Page 1809 of 2771

NISSAN LATIO 2008 Service Repair Manual FRONT DRIVE SHAFT FAX-13 < SERVICE INFORMATION > C E F G H I J K L MA B FA X N O P 6. Remove snap ring using a suitable tool, then remove spider assembly from shaft. 7. Remove boot from shaft. 8. Clea

Page 1810 of 2771

NISSAN LATIO 2008 Service Repair Manual FAX-14 < SERVICE INFORMATION > FRONT DRIVE SHAFT 1. Install new boot and new small boot band on shaft. CAUTION: • Do not reuse boot or boot band. • Cover drive shaft serration with tape to prevent

Page 1811 of 2771

NISSAN LATIO 2008 Service Repair Manual FRONT DRIVE SHAFT FAX-15 < SERVICE INFORMATION > C E F G H I J K L MA B FA X N O P 2. Pull and tighten the boot band using suitable tool until both pawls of boot band are secured in the boot band groo

Page 1812 of 2771

NISSAN LATIO 2008 Service Repair Manual FAX-16 < SERVICE INFORMATION > FRONT DRIVE SHAFT 4. Attach new circlip to shaft. Thread nut onto end of joint sub- assembly and press fit using suitable tool. CAUTION: • Do not reuse circlip. • Ci

Page 1813 of 2771

NISSAN LATIO 2008 Service Repair Manual FRONT DRIVE SHAFT FAX-17 < SERVICE INFORMATION > C E F G H I J K L MA B FA X N O P Damper 1. Secure damper with new damper bands. CAUTION: Do not reuse damper bands. Disassembly and Assembly (Right Si

Page 1814 of 2771

NISSAN LATIO 2008 Service Repair Manual FAX-18 < SERVICE INFORMATION > FRONT DRIVE SHAFT 4. Put matching marks on spider assembly and shaft. 5. Remove snap ring using a suitable tool, then remove spider assembly from shaft. 6. Remove boot f

Page 1815 of 2771

NISSAN LATIO 2008 Service Repair Manual FRONT DRIVE SHAFT FAX-19 < SERVICE INFORMATION > C E F G H I J K L MA B FA X N O P 2. Remove dust shield, then remove snap ring using a suitable tool. 3. Press support bearing assembly off slide joint

Page 1816 of 2771

NISSAN LATIO 2008 Service Repair Manual FAX-20 < SERVICE INFORMATION > FRONT DRIVE SHAFT 1. Install new boot and new small boot band on shaft. CAUTION: • Do not reuse boot or boot band. • Cover drive shaft serration with tape to prevent
