Page 2217 of 2771

NISSAN LATIO 2008 Service Repair Manual LT-80 < SERVICE INFORMATION > PARKING, LICENSE PLATE AND TAIL LAMPS 1. Start auto active test. Refer to PG-19, "Auto Active Test" . 2. Make sure parking, license plate and tail lamps operate.

Page 2218 of 2771

NISSAN LATIO 2008 Service Repair Manual PARKING, LICENSE PLATE AND TAIL LAMPS LT-81 < SERVICE INFORMATION > C D E F G H I J L MA B LT N O P OK or NG OK >> GO TO 7. NG >> GO TO 6. 6.CHECK PARKING, LICENSE PLATE AND TAIL LAMP CIRCUIT 1. Turn

Page 2219 of 2771

NISSAN LATIO 2008 Service Repair Manual LT-82 < SERVICE INFORMATION > PARKING, LICENSE PLATE AND TAIL LAMPS 1. Check continuity between front combination lamp harness con- nector and ground. 2. Check continuity between license plate lamp ha

Page 2220 of 2771

NISSAN LATIO 2008 Service Repair Manual PARKING, LICENSE PLATE AND TAIL LAMPS LT-83 < SERVICE INFORMATION > C D E F G H I J L MA B LT N O P 2. Remove the license plate lamp bulb socket (1) and remove the license plate lamp bulb (2). 3. Inst

Page 2221 of 2771

NISSAN LATIO 2008 Service Repair Manual LT-84 < SERVICE INFORMATION > PARKING, LICENSE PLATE AND TAIL LAMPS 2. Remove the license plate lamp assembly (1). Installation Installation is in the reverse order of removal. TAIL LAMP Refer to LT-8

Page 2222 of 2771

NISSAN LATIO 2008 Service Repair Manual REAR COMBINATION LAMP LT-85 < SERVICE INFORMATION > C D E F G H I J L MA B LT N O P REAR COMBINATION LAMP ComponentINFOID:0000000001704462 Hatchback Bulb ReplacementINFOID:0000000001704463 HATCHBACK 1

Page 2223 of 2771

NISSAN LATIO 2008 Service Repair Manual LT-86 < SERVICE INFORMATION > REAR COMBINATION LAMP Removal and Installation INFOID:0000000001704464 HATCHBACK Removal 1. Remove rear combination lamp nuts. 2. Pull the rear combination lamp toward re

Page 2224 of 2771

NISSAN LATIO 2008 Service Repair Manual INTERIOR LAMP LT-87 < SERVICE INFORMATION > C D E F G H I J L MA B LT N O P INTERIOR LAMP Map LampINFOID:0000000001704466 BULB REPLACEMENT 1. Remove the map lamp lens (1). 2. Remove the bulb from lamp
