Q08242
TOYOTA Hand-Held Tester
DLC3
P11446Fuel Inlet Hose
P12558
Fuel Inlet
Hose
SF0GH-01
Z13307
Fuel Inlet HoseSST
Gasket
SSTSST
Gasket(Union)
- SFI (2JZ-GTE)FUEL PUMP
SF-5
1331 Author: Date:
1997 SUPRA (RM502U)
FUEL PUMP
ON-VEHICLE INSPECTION
1. CHECK FUEL PUMP OPERATION
(a) Connect the TOYOTA hand-held tester to the DLC3.
(b) Turn the ignition switch ON and TOYOTA hand-held tes-
ter main switch ON.
NOTICE:
Do not start the engine.
(c) Select the ACTIVE TEST mode on the TOYOTA hand-
held tester.
(d) Please refer to the TOYOTA hand-held tester operator's
manual for further details.
(e) If you have no TOYOTA hand-held tester, connect the
positive (+) and negative (-) leads from the battery to the
fuel pump connector.
(See step 8)
(f) Check that there is pressure in the fuel inlet hose from the
fuel filter.
HINT:
If there is fuel pressure, you will hear the sound of fuel flowing.
If there is no pressure, check the following parts:
Fuses
EFI No.2 relay
Fuel pump
ECM
Wiring connections
(g) Turn the ignition switch to LOCK.
(h) Disconnect the TOYOTA hand- held tester from the
DLC3.
2. CHECK FUEL PRESSURE
(a) Check the battery voltage is above 12 V.
(b) Disconnect the negative (-) terminal cable from the bat-
tery.
(c) Remove the union bolt and 2 gaskets, disconnect the fuel
inlet hose from the fuel filter.
CAUTION:
Put a suitable container or shop towel under the fuel
filter.
Slowly loosen the union bolt.
(d) Install the fuel inlet hose and SST (pressure gauge) to the
fuel filter with the 3 gaskets and SST (union bolt).
SST 09268-45012
Torque: 29 N´m (300 kgf´cm, 22 ft´lbf)
(e) Wipe off any splattered gasoline.
Page 1466 of 1807

Q08242
TOYOTA Hand-Held Tester
DLC3
P12563
Disconnect
Plug SF-6
- SFI (2JZ-GTE)FUEL PUMP
1332 Author: Date:
1997 SUPRA (RM502U)
(f) Connect the TOYOTA hand-held tester to the DLC3.
(See step 1 in check fuel pump operation (a) to (e).)
(g) Reconnect the negative (-) terminal cable to the battery.
(h) Turn the ignition switch ON.
(i) Measure the fuel pressure.
Fuel pressure:
226 - 275 kPa (2.3 - 2.8 kgf/cm
2, 33 - 40 psi)
If pressure is high, replace the fuel pressure regulator.
If pressure is low, check the following parts:
(1) Fuel hoses and connections
(2) Fuel pump
(3) Fuel filter
(4) Fuel pressure regulator
(j) Remove the TOYOTA hand-held tester from the
DLC3.
(k) Start the engine.
(l) Disconnect the vacuum sensing hose from the fuel pres-
sure regulator, and plug the hose end.
(m) Measure the fuel pressure at idle.
Fuel pressure:
226 - 275 kPa (2.3 - 2.8 kgf/cm
2, 33 - 40 psi)
(n) Reconnect the vacuum sensing hose to the fuel pressure
regulator.
(o) Measure the fuel pressure at idle.
Fuel pressure:
167 - 216 kPa (1.7 - 2.2 kgf/cm
2, 24 - 31 psi)
If pressure is not as specified, check the vacuum sensing hose
and fuel pressure regulator.
(p) Stop the engine.
(q) Check that the fuel pressure remains as specified for 5
minutes after the engine has stopped.
Fuel pressure:
147 kPa (1.5 kgf/cm
2, 21 psi) or more
If pressure is not as specified, check the fuel pump, pressure
regulator and/or injectors.
(r) After checking fuel pressure, disconnect the negative (-)
terminal cable from the battery and carefully remove the
SST to prevent gasoline from splashing.
SST 09268-45012
(s) Reinstall the fuel inlet hose to the fuel filter with 2 new gas-
kets and the union bolt.
Torque: 29 N´m (300 kgf´cm, 22 ft´lbf)
(t) Reconnect the negative (-) terminal cable to the battery.
(u) Check for fuel leaks.
3. TAKE OUT FLOOR CARPET
4. REMOVE SPARE WHEEL COVER
5. REMOVE SPARE WHEEL
6. REMOVE SERVICE HOLE COVER
7. DISCONNECT FUEL PUMP & SENDER GAUGE CON-
NECTOR
Page 1467 of 1807

B01419
Ohmmeter4
5
B01429
4
5
Battery
- SFI (2JZ-GTE)FUEL PUMP
SF-7
1333 Author: Date:
1997 SUPRA (RM502U)
8. INSPECT FUEL PUMP RESISTANCE
Using an ohmmeter, measure the resistance between terminals
4 and 5.
Resistance: 0.1 - 3.0 W at 20°C (68°F)
If the resistance is not as specified, replace the fuel pump, lead
wire or fuel pump bracket.
