- DIAGNOSTICSENGINE (2JZ-GTE)
398 Author: Date:
1997 SUPRA (RM502U)
CIRCUIT INSPECTION
DTC P0100 Mass Air Flow Circuit Malfunction
CIRCUIT DESCRIPTION
The mass air flow meter uses a platinum hot wire. The hot wire air flow meter consists of a platinum hot wire,
thermistor and a control circuit installed in a plastic housing. The hot wire air flow meter works on the principle
that the hot wire and thermistor located in the intake air bypass of the housing detect any changes in the
intake air temperature.
The hot wire is maintained at the set temperature by controlling the current flow through the hot wire. This
current flow is then measured as the output voltage of the air flow meter.
The circuit is constructed so that the platinum hot wire and thermistor provide a bridge circuit, with the power
transistor controlled so that the potential of ºAº and ºBº remains equal to maintain the set temperature.
DTC No.DTC Detecting ConditionTrouble Area
Open or short in mass air flow meter circuit with engine speed
4,000 rpm or less
Open or short in mass air flow meter circuit
P0100Open or short in mass air flow meter circuit with engine speed
4,000 rpm or more
(2 trip detection logic)
Oen or short in mass air flow meter circuit
Mass air flow meter
ECM
If the ECM detects DTC ºP0100º it operates the fail safe function, keeping the ignition timing and injection
volume constant and making it possible to drive the vehicle.
HINT:
After confirming DTC P0100 use the OBD II scan tool or TOYOTA hand-held tester to confirm the mass air
flow ration from ºCURRENT DATAº.
Mass Air Flow Value (gm / sec.)Malfunction
0.0Mass Air flow meter power source open
VG circuit open or short
359.0 or moreVG - circuit open
Page 586 of 1807
FI6930
B-W
R/B No.22
2A
EFI No.1 B
BatteryEFI Main RelayB-R R/B No.2
B-Y
W-B
EBEA2
2
22
2 23
5
1
EA1
8
5
1
Mass Air Flow Meter2
5Y-R
B-RA
B
B 66
28
E2G
E1 VG GR24
M-RELB+ ECM
1
- DIAGNOSTICSENGINE (2JZ-GTE)
DI-171
399 Author: Date:
1997 SUPRA (RM502U)
WIRING DIAGRAM
INSPECTION PROCEDURE
1 Connect the OBD II scan tool or TOYOTA hand-held tester, and read value of
mass air flow rate.
RESULT:
(a) Connect the OBD II scan tool or TOYOTA hand-held tester to the DLC3.
(b) Turn ignition switch ON and push the OBD II scan tool or TOYOTA hand-held tester main switch ON.
(c) Start the engine.
CHECK:
Read mass air flow rate on the OBD II scan tool or TOYOTA hand-held tester.
RESULT:
Type IType II
Mass air flow rate0.0 gm / sec.359.0 gm / sec. or more
Type I Go to step 2.
Type II Go to step 5.
Page 587 of 1807
BE6653
P24310A00099
ON
1(+)
A00689
STARTCheck Harness A
ECM
B66 VG(+)
DI-172
- DIAGNOSTICSENGINE (2JZ-GTE)
400 Author: Date:
1997 SUPRA (RM502U)
2 Check voltage of mass air flow meter power source.
PREPARATION:
(a) Disconnect the mass air flow meter connector.
(b) Turn ignition switch ON.
CHECK:
Measure voltage between terminal 1 of mass air flow meter con-
nector and body ground.
OK:
Voltage: 9 - 14 V
NG Check for open in harness and connector be-
tween EFI main relay (Marking: EFI MAIN) and
mass air flow meter (See page IN-28).
OK
3 Check voltage between terminal VG of ECM and body ground.
PREPARATION:
(a) Connect Check Harness A (See page DI-164).
(b) Start the engine.
CHECK:
Measure voltage between terminal VG of ECM and body
ground while engine is idling, transmission is in park or neutral
position and A/C switch is OFF.
OK:
Voltage: 1.1 - 1.5 V
OK Check and replace ECM (See page IN-28).
NG
Page 588 of 1807
S00344
Check Harness A
ECM
B28 E2G
- DIAGNOSTICSENGINE (2JZ-GTE)
DI-173
401 Author: Date:
1997 SUPRA (RM502U)
4 Check for open and short in harness and connector between mass air flow meter
and ECM (See page IN-28).
NG Repair or replace harness or connector.
OK
Replace mass air flow meter.
5 Check continuity between terminal E2G of ECM and body ground.
PREPARATION:
Connect Check Harness A (See page DI-164).
CHECK:
Check continuity between terminal E2G of ECM and body
ground.
OK:
Continuity (1 W or less)
NG Check and replace ECM (See page IN-28).
OK
6 Check for open in harness and connector between mass air flow meter and ECM
(See page IN-28).
NG Repair or replace harness or connector.
OK
Replace mass air flow meter.
Page 589 of 1807
DI-174
- DIAGNOSTICSENGINE (2JZ-GTE)
402 Author: Date:
1997 SUPRA (RM502U)
DTC P0101 Mass Air Flow Circuit Range / Performance
Problem
CIRCUIT DESCRIPTION
Refer to ºMass Air Flow Circuit Malfunctionº on page DI-170.
DTC No.DTC Detecting ConditionTrouble Area
P0101
Conditions (a), (b) and (c) continue with engine speed 900
rpm or less:
(2 trip detection logic)
(a) Closed throttle position switch: ON
(b) Mass air flow meter output > 2.2 V
(c) Engien coolant temp. 70°C
Mass air flow meterP0101
Conditions (a) and (b) continue with engine speed 1,500 rpm or
more:
(2 trip detection logic)
(a) Mass air flow meter output < 1.0 V
(b) VTA 0.72 V
Mass air flow meter
WIRING DIAGRAM
Refer to page DI-170 or the WARNING DIAGRAM.
INSPECTION PROCEDURE
1 Are there any other codes (besides DTC P0101) being output?
YES Go to relevant DTC chart.
NO
Replace mass air flow meter.
DI4SN-01
Page 590 of 1807

