LAN-82
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 5)]
MAIN LINE BETWEEN DLC AND TCM CIRCUIT
COMPONENT DIAGNOSIS
MAIN LINE BETWEEN DLC AND TCM CIRCUIT
Diagnosis ProcedureINFOID:0000000001711423
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side
and harness side).
- Harness connector M69
- Harness connector E7
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTINUITY (OPEN CIRCUIT)
1. Disconnect the harness connectors M69 and E7.
2. Check the continuity between the data link connector and the harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the data link connector and the harness connector M69.
3.CHECK HARNESS CONTINUITY (OPEN CIRCUIT)
1. Disconnect the connector of TCM.
2. Check the continuity between the harness connector and the TCM.
Is the inspection result normal?
YES (Present error)>>Check CAN system type decision again.
YES (Past error)>>Error was detected in the main line between the data link connector and the TCM.
NO >> Repair the main line between the harness connector E7 and the TCM.
Data link connector Harness connector
Continuity
Connector No. Terminal No. Connector No. Terminal No.
M226
M6932A Existed
14 31A Existed
Harness connector TCM harness connector
Continuity
Connector No. Terminal No. Connector No. Terminal No.
E732A
E315 Existed
31A 6 Existed