9. INSPECT FUEL PUMP OPERATION
Connect a tester lead from terminal 4 of the connector to the
positive (+) terminal of the battery; connect another tester lead
from terminal 5 of the connector to the negative (-) terminal of
the battery.
NOTICE:
These tests must be performed quickly (within 10 se-
conds) to prevent the coil from burning out.
Keep the fuel pump as far away from the battery as
possible.
Always connect or disconnect at the battery.
If operation is not as specified, replace the fuel pump, lead wire
or fuel pump bracket.
10. RECONNECT FUEL PUMP & SENDER GAUGE CON-
NECTOR
11. INSTALL SERVICE HOLE COVER
12. INSTALL SPARE WHEEL
13. INSTALL SPARE WHEEL COVER
14. INSTALL FLOOR CARPET
Page 1468 of 1807
SF0GI-01
Z13599
Spare Wheel Cover
Spare Wheel Carrier
Spare Wheel
Service Hole Cover
Floor CarpetConnector
for Fuel Pump
and Sender Gauge
Gasket
Fuel Outlet
HoseFuel Return
Hose
GasketRetainer
Clamp
GasketFuel
Breather
Hose
Fuel Pump and
Sender Gauge
Assembly
Non-reusable partFuel Pump
Retainer
x 6 SF-8
- SFI (2JZ-GTE)FUEL PUMP
1334 Author: Date:
1997 SUPRA (RM502U)
COMPONENTS
Page 1469 of 1807
P18050
Fuel Pump FilterFuel Sender Gauge Fuel Hose Lead Wire
for Fuel Pump
Fuel Pump
Rubber CushionClip
Fuel Pump Bracket
Non-reusable part
- SFI (2JZ-GTE)FUEL PUMP
SF-9
1335 Author: Date:
1997 SUPRA (RM502U)
Page 1470 of 1807
SF19Z-01
P11357
(1) (2)
(3) (4)
P11280
SST
Rib
P12033
Fuel Return
Hose SF-10
- SFI (2JZ-GTE)FUEL PUMP
1336 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
CAUTION:
Do not smoke or work near an open flame when working on
the fuel pump.
1. TAKE OUT FLOOR CARPET
2. REMOVE SPARE WHEEL COVER
3. REMOVE SPARE WHEEL
4. REMOVE SERVICE HOLE COVER
5. REMOVE FUEL PUMP AND SENDER GAUGE
ASSEMBLY
(a) Disconnect the connector and hoses from the fuel pump
bracket:
(1) Fuel pump connector
(2) Fuel outlet hose
Remove the union bolt and 2 gaskets, and discon-
nect the outlet hose.
(3) Fuel return hose
(4) Fuel breather hose
(b) Remove the retainer clamp.
(c) Using SST, loosen the retainer.
SST 09808-14010
(d) Remove the retainer, and disconnect the fuel pump and
sender gauge assembly from the fuel tank.
(e) Disconnect the fuel return hose from the return port of the
fuel pump bracket.
(f) Remove the fuel pump, sender gauge assembly and gas-
ket.
Page 1471 of 1807
P11481
SF0GK-01
P11970
P11482Pull
P11971
Clip
- SFI (2JZ-GTE)FUEL PUMP
SF-1 1
1337 Author: Date:
1997 SUPRA (RM502U)
DISASSEMBLY
1. REMOVE FUEL SENDER GAUGE FROM FUEL PUMP
BRACKET
(a) Disconnect the connector from the fuel pump bracket.
(b) Remove the 2 screws and sender gauge.
2. REMOVE FUEL PUMP FROM PUMP BRACKET
(a) Remove the lead wire.
(b) Pull out the lower side of the fuel pump from the pump
bracket.
(c) Remove the rubber cushion from the fuel pump.
(d) Disconnect the fuel hose from the fuel pump, and remove
the fuel pump.
3. REMOVE FUEL PUMP FILTER FROM FUEL PUMP
(a) Using a small screwdriver, remove the clip.
HINT:
At the time of installation,please refer to the following items.
Use a new clip.
(b) Pull out the pump filter.
Page 1472 of 1807
SF0GM-01
P12033
Fuel Return
Hose
P13168
Z09524
SST
Rib
Area
P11279
- SFI (2JZ-GTE)FUEL PUMP
SF-13
1339 Author: Date:
1997 SUPRA (RM502U)
INSTALLATION
1. INSTALL FUEL PUMP AND SENDER GAUGE
ASSEMBLY
(a) Install a new gasket to the fuel tank.
(b) Insert fuel pump and sender gauge assembly into the fuel
tank.
(c) Connect the fuel return hose to the return port of the fuel
pump bracket.
(d) Align the arrow marks of the fuel pump bracket and fuel
tank.
(e) Temporarily install the retainer.
(f) Using SST, tighten the retainer until the arrow mark on the
retainer is within the lines on the fuel tank.
SST 09808-14010
(g) Check that the arrow marks of the fuel pump bracket and
fuel tank are aligned.
(h) Install the retainer clamp.
(i) Connect the connector and hoses to the fuel pump brack-
et:
Fuel pump connector
Fuel outlet hose
Connect the outlet hose with 2 new gaskets and the
union bolt.
Torque: 29 N´m (300 kgf´cm, 22 ft´lbf)
