Page 1665 of 2771

NISSAN LATIO 2008 Service Repair Manual EI-42 < ON-VEHICLE REPAIR > REAR PARCEL SHELF FINISHER REAR PARCEL SHELF FINISHER Removal and InstallationINFOID:0000000001704237 REMOVAL 1. Remove rear seat. Refer to SE-15, "Removal and Installa

Page 1666 of 2771

NISSAN LATIO 2008 Service Repair Manual FLOOR TRIM EI-43 < ON-VEHICLE REPAIR > C D E F G H J K L MA B EI N O P FLOOR TRIM Removal and InstallationINFOID:0000000001704238 REMOVAL 1. Disconnect both the negative and positive battery cables, t

Page 1667 of 2771

NISSAN LATIO 2008 Service Repair Manual EI-44 < ON-VEHICLE REPAIR > FLOOR TRIM 6. Disconnect floor harness connector. 7. Remove diagnosis sensor unit. Refer to SRS-44 . 8. Remove key interlock cable. Refer to AT-213 . 9. Remove floor carpet

Page 1668 of 2771

NISSAN LATIO 2008 Service Repair Manual HEADLINING EI-45 < ON-VEHICLE REPAIR > C D E F G H J K L MA B EI N O P HEADLINING ComponentINFOID:0000000001704239 Hatchback Models LIIA2576E 1. Headlining 2. Assist grip 3. Sunvisor 4. Cap 5. Sunviso

Page 1669 of 2771

NISSAN LATIO 2008 Service Repair Manual EI-46 < ON-VEHICLE REPAIR > HEADLINING Sedan Models 7. Roof console/map lamp assembly (if equipped)8. Antenna feeder cable 9. Room lamp 10. Dual lock fastener 11. Room lamp harness 12. Insulator 13.

Page 1670 of 2771

NISSAN LATIO 2008 Service Repair Manual HEADLINING EI-47 < ON-VEHICLE REPAIR > C D E F G H J K L MA B EI N O P Removal and Installation - HatchbackINFOID:0000000001704240 REMOVAL 1. Remove the negative and positive battery cables. 2. Remove

Page 1671 of 2771

NISSAN LATIO 2008 Service Repair Manual EI-48 < ON-VEHICLE REPAIR > HEADLINING 12. Remove sunvisor holders RH/LH by rotating 45 degrees, then pulling outward. 13. Release the metal clips, then remove the roof console/map lamp assembly (if e

Page 1672 of 2771

NISSAN LATIO 2008 Service Repair Manual HEADLINING EI-49 < ON-VEHICLE REPAIR > C D E F G H J K L MA B EI N O P Avoid headlining damage when installing by inserting rear clips first during assembly. Removal and Installation - SedanINFOID:000
