Outside Handle
Door Lock CylinderDoor Glass
Belt Moulding
Outer Rear View Mirror
Door Hinge
Door Check Door Window Upper Stop
Door Lock
Door Hinge
Weatherstrip
Glass Guide
Service Hole Cover Inside Panel
Frame
Window Regulator
Armrest Bracket
Setting Nut
Window Guide
Lower PlateInside Handle
Plate
Trim BoardInside Handle
Speaker
Power Window Switch
(Passenger's) Inside Handle Bezel
Power Window Master Switch
Precoated part
7.4 (76, 67 in.´lbf)
11 (115, 8.3)
52 (530, 38)
25 (260, 19)
5.0 (51, 44 in.´lbf)
5.4 (55, 48 in.´lbf)7.4 (76, 67 in.´lbf)
N´m (kgf´cm, ft´lbf): Specified torque
- BODYFRONT DOOR
BO-7
2087 Author: Date:
1997 SUPRA (RM502U)
FRONT DOOR
COMPONENTS
Page 266 of 1807

BO0QD-01
N08444
Vehicle
Outside Inside
N08445
N19391
: 6 Clips
N08456
Snap Snap
Setting NutLower Plate BO-8
- BODYFRONT DOOR
2088 Author: Date:
1997 SUPRA (RM502U)
DISASSEMBLY
1. REMOVE INSIDE HANDLE BEZEL
Remove the screw, then pull the inside handle bezel.
2. REMOVE TRIM BOARD
3. REMOVE THESE PARTS:
(a) Power window master switch
(b) Speaker
(c) Inside handle
(d) Inside handle plate
(e) Armrest bracket
(f) Service hole cover
(g) Weatherstrip
(h) Inside panel frame
(i) Door glass
Torque: 7.4 N´m (76 kgf´cm, 67 in.´lbf)
4. REMOVE DOOR BELT MOULDING
(a) Remove the clip.
(b) Using a screwdriver, remove the door belt moulding as
shown in the illustration.
HINT:
Tape the screwdriver tip before use.
5. REMOVE WINDOW GUIDE LOWER PLATE
(a) Remove the bolt of the lower plate and connector.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(b) Unlock the snap by pulling the lower plate.
(c) Remove the snap and lower plate from the stud bolt of the
lower bracket.
(d) Remove the setting nut from the lower bracket.
Page 267 of 1807

N19389
N19532
0 - 1.0 mm
(0 - 0.04 mm)
N19388
- BODYFRONT DOOR
BO-9
2089 Author: Date:
1997 SUPRA (RM502U)
6. REMOVE WINDOW REGULATOR
(a) Disconnect the connector.
(b) Remove the bolt, 2 nuts and window regulator.
Torque: 7.4 N´m (76 kgf´cm, 67 in.´lbf)
HINT:
At the time of reassembly, please refer to the following item.
Apply MP grease to the glass guide and rollers of the window
regulator.
7. REMOVE DOOR LOCK
(a) Disconnect the connector and clamp.
(b) Disconnect the link from the outside handle.
HINT:
At the time of reassembly, please refer to the following item.
After connecting the link, check that the clearance is within the
specification as shown in the illustration.
(c) Remove the 3 screws.
Torque: 5.0 N´m (51 kgf´cm, 44 in.´lbf)
HINT:
At the time of reassembly, please refer to the following item.
Apply adhesive to the 3 screws.
Part No.08833-00070, THREE BOND 1324 or equiva-
lent.
(d) Remove the door lock through the service hole.
HINT:
At the time of reassembly, please refer to the following item.
Apply MP grease to the sliding and rotating parts of the door
lock.
8. REMOVE THESE PARTS:
(a) Outside handle
(b) Door lock cylinder
(c) Outer rear view mirror
Page 268 of 1807
BO0QE-01
N16816
SST
N16815
SST
N08443
N11799
BO-10
- BODYFRONT DOOR
2090 Author: Date:
1997 SUPRA (RM502U)
ADJUSTMENT
1. ADJUST DOOR IN FORWARD/REARWARD AND VER-
TICAL DIRECTIONS
Using SST, adjust the door by loosening the body side hinge
bolts.
SST 09812-00020
Torque: 52 N´m (530 kgf´cm, 38 ft´lbf)
2. ADJUST DOOR IN LEFT/RIGHT AND VERTICAL
DIRECTIONS
Using SST, adjust the door by loosening the door side hinge
bolts.
SST 09812-00010
HINT:
Substitute the standard bolt for the centering bolt.
(See page BO-6)
Torque: 25 N´m (260 kgf´cm, 19 ft´lbf)
3. ADJUST DOOR LOCK STRIKER
(a) Check that the door fit and door lock linkages are adjusted
correctly.
(b) Using a screwdriver, remove the striker cover.
(c) Using a torx wrench, loosen the striker mounting screws.
(d) Using a brass bar and hammer, tap the striker to adjust it.
CAUTION:
Do not tap the striker too hard.
Page 269 of 1807

