REAR FLOOR PAN (ASSY)
REMOVAL (With the body lower back panel removed.)
BODY PANEL REPLACEMENTRE-54
Page 474 of 1807
INSTALLATION
BODY PANEL REPLACEMENTRE-55
Page 475 of 1807
NO8909
NO8909mm (in.) Imaginary
Standard
Line
(Three-Dimensional Distance)
Symbol Name Hole dia. Symbol Name Hole dia.
A, a Strut rod installation hole-inner14.2
(0. 559)F, f No. 2 lower arm installation hole-front26y14.2
(1.02y0.559)
B, b Differential carrier installation nut12 (0.47)
nutG, g Rear suspension member standard hole 20 (0.79)
C, c Rear suspension member standard hole 20 (0.79) H, h Upper arm installation hole-rear14.2
(0.559)
D, d No. 1 lower arm installation hole-front26x 14.2
(1.02y0.559)I, i No. 2 lower arm installation hole-rear26y14.2
(1.02y0.559)
E, eUpper arm installation hole-front14.2
(0.559)
REAR SUSPENSION CROSSMEMBER
BODY DIMENSIONSDI-12
Page 476 of 1807
mm (in.)NO8909
NO8909
Imaginary
Standard
Line
(Two-Dimensional Distance)
Symbol Name Hole dia. Symbol Name Hole dia.
A, a Strut rod installation hole-inner14.2
(0.559)F, f No. 2 lower arm installation hole-front26y14.2
(1.02y0.559)
B, b Differential carrier installation nut12 (0.47)
nutG, g Rear suspension member standard hole20 (0.79)
C, c Rear suspension member standard hole 20 (0.79) H, h Upper arm installation hole-rear14.2
(0.559)
D, d No. 1 lower arm installation hole-front26y14.2
(1.02y0.559)I, i No. 2 lower arm installation hole-rear26y14.2
(1.02y0.559)
E, e Upper arm installation hole-front14.2
(0.559)
REAR SUSPENSION CROSSMEMBER (Cont'd)
BODY DIMENSIONSDI-13
Page 477 of 1807
ROCKER OUTER PANEL (CUT)
REMOVAL
Cut and Join Location
(Cut Location for Supply Parts)Cut and Join Location
(Cut Location for Supply Parts)
Normal Roof:
Sport Roof:
(Cut and Join Location) (Cut and Join Location)Normal Roof
Normal Roof
Sport Roof
Sport Roof
1. Cut and join the parts at the location as shown
above.
HINT:
1) Be careful to cut so the rocker panel reinforce-
ment is not damaged.
BODY PANEL REPLACEMENTRE-32
Page 478 of 1807
INSTALLATION
Butt Weld Butt Weld
Normal Roof:
Sport Roof:
1. Temporarily install the new parts and check
the fit of the front door.
BODY PANEL REPLACEMENTRE-33
Page 479 of 1807
ROOF PANEL (ASSY): Sport Roof
REMOVAL
Braze
(both sides)
Braze
(both sides)
1. Heat the brazed area of the front body pillar
and quarter panel and scrape off the brazing
with a wire brush.
HINT: Be careful not to overheat the pillar sides.
BODY PANEL REPLACEMENTRE-64
Page 480 of 1807
2. Braze the front body pillar and quarter panel
connection.
HINT: Before performing these operations, place
a wet rag on the roof panel to protect it from
damage.
INSTALLATION
Body Sealer
Braze
(both sides)
Braze
(both sides)
1. Before temporarily installing the new parts,
apply body sealer to the windshield header
panel, roof panel reinforcement and back
door opening frame.
HINT:
1) Apply just enough sealer for the new parts to
make contact.
2) For other sealing points, refer to Section AR.
