Page 257 of 1807
BE1L5-01
1 CLOCK WILL NOT OPERATE
I02074
Is there battery positive voltage between terminal
+B and body ground?
Is there continuity between terminal GND and body
ground?Open or short circuit in wire harness between
terminal +B and DOME fuse.
Open circuit in wire harness between terminal
GND and body ground. Ye s
Ye sNo
No
Replace clock assembly.
- BODY ELECTRICALCLOCK
BE-101
2079 Author: Date:
1997 SUPRA (RM502U)
CLOCK
TROUBLESHOOTING
HINT:
Troubleshoot the clock according to the table below.
ProblemNo.
Clock will not operate1
Clock loses or gains time2
± 1.5 seconds / day
1. PROBLEM No.1
(a) Check that the battery positive voltage is 10 - 16 V.
If voltage is not as specified, replace the battery.
(b) Check that the DOME fuse is not blown.
If the fuse is blown, replace the fuse and check for short.
(c) Troubleshoot the clock as follows.
HINT:
Inspect the connector on the wire harness side.
Page 258 of 1807
2 CLOCK LOSES OR GAINS TIME
I02074
Is there 10 - 16 V between terminal +B and body
ground?Locate cause and repair, or recharge battery.
Ye sBellow 10 V
Adjust or replace clock assembly. BE-102
- BODY ELECTRICALCLOCK
2080 Author: Date:
1997 SUPRA (RM502U)
2. PROBLEM No.2
(a) Check that the battery positive voltage is 10 - 16 V.
If voltage is not as specified, replace the battery.
(b) Inspect the error of the clock.
Allowable error (per day): ± 2.0 seconds
If the error exceeds the allowable error, replace the clock as-
sembly.
(c) Check if the clock adjusting button is sticking in position
and has failed to return.
If the button has not returned, repair or replace the clock assem-
bly.
(d) Troubleshoot the clock as follows.
HINT:
Inspect the connector on the wire harness side.
Page 259 of 1807
BO0Q7-01
V00005
Shape (Example)
Removal/ Installation
Screwdriver
Scraper Clip RemoverPliers
- BODYCLIP
BO-1
2081 Author: Date:
1997 SUPRA (RM502U)
CLIP
REPLACEMENT
The removal and installation methods of typical clips used in body parts are shown in the table below.
HINT:
If the clip is damaged during the operation, always replace it with a new clip.
Page 260 of 1807
V00012
Shape (Example)
Removal/ Installation
Installation Removal
Removal Installation BO-2
- BODYCLIP
2082 Author: Date:
1997 SUPRA (RM502U)
Page 261 of 1807
BO0Q8-01
- BODYSRS AIRBAG
BO-3
2083 Author: Date:
1997 SUPRA (RM502U)
SRS AIRBAG
PRECAUTION
The TOYOTA SUPRA is equipped with an SRS (Supplemental Restraint System) such as the driver
airbag and front passenger airbag. Failure to carry out service operation in the correct sequence
could cause the SRS to unexpectedly deploy during servicing, possibly leading to a serious acci-
dent. Before servicing (including removal or installation of parts, inspection or replacement), be sure
to read the precautionary notices in the RS section.
Page 262 of 1807
BO0Q9-01
N19400
Front Fender Liner RH
Front Fender
Splash Shield RHEngine Upper Cover No.2
X12Front Fender liner LH
X12
Front Fender
Splash Shield LH Air Cleaner Cap X16
X6
Reinforcement
Hood to Front End
Panel Seal
Upper Center Retainer
Energy AbsorberHeadlightX6
Emblem
Lower Center Retainer
Side Marker
Light
Front Spoiler
Side Retainer RH Lower Radiator GrilleLower Center
No.2 Retainer
Side Marker Light
Front Spoiler
Retainer Upper No.3
Front License Plate
Mounting Bracket
Front Turn Signal and Parking LightFront Spoiler
Retainer Upper
RH
Front Spoiler
Retainer Lower No.1Front Spoiler
Side Retainer LH
Front Spoiler Cover
Front Spoiler
Retainer Upper LH
5.9 (60, 52 in.´lbf)
5.9 (60, 52 in.´lbf)N´m (kgf´cm, ft´lbf)
: Specified torque BO-4
- BODYFRONT BUMPER
2084 Author: Date:
1997 SUPRA (RM502U)
FRONT BUMPER
COMPONENTS
Page 263 of 1807
BO0QA-01
N11813
Spare Wheel Cover
Deck Trim Side Board RH
Quarter Wheel House
Inner Cover RH
Quarter Wheel House Inner
Cover LHSport Roof:
Stay Support CoverRemovable
Roof Stay
Lower Back Service
Hole Cover
Deck Trim Rear Cover
Deck Trim Rear Cover
Deck Trim Side Board LH
ReinforcementLicense Plate Light
Rear Combination Light
End Retainer RH
Rear Bumper Cover
End Retainer No.2
End Retainer LH Energy Absorber
42 (430, 31)
5.9 (60, 52 in.´lbf)
N´m (kgf´cm, ft´lbf) : Specified torque
- BODYREAR BUMPER
BO-5
2085 Author: Date:
1997 SUPRA (RM502U)
REAR BUMPER
COMPONENTS
Page 264 of 1807
N03433
Centering BoltStandard Bolt
BO0QB-01
N08530
N08531
N08532
BO-6
- BODYHOOD
2086 Author: Date:
1997 SUPRA (RM502U)
HOOD
ADJUSTMENT
HINT:
Since the centering bolt is used as the hood hinge and lock set
bolt, the hood and lock cannot be adjusted with it on. Substitute
the standard bolt for the centering bolt.
1. ADJUST HOOD IN FORWARD/REARWARD AND
LEFT/RIGHT DIRECTIONS
Adjust the hood by loosening the hood side hinge bolts.
Torque: 13 N´m (130 kgf´cm, 9.4 ft´lbf)
2. ADJUST FRONT EDGE OF HOOD IN VERTICAL
DIRECTIONS
Adjust the hood by turning the cushions.
3. ADJUST HOOD LOCK
Adjust the lock by loosening bolts.
Torque: 8.8 N´m (90 kgf´cm, 78 in.´lbf)
