRefer to the Transmission Workshop Manual.
NG
NG
MUT-
IIData List
DNo. 12 Shift actuator voltage
OK:Refer to P.23-87 (Data List Chart).Transient malfunction (Refer to GROUP 00 - Points to Note
for Transient Malfunctions.) OK
OK NG
Check the harness between the shift actuator and the
transfer-ECU, and repair if necessary.Repair
Check the following connector:E-105
OK
NG
OK
OK
NG
Replace the transfer-ECU.
Check the following connectors:C-11, E-105Measure at shift actuator connector C-11.
DDisconnect the connector and measure at the harness
side.
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 2.
DVoltage between terminals 2 and earth
OK:System voltage
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 3.
DVoltage between terminal 1 and earth
OK:System voltage
Measure at transfer-ECU connector E-105
DMeasure at ECU terminals.
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 2.
DVoltage between terminal 1 and earth
OK:System voltage
DDrive the shift actuator in accordance with MUT-
IIactuator
test No. 3.
DVoltage between terminals 3 and earth
OK:System voltage
Repair NG
Check the following connector:C-11Repair
MUT-II Actuator test
DNo. 2, No. 3 Shift actuator
OKRefer to P.23-89 (Actuator Test).
OKNGReplace the shift actuator.
L
Code No. 45 Incorrect tyre diametersProbable cause
Code No. 45 is output to indicate incorrect tyre pressure, uneven tyre sizes or
non-uniform tyre brands, which have caused a large difference in speed between
the front and rear wheel speeds and the setting values when the freewheel
engageswitch is on.DMalfunction of tyre
DMalfunction of transfer-ECU
NG
Replace
Replace the transfer-ECU. NGCheck the trouble symptoms.
OK
Tyre Check
Code No. 51 Malfunction of transfer-ECUProbable cause
Code No. 51 is output when a problem with the transfer-ECU is detected.DMalfunction of transfer-ECU
Replace the transfer-ECU.


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

AUTOMATIC TRANSMISSION -Troubleshooting II>23-87
DATA LIST REFERENCE TABLE
Item
No.Check itemInspection conditionsNormal condition
1Accelerator pedalEngine: StoppedAccelerator pedal: Fully closed985 - 1,085 mV
position sensor
(APS)Selector lever position:
PAccelerator pedal: DepressedGradually increases from
the above value.
Accelerator pedal: Fully open4000 mV or higher
2Front propeller shaft
speed sensorTransfer position: 4WDDriving at a constant speed of
30 km/h30 km/h
3Rear propeller shaftTransfer position: 4WDDriving at a constant speed of30 km/h3Rear propeller shaft
speed sensorTransfer position: 4WDDriving at a constant speed of
30 km/h30 km/h
4Difference between
front and rear pro-
peller shaft speedsTransfer position: 4WDDriving at a constant speed of
30 km/hWithin 5 km/h
5Vehicle speedIdling in 1st (Vehicle stopped)0 km/h
Driving at a constant speed of 50 km/h in 3rd50 km/h
6Transfer lever posi-Ignition switch: ONTransfer shift lever position: 2H2H
tionEngine: StoppedTransfer shift lever position: 4H4H
Transfer shift lever position:
4HLc4HLc
Transfer shift lever position:
4LLc4LLc
7Transfer positionDriving at a constant
speed of 10 km/hTransfer shift lever position:
2H®4H2H - 4H®4H
Transfer shift lever position:
4H®4HLc4H - 4HL®4HL
Engine: Stopped
Selector lever position:Transfer shift lever position:
4HLc®4LLc4HL - 4LL®4LL
NTransfer shift lever position:
4LLc®4HLc4HL - 4LL®4HL
Driving at a constant
speed of 10 km/hTransfer shift lever position:
4HLc®4H4H - 4HL®4H
Transfer shift lever position:
4H®2H2H - 4H®2H
8Main relay voltageIgnition switch: ONSystem voltage (V)
9Ignition voltageIgnition switch: ONSystem voltage (V)
10Shift actuator cur-
rentDuring transfer selection (while motor is running)0A®0.2 A®0A
11Target currentDuring transfer selection (while motor is running)0A®1.5 A®0A
12Shift actuator volt-
ageIgnition switch: ON
Selector lever position: N
Transfer shift lever position: 2H®4H (or 4H®4HLc,
4HLc®4LLc)System voltage (V)
Ignition switch: ON
Selector lever position: N
Transfer shift lever position: 4LLc®4HLc (or 4HLc®4H,
4H®2H)System voltage (V)