FI4741
Acceptable
Resistance kW
-20 0
20 40 60 80 100
(-4) (32) (68)(104)(140)(176)(212)
Temperature °C (°F) 0.1 0.20.3 0.51 2 35 10 2030
- DIAGNOSTICSENGINE (2JZ-GTE)
DI-175
403 Author: Date:
1997 SUPRA (RM502U)
DTC P0110 Intake Air Temp. Circuit Malfunction
CIRCUIT DESCRIPTION
The intake air temperature sensor is built into the air flow meter
and senses the intake air temperature.
A thermistor built in the sensor changes the resistance value
according to the intake air temperature.
The lower the intake air temperature, the greater the thermistor
resistance value, and the higher the intake air temperature, the
lower the thermistor resistance value (See Fig. 1).
The intake air temperature sensor is connected to the ECM.
The 5 V power source voltage in the ECM is applied to the in-
take air temperature sensor from the terminal THA via a resistor
R.
That is , the resistor R and the intake air temperature sensor are
connected in series. When the resistance value of the intake air
temperature sensor changes in accordance with changes in the
intake air temperature, the potential at terminal THA also
changes. Based on this signal, the ECM increases the fuel in-
jection volume to improve driveability during cold engine opera-
tion.
If the ECM detects the DTC ºP0110º, it operates the fail safe
function in which the intake air temperature is assumed to be
20°C (68°F).
Intake Air Temp. °C (°F)Resistance (kW)Voltage (V)
-20 (-4)16.24.3
0 (32)5.93.4
20 (68)2.52.4
40 (104)1.11.4
60 (140)0.60.9
80 (176)0.30.5
100 (212)0.10.2
DTC No.DTC Detecting ConditionTrouble Area
P0110Open or short in intake air temp. sensor circuit
Open or short in intake air temp. sensor circuit
Intake air temp. sensor
ECM
HINT:
After confirming DTC P0110 use the OBD II scan tool or TOYOTA hand-held tester to confirm the intake
air temperature from ºCURRENT DATAº.
Temperature DisplayedMalfunction
- 40°C (- 40°F)Open circuit
140°C (284°F) or moreShort circuit
DI4SO-01
Page 591 of 1807

FI6448
Intake Air Temp. Sensor
(Inside the mass air flow meter)
3
4P-L
W-B45
65B
BECM
5V
THAR
E2
E2
DI-176
- DIAGNOSTICSENGINE (2JZ-GTE)
404 Author: Date:
1997 SUPRA (RM502U)
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
If DTC ºP0110º (Intake Air Temp. Circuit Malfunction), ºP0115º (Engine Coolant Temp. Circuit Malfunc-
tion), ºP0120º (Throttle/Pedal Position Sensor/Switch ºAº Circuit Malfunction), are output simulta-
neously, E2 (sensor ground) may be open.
1 Connect the OBD II scan tool or TOYOTA hand-held tester, and read value of in-
take air temperature.
PREPARATION:
(a) Connect the OBD II scan tool or TOYOTA hand-held tester to the DLC3.
(b) Turn ignition switch ON and push the OBD II scan tool or TOYOTA hand-held tester main switch ON.
CHECK:
Read temperature value on the OBD II scan tool or TOYOTA hand-held tester.
OK:
Same as actual intake air temperature.
HINT:
If there is open circuit, OBD II scan tool or TOYOTA hand-held tester indicates - 40°C (- 40°F).
If there is short circuit, OBD II scan tool or TOYOTA hand-held tester indicates 140°C (284°F) or more.
NG - 40 °C (- 40 °F) ............. Go to step 2.
140 °C (284 °F) or more .. Go to step 4.
OK
Check for intermittent problems.
(See page DI-147)
Page 592 of 1807

BE6653
A00347
A00348
ON
Intake Air
Temp. Sensor
3
4ECM
5V
THA
E2 B
B 45
65
A00690
ON
Intake Air
Temp. Sensor3
445
65
B
B
ECM
5V
THA
E2
Check Harnss A
B45, 65
THA
E2
ECM
- DIAGNOSTICSENGINE (2JZ-GTE)
DI-177
405 Author: Date:
1997 SUPRA (RM502U)
2 Check for open in harness or ECM.
PREPARATION:
(a) Disconnect the mass air flow meter connector.
(b) Connect sensor wire harness terminals together.
(c) Turn ignition switch ON.
CHECK:
Read temperature value on the OBD II scan tool or TOYOTA
hand-held tester.
OK:
Temperature value: 140°C (284°F) or more
OK Confirm good connection at sensor.
If OK, replace mass air flow meter.
NG
3 Check for open in harness or ECM.
PREPARATION:
(a) Connect Check Harness A (See page DI-164).
(b) Connect between terminals THA and E2 of ECM connec-
tor.
HINT:
Mass air flow meter connector is disconnected. Before check-
ing, do a visual and contact pressure check for the ECM con-
nector (See page IN-28).
(c) Turn ignition switch ON.
CHECK:
Read temperature value on the OBD II scan tool or TOYOTA
hand-held tester.
OK:
Temperature value: 140°C (284°F) or more
OK Open in harness between terminals E2 or THA,
repair or replace harness.
NG
Confirm good connection at ECM.
If OK, replace ECM.
