Page 697 of 2771

NISSAN LATIO 2008 Service Repair Manual BODY REPAIR BL-263 < SERVICE INFORMATION > C D E F G H J K L MA B BL N O P Exterior, Hatchback LIIA2587E

Page 698 of 2771

NISSAN LATIO 2008 Service Repair Manual BL-264 < SERVICE INFORMATION > BODY REPAIR Exterior, Sedan LIIA2889E

Page 699 of 2771

NISSAN LATIO 2008 Service Repair Manual BODY REPAIR BL-265 < SERVICE INFORMATION > C D E F G H J K L MA B BL N O P Interior Precaution in Repairing High Strength SteelINFOID:0000000001704125 High strength steel is used for body panels in or

Page 700 of 2771

NISSAN LATIO 2008 Service Repair Manual BL-266 < SERVICE INFORMATION > BODY REPAIR • The repair of reinforcements (such as side members) by heat- ing is not recommended since it may weaken the component. When heating is unavoidable, do no

Page 701 of 2771

NISSAN LATIO 2008 Service Repair Manual BODY REPAIR BL-267 < SERVICE INFORMATION > C D E F G H J K L MA B BL N O P • The spot weld on HSS panels is harder than that of an ordi- nary steel panel. Therefore, when cutting spot welds on a HSS

Page 702 of 2771

NISSAN LATIO 2008 Service Repair Manual BL-268 < SERVICE INFORMATION > BODY REPAIR • Peel off old bonding material on the surface of outer wheelhouse and clean thoroughly. • Peel off a primer coat in the specified area where new adhesiv

Page 703 of 2771

NISSAN LATIO 2008 Service Repair Manual BODY REPAIR BL-269 < SERVICE INFORMATION > C D E F G H J K L MA B BL N O P - Remove foam material remaining on vehicle side. - Clean area in which foam was removed. - Install service part. - Insert no

Page 704 of 2771

NISSAN LATIO 2008 Service Repair Manual BL-270 < SERVICE INFORMATION > BODY REPAIR Sedan 1. Body side outer 2. Front pillar lower reinforcement 3. Body side insulation (foam) front pil- lar 4. Roof panel assembly 5. Body side insulation (Fo