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

AUTOMATIC TRANSMISSION -Troubleshooting II>23-88
Item
No.Normal condition Inspection conditions Check item
21Ignition switchIgnition switch: ONON
Ignition switch: OFFOFF
22Transmission identi-
ficationVehicles with A/TA/T
23Stop lamp switchIgnition switch: ONBrake pedal: DepressedON
Engine: StoppedBrake pedal: ReleasedOFF
24Transfer leverTransfer shift lever position: 2HON
switch 2HTransfer shift lever position: Other than the aboveOFF
25Transfer leverTransfer shift lever position: 4HON
switch 4HTransfer shift lever position: Other than the aboveOFF
26Transfer leverTransfer shift lever position: 4HLcON
switch 4HLcTransfer shift lever position: Other than the aboveOFF
27Transfer leverTransfer shift lever position: 4LLcON
switch 4LLcTransfer shift lever position: Other than the aboveOFF
28Engine identificationPetrol vehiclesPETROL
Diesel vehiclesDIESEL
30Freewheel engageDuring 2WDON
solenoid valveDuring 4WDOFF
31Inhibitor switch NSelector lever position: NON
Selector lever position: Other than the aboveOFF
32Inhibitor switch PSelector lever position: PON
Selector lever position: Other than the aboveOFF
332WD switchDriving conditions: 2WD (2H)ON
Driving conditions: Other than the aboveOFF
342WD/4WD switchDriving conditions: 2WD (2H), 4WD (4H)ON
Driving conditions: Other than the aboveOFF
354H switchDriving conditions: 4WD (4H), 4WD (4HLc)ON
Driving conditions: Other than the aboveOFF
36Center differentialDriving conditions: 4WD (4HLc), 4WD (4LLc)ON
lock switchDriving conditions: Other than the aboveOFF
374LLc switchDriving conditions: 4WD (4LLc)ON
Driving conditions: Other than the aboveOFF
38Freewheel engageDuring 2WDOFF
switchDuring 4WDON


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

C
heck it e m T
e st co nte nts I
n sp ectio n co ndit io ns N
orm alco ndit io n 1 F
re ew heel engage so -
l e noid va lv e T
he fr e ew heel en-
g age so le noid va lv e
i s driv e n. I
g nit io n sw it c h : O N
S ele cto r le ve r posit io n:
P I
f th e fr e ew heele ngage so le noid
v a lv e is on,it is tu rn ed off , and if
i t is off , it is tu rn ed on. 2
S
hif t actu ato r T
he m oto rin sid e th e
s h if t actu ato r is ru n
i n th e fo rw ard dir e c-
t io n. P
E ngin e: 0 r/m in
V ehic le sp eed: 0 km /h
( v e hic le sto pped) I
f th e tr a nsfe r is atth e 2H ,4 H or
4 H Lc posit io n, it sh if ts fr o m th at
p osit io n to th e 2H , 4H , 4H Lc,
4 LLc posit io ns in th ato rd er, a nd
t h en re tu rn s to th e orig in al
p osit io n. If it is at th e 4LLc
p osit io n, no sh if tin g is ca rrie d
o ut. 3 T
he m oto rin sid e th e
s h if t actu ato r is ru n
i n th e re ve rs e dir e c-
t io n. I
f th e tr a nsfe r is atth e 4H ,4 H Lc
o r 4LLc posit io n, it sh if ts fr o m
t h atp osit io n to th e 4LLc, 4 H Lc ,
4 H , 2H posit io ns in th at ord er,
a nd th en re tu rn s to th e orig in al
p osit io n.If it is atth e 2H posit io n,
n o sh if tin g is ca rrie d out.

