Page 1489 of 1807
SF0GX-01
B02655
SST
- SFI (2JZ-GTE)FUEL PRESSURE PULSATION DAMPER
SF-31
1357 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. REMOVE STARTER
(See page ST-4)
2. REMOVE FUEL PRESSURE PULSATION DAMPER
(a) Using SST, remove the pulsation damper and upper gas-
ket.
SST 09612-24014 (09617-24011)
(b) Disconnect the fuel inlet pipe from the fuel pipe support,
and remove the lower gasket.
Page 1490 of 1807
SF0GY-02
B02656
New
Gasket
(Large)
New
Gasket
(Small)
B02657
Fulcrum
LengthSST SF-32
- SFI (2JZ-GTE)FUEL PRESSURE PULSATION DAMPER
1358 Author: Date:
1997 SUPRA (RM502U)
INSTALLATION
1. INSTALL FUEL PRESSURE PULSATION DAMPER
(a) Install the fuel inlet pipe and pulsation damper with 2 new
gaskets.
HINT:
Different sized gaskets are used for the upper (large size) and
lower (small size).
(b) Using SST, tighten the pulsation damper.
SST 09612-24014 (09617-24011)
Torque:
41 N´m (420 kgf´cm, 30 ft´lbf)
35 N´m (350 kgf´cm, 25 ft´lbf) for SST
HINT:
Use a torque wrench with a fulcrum length of 30 cm (11.81 in.).
2. INSTALL STARTER
(See page ST-15)
3. CHECK FOR FUEL LEAKS
(See page SF-1)
Page 1491 of 1807
SF0H0-02
P20903
No.2 Fuel Tank
Protector
Fuel Inlet
Pipe Shield
Fuel Tank CapFuel Pump
Retainer
Fuel Pump and
Gasket
Fuel Breather Pipe
Fuel Tank Band
Fuel Tank ProtectorFuel Tank EVAP Hose Retainer Clamp
Fuel Outlet Pipe
Fuel return
Hose
Fuel Return Hose Gasket
Gasket
Sender Gauge
Assembly
Non-reusable part SF-34
- SFI (2JZ-GTE)FUEL TANK AND LINE
1360 Author: Date:
1997 SUPRA (RM502U)
COMPONENTS
Page 1492 of 1807
SF0H1-01
BO0919
Crack
Leakage
FI1654
SSTUse SST
(310 kgf´cm, 22 ft´lbf)
Fulcrum Length
(11.81 in.)
SST : 09631 - 22020
30 N´m
30 cm
FU0041
Pipe2 - 7mm(0.08-0.28 in.)
Hose
Clip
0 -3mm(0 - 0.12 in.)
- SFI (2JZ-GTE)FUEL TANK AND LINE
SF-35
1361 Author: Date:
1997 SUPRA (RM502U)
INSPECTION
INSPECT FUEL TANK AND LINE
(a) Check the fuel lines for cracks or leakage, and all connec-
tions for deformation.
(b) Check the fuel tank vapor vent system hoses and connec-
tions for looseness, sharp bends or damage.
(c) Check the fuel tank for deformation, cracks, fuel leakage
or tank band looseness.
(d) Check the filler neck for damage or fuel leakage.
(e) Hose and tube connections are as shown in the illustra-
tion.
If a problem is found, repair or replace the part as necessary.
Page 1493 of 1807
SF0H2-01
P18727
No.1 Air Hose
Wire ClampAir Cleaner Hose
MAF Meter
ConnectorMAF Meter SF-36
- SFI (2JZ-GTE)MASS AIR FLOW (MAF) METER
1362 Author: Date:
1997 SUPRA (RM502U)
MASS AIR FLOW (MAF) METER
COMPONENTS
Page 1494 of 1807
SF0H3-01
P12084
ClampConnector
- SFI (2JZ-GTE)MASS AIR FLOW (MAF) METER
SF-37
1363 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. REMOVE NO.1 AIR HOSE
2. REMOVE AIR CLEANER HOSE
3. REMOVE MAF METER
(a) Remove the 2 bolts, and disconnect the MAF meter from
the air cleaner case.
Torque: 6.9 N´m (70 kgf´cm, 61 in.´lbf)
(b) Disconnect the MAF meter wire from the wire clamp on
the air cleaner case.
(c) Disconnect the MAF meter connector, and remove the
MAF meter.
Page 1495 of 1807

SF0H4-01
FI6961
E2
THa Ohmmeter
P12997
Voltmeter
VG
E21 Air SF-38
- SFI (2JZ-GTE)MASS AIR FLOW (MAF) METER
1364 Author: Date:
1997 SUPRA (RM502U)
INSPECTION
1. INSPECT MAF METER RESISTANCE
Using an ohmmeter, measure the resistance between terminals
THA and E2.
Resistance:
-20°C (-4°F)10 - 20 kW
0°C (32°F)4 - 7 kW
20°C (68°F)2 - 3 kW
40°C (104°F)0.9 - 1.3 kW
60°C (140°F)0.4 - 0.7 kW
If the resistance is not as specified, replace the MAF meter.
2. INSPECT MAF METER OPERATION
(a) Connectfthe MAF meter connector.
(b) Connectfthe negative (-) terminal cable to the battery.
(c) Using a voltmeter, connect the positive (+) tester probe to
terminal VG, and negative (-) tester probe to terminal
E21.
(d) Turn the ignition switch ON.
(e) Blow air into the MAF meter, and check that the voltage
fluctuates.
If operation is not as specified, replace the MAF meter.
(f) Turn the ignition switch OFF.
(g) Disconnect the negative (-) terminal cable from the bat-
tery.
(h) Disconnect the MAF meter connector.
Page 1496 of 1807

P11325
SF0H6-01
P12079
P12560
Turn
Dashpot
Adjusting Screw
Push Rod SF-40
- SFI (2JZ-GTE)THROTTLE BODY
1366 Author: Date:
1997 SUPRA (RM502U)
THROTTLE BODY
ON-VEHICLE INSPECTION
1. INSPECT THROTTLE BODY
(a) Check that the throttle linkage moves smoothly.
(b) Check the vacuum at the purge port.
Start the engine.
Check the vacuum with your finger.
Port nameAt idleAt 3,000 rpm
PurgeNo vacuumVacuum
2. INSPECT DASHPOT
(a) Warm up engine.
Allow the engine to warm up to normal operating tempera-
ture.
(b) Check idle speed.
Idle speed (Transmission in neutral position):
650 ± 50 rpm
(c) Check and adjust dashpot setting speed.
(1) Disconnect the control cables from the throttle
body.
(2) Turn the throttle linkage until the dashpot adjusting
screw starts to separate from the push rod. Then
keep the throttle linkage at that position.
(3) Check that the dashpot is set.
Dashpot setting speed: 2,300 ± 400 rpm
(4) Reconnect the control cables to the throttle body.
(d) Check VTV operation
(1) Maintain the engine speed at 3,500 rpm.
(2) Release the throttle valve, and check that the en-
gine returns to idle in a few seconds.