Z13646
A-A (Normal Roof)
A-A (Sport Roof) 6.9 ± 2
(0.272 ± 0.08)
A
B A
B
7 ± 2
(0.276 ± 0.08) 6.9 ± 2
(0.272 ± 0.08) 7 ± 2
(0.276 ± 0.08)
mm (in.) B-B
4.1 (0.161)9.1 ± 1.5
(0.358 ± 0.06)
- BODYFRONT DOOR
BO-1 1
2091 Author: Date:
1997 SUPRA (RM502U)
4. CHECK FRONT DOOR GLASS
Check the following items. If the conditions are not met, readjust
the glass.
(1) When you close the door with the glass fully closed,
the A-A, B-B sections are in the same condition as
shown in the illustration below.
(2) When you push the glass firmly from inside, the
glass stops at the roof drip moulding and does not
move.
(3) When you close the door with the glass fully closed,
the glass is not caught in the outside lip of the
weatherstrip and does not touch to the roof drip
moulding.
(4) With the door closed, the glass moves smoothly.
(5) The upper edge of the glass cannot be seen from
outside of the vehicle (edge touching roof side rail
weatherstrip).
(6) While the glass is being raised, the glass and roof
side rail weatherstrip are parallel, and the front and
rear door window upper stops touch at the same
time.
Page 270 of 1807
N08480
Door Window
Upper StopDoor Window
Upper Stop
Carrier Plate
Guide Lower Bracket
Lower Plate
N08475
Setting NutSnap
Lower Plate
N08477
N08845
BO-12
- BODYFRONT DOOR
2092 Author: Date:
1997 SUPRA (RM502U)
5. ADJUST FRONT DOOR GLASS
Upper side of glass - in/out
(1) Remove the lower plate bolt.
(2) Pull the lower plate so that the snap is unlocked.
(3) Remove the snap and lower plate.
(4) Adjust the glass by turning the setting nut.
(5) Reinstall the lower plate, snap and bolt.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
Position (forward/rearward) the glass and attitude of
glass
Loosen the 3 bolts of the carrier plate and adjust.
Torque: 7.4 N´m (76 kgf´cm, 67 in.´lbf)
Position (vertical) the glass and attitude of glass
(when glass fully closed)
Adjust the door window upper stop.
Torque: 11 N´m (115 kgf´cm, 8.3 ft´lbf)
Page 271 of 1807
BO0QG-01
N19401
Back Door
Damper StayCenter Stop Light
Tonneau Cover Retractor
Back Door
Trim Board
Lock Striker
Lock Cylinder
Back Door Lock
Sport Roof:
Removable
Roof HolderHolder Garnish
Stay Support Cover
Removable Roof Stay
Lower Back Service Hole Cover Rear Seatback
Roof Side Inner Garnish
Front Seat
Outer Belt
Rear Seat Cushion
Tonneau Cover
Luggage Compartment Mat
Spare Wheel Cover
Deck Trim Rear Cover Deck Trim Side Board
Quarter Wheel House
Inner Cover
Rear Seat Outer Belt Speaker Grille Rear Quarter
Trim Board
Precoated part
7.8 (80, 69 in.´lbf)
13 (130, 9.4)
19 (195, 14)
5.9 (60, 52 in.´lbf)
N´m (kgf´cm, ft´lbf): Specified torque
43 (440, 32)
43 (440, 32)
BO-14
- BODYBACK DOOR
2094 Author: Date:
1997 SUPRA (RM502U)
BACK DOOR
COMPONENTS
Page 272 of 1807
BO0QH-01
N08890
- BODYBACK DOOR
BO-15
2095 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. REMOVE BACK DOOR TRIM BOARD
2. REMOVE LOCK STRIKER
Torque: 13 N´m (130 kgf´cm, 9.4 ft´lbf)