AUTOMATIC TRANSMISSION -Troubleshooting II>23-90
Ter-
minal
No.Check itemInspection conditionsStandard value
1Shift actuatorTransfer shift lever position: 2H®4H5.6 V®11.0 V®
5.6 V
3Shift actuatorTransfer shift lever position: 4H®2H5.6 V®11.0 V®
5.6 V
5Accelerator pedal positionAccelerator pedal: Fully closed (engine stopped)0.985 - 1.085 V
sensor (APS)Accelerator pedal: Fully open (engine stopped)4.0 V or higher
7Front propeller shaft speed
sensorMeasure the voltage between terminals 7 and 18 using
an oscilloscope.
Engine: 2 000 r/min
Shift range: 4thOscilloscope check
procedure (Refer to
P. 23-69 Pattern B>.)
9Rear propeller shaft speed
sensorMeasure the voltage between terminals 9 and 18 using
an oscilloscope.
Engine: 2 000 r/min
Shift range: 4thOscilloscope check
procedure (Refer to
P. 23-69 Pattern B>.)
11Diagnosis outputWhen normal (no diagnosis codes are output)0 V and 5 V alterna-
tes
13Power supplyIgnition switch: OFF0V
Ignition switch: ONSystem voltage
18Sensor earthAt all times0.5 V or less
20Transfer lever switch 2HTransfer shift lever position: 2HSystem voltage
Transfer shift lever position: Other than the above0V
21Transfer lever switch 4HTransfer shift lever position: 4HSystem voltage
Transfer shift lever position: Other than the above0V
22Transfer lever switch 4HLcTransfer shift lever position: 4HLcSystem voltage
Transfer shift lever position: Other than the above0V
23Transfer lever switch 4LLcTransfer shift lever position: 4LLcSystem voltage
Transfer shift lever position: Other than the above0V
24Diagnosis control––
25EarthAt all times0V
26EarthAt all times0V
31Backup power supplyAt all timesSystem voltage
32Inhibitor switch NSelector lever position: NSystem voltage
Selector lever position: Other than the above0V
33Inhibitor switch PSelector lever position: PSystem voltage
Selector lever position: Other than the above0V
34Stop lamp switchBrake pedal: DepressedSystem voltage
Brake pedal: Released0V
35EarthAt all times0V
37Rear wheel indicator lampOther than during transfer selectionSystem voltage
38Front wheel indicator lampDuring 4WDSystem voltage
39Earth <6G7>At all times0V


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk

AUTOMATIC TRANSMISSION -Troubleshooting II>23-91
Ter-
minal
No.Standard value Inspection conditions Check item
40Center differential lock
lampDuring 4WD (4HLc or 4LLc)System voltage
41Solenoid valve A, BTransfer shift lever position: 2H1V
Transfer shift lever position: Other than 2HSystem voltage
42EarthAt all times0V
432WD switchTransfer shift lever position: 2H0V
Transfer shift lever position: Other than 2H10.5 V
442WD/4WD switchTransfer shift lever position: 2H or 4H0V
Transfer shift lever position: 4HLc or 4LLc10.5 V
454H switchTransfer shift lever position: 4H or 4HLc0V
Transfer shift lever position: 2H or 4LLc10.5 V
46Center differential lockTransfer shift lever position: 4HLc or 4LLc0V
switchTransfer shift lever position: 2H or 4H10.5 V
474HLc switchTransfer shift lever position: 4LLc0V
Transfer shift lever position: Other than 4LLc10.5 V
50Freewheel engage switchTransfer position: 2WD10.5 V
Transfer position: 4WD0V


www.WorkshopManuals.co.uk


Purchased from www.WorkshopManuals.co.uk
