Page 409 of 2771

NISSAN LATIO 2008 Service Repair Manual AV-50 < SERVICE INFORMATION > TELEPHONE OK or NG OK >> GO TO 2. NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG- 3. 2.CHECK POWER SUPPLY CIRCU

Page 410 of 2771

NISSAN LATIO 2008 Service Repair Manual TELEPHONE AV-51 < SERVICE INFORMATION > C D E F G H I J L MA B AV N O P 1. Press the SEND switch. 2. Check the indicator is blinking. OK or NG OK >> INSPECTION END NG >> Check steering wheel audio con

Page 411 of 2771

NISSAN LATIO 2008 Service Repair Manual AV-52 < SERVICE INFORMATION > TELEPHONE 3.CHECK BLUETOOTH CONTROL UNIT 1. Turn ignition switch ON. 2. Check voltage between Bluetooth control unit harness connec- tor B121 terminals 17, 18 and ground.

Page 412 of 2771

NISSAN LATIO 2008 Service Repair Manual TELEPHONE AV-53 < SERVICE INFORMATION > C D E F G H I J L MA B AV N O P 3. Check voltage between Bluetooth microphone connector R15 terminal 5 and ground. YES or NO YES >> GO TO 3. NO >> Replace Bluet

Page 413 of 2771

NISSAN LATIO 2008 Service Repair Manual AV-54 < SERVICE INFORMATION > TELEPHONE OK or NG OK >> GO TO 3. NG >> Repair harness or connector. 3.CHECK MUTE SIGNAL 1. Connect Bluetooth control unit connector and audio unit connector. 2. Turn ign

Page 414 of 2771

NISSAN LATIO 2008 Service Repair Manual TELEPHONE AV-55 < SERVICE INFORMATION > C D E F G H I J L MA B AV N O P Hatchback Sedan LKIA0762E 1. Bluetooth control unit bracket 2. Bluetooth control unit A. Blue tooth control unit bolts B. BLueto

Page 415 of 2771

NISSAN LATIO 2008 Service Repair Manual AV-56 < SERVICE INFORMATION > TELEPHONE Removal 1. For hatchback, remove luggage side lower finish (RH). Refer to EI-51, "Removal and Installation". • Disconnect Bluetooth antenna harness cl

Page 416 of 2771

NISSAN LATIO 2008 Service Repair Manual TELEPHONE AV-57 < SERVICE INFORMATION > C D E F G H I J L MA B AV N O P Sedan Removal 1. For hatchback, remove luggage side lower finisher (RH). Refer to EI-51, "Removal and Installation". 2.
