EXTERIOR -Garnish51-18
REMOVAL SERVICE POINT
A
A"
SIDE SILL GARNISH REMOVAL
Remove by the same procedure as given in FRONT DOOR
MOULDING, FRONT WHEEL CUT MOULDING, REAR
WHEEL CUT MOULDING AND REAR DOOR MOULDING
REMOVAL. (Refer to P.51-14.)
INSTALLATION SERVICE POINT
"
AA
SIDE SILL GARNISH INSTALLATION
Install by the same procedure as given in FRONT DOOR
MOULDING, FRONT WHEEL CUT MOULDING, REAR
WHEEL CUT MOULDING AND REAR DOOR MOULDING
INSTALLATION. (Refer to P.51-14.)
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk
Page 1426 of 1839
S
pecif ie d se ala nta nd adhesiv e F
ro nt m udguard D
ouble -s id ed ta pe [5 m m wid e and 0.8 m m th ic k] R
ear m udguard 1
5
B C V
ie w B
A dhesiv e ta p e: Double -s id e ta p e [5 mm wid th an d 0.8 mm
t h ic kn ess.] <
Short w heelb ase >
Page 1427 of 1839
EXTERIOR -Mudguard51-20
REMOVAL SERVICE POINTS
A
A"
FRONT MUDGUARD, REAR MUDGUARD
REMOVAL
Remove by the same procedure as given in FRONT DOOR
MOULDING, FRONT WHEEL CUT MOULDING, REAR
WHEEL CUT MOULDING AND REAR DOOR MOULDING
REMOVAL. (Refer to P.51-14.)
A
B"
FRONT MUDGUARD COVER REMOVAL
Remove by the same procedure as for REAR MUDGUARD
REINFORCEMENT, REAR BUMPER SIDE RETAINER,
REAR BUMPER CORNER BRACKET REMOVAL. (Refer to
P.51-10.)
INSTALLATION SERVICE POINTS
"
AA
FRONT MUDGUARD, REAR MUDGUARD
INSTALLATION
Install by the same procedure as given in FRONT DOOR
MOULDING, FRONT WHEEL CUT MOULDING, REAR
WHEEL CUT MOULDING AND REAR DOOR MOULDING
INSTALLATION. (Refer to P.51-14.)
"
BA
FRONT MUDGUARD COVER INSTALLATION
Install by the same procedure as for REAR MUDGUARD
REINFORCEMENT, REAR BUMPER SIDE RETAINER, REAR
BUMPER CORNER BRACKET INSTALLATION. (Refer to
P.51-10.)
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk
Page 1428 of 1839
N
um ber N
am e U
se M
B990784 O
rn am entre m ove r R
ear defle cto r co ve r re m ova l S
ectio n A –A
T a b 5
.0
±1
.0 N
×m 5
.0
±1
.0 N
×m
R ear defle cto r re m oval ste p s
1 . R esin plu g A
A"
2. R ear defle cto r co ve r
3 . R ear defle cto r
R EM OVA L SER VIC E PO IN T
A A"
REA R DEFLE C TO R CO VER REM OVA L
1 . In se rt th e sp ecia l to ol in to th e slit on th e re ar defle cto r
c o ve r.
2 . Rele ase th e ta b by pry in g it to w ard s th e fr o to fth e ve hic le . S
lit
w
ww.W ork sh opM an uals .c o .u k
P urc h ased f r o m w ww.W ork sh opM an uals .c o .u k
Page 1429 of 1839
Page 1430 of 1839
EXTERIOR -Side Step/Winshield Wiper and Washer51-23
REMOVAL SERVICE POINT
A
A"
SIDE STEP COVER, NON-SLIP COVER REMOVAL
Remove by the same procedure as for REAR MUDGUARD
REINFORCEMENT, REAR BUMPER SIDE RETAINER, REAR
BUMPER CORNER BRACKET REMOVAL. (Refer to P.51-9.)
INSTALLATION SERVICE POINT
"
AA
SIDE STEP COVER, NON-SLIP COVER
INSTALLATION
Install by the same procedure as for REAR MUDGUARD
REINFORCEMENT, REAR BUMPER SIDE RETAINER, REAR
BUMPER CORNER BRACKET INSTALLATION. (Refer to
P.51-10.)
WINDSHIELD WIPER AND WASHER
SERVICE SPECIFICATIONS
ItemsStandard value
Park position of the windshield wiper arm and blade assemblyDriver’s side20 - 30
(Distance from end of wiper blade to end of front deck garnish)
mmPassenger’s side25 - 35
TROUBLESHOOTING
The windshield wiper and washer is controlled by the SWS (Smart Wiring System). For troubleshooting
procedures, refer to GROUP 54B - SWS Diagnosis.
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk
Page 1431 of 1839
W
IN DSH IE LD WIP ER AND WASH ER
R EM OVA L AND IN STA LLA TIO N S
ectio n A –A S
ectio n B –B
V
ie w A
N O TE
: in dic a te s th e clip posit io ns.
: in dic a te s th e ta b posit io ns.
3
4C
C
C
C 1
3.0
± 3
.0 N
×m 4
.9
± 1
.0 N
×m 8
.9
± 1
.9 N
×m 4
.9
± 0
.7 N
×m 4
.9
± 0
.7 N
×m A
1 1
1 2
Page 1432 of 1839
L
in k
a sse m bly P
asse nger’s
s id e (B ) D
riv e r’s sid e (A ) F
ro nt deck garn is h end H
ig h sp eed (
B )A uto m atic sto p
w
ww.W ork sh opM an uals .c o .u k
