Page 1385 of 1807
LU04Q-01
B02884
Water Bypass HosePS Oil Reservoir
Engine Wire Protector
O-Ring
Oil Cooler
Plate Washer
Relief Valve
Oil Filter
Non-reusable part
- LUBRICATIONOIL COOLER (2JZ-GTE)
LU-19
1466 Author: Date:
1997 SUPRA (RM502U)
OIL COOLER (2JZ-GTE)
COMPONENTS
Page 1386 of 1807
LU04R-01
P11555
P12215
30 mm
Socket
Wrench LU-20
- LUBRICATIONOIL COOLER (2JZ-GTE)
1467 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. DISCONNECT PS OIL RESERVOIR WITHOUT
DISCONNECTING HOSES
(a) Disconnect the 2 clamps of the engine wire protector from
the bracket.
(b) Remove the 3 bolts and disconnect the reservoir.
2. DRAIN ENGINE COOLANT
3. REMOVE OIL FILTER
(See page LU-4)
4. DISCONNECT WATER BYPASS HOSES FROM OIL
COOLER
5. REMOVE OIL COOLER
(a) Remove the relief valve, plate washer and oil cooler.
(b) Remove the 2 O-rings from the oil cooler.
Page 1387 of 1807
LU04S-01
P11183
Push
- LUBRICATIONOIL COOLER (2JZ-GTE)
LU-21
1468 Author: Date:
1997 SUPRA (RM502U)
INSPECTION
1. INSPECT RELIEF VALVE
Push the valve with a wooden stick to check if it is stuck.
If stuck, replace the relief valve.
2. INSPECT OIL COOLER
Check the oil cooler for damage or clogging.
If necessary, replace the oil cooler.
Page 1388 of 1807
LU04T-02
P11208
New O-Ring LU-22
- LUBRICATIONOIL COOLER (2JZ-GTE)
1469 Author: Date:
1997 SUPRA (RM502U)
INSTALLATION
1. INSTALL OIL COOLER
(a) Install 2 new O-rings to the oil cooler.
(b) Apply a light coat of engine oil on the threads and under
the head of the relief valve.
(c) Temporarily install the oil cooler with the plate washer and
relief valve.
(d) Tighten the relief valve.
Torque: 78 N´m (800 kgf´cm, 58 ft´lbf)
2. CONNECT WATER BYPASS HOSES TO OIL
COOLER
3. CONNECT PS OIL RESERVOIR
4. INSTALL OIL FILTER
5. FILL WITH ENGINE COOLANT
6. START ENGINE AND CHECK FOR LEAKS
7. CHECK ENGINE OIL LEVEL
Page 1389 of 1807
LU051-01
Z13338
Oil Nozzle
Crankshaft
- LUBRICATIONOIL NOZZLE (2JZ-GTE)
LU-23
1470 Author: Date:
1997 SUPRA (RM502U)
OIL NOZZLE (2JZ-GTE)
COMPONENTS
Page 1390 of 1807
LU052-01
P11778
5 mm
Hexagon
Wrench LU-24
- LUBRICATIONOIL NOZZLE (2JZ-GTE)
1471 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. REMOVE CRANKSHAFT
(See page EM-71)
2. REMOVE OIL NOZZLES (WITH RELIEF VALVES)
Using a 5 mm hexagon wrench, remove the bolt and oil nozzle.
Remove the 6 oil nozzles.
Page 1391 of 1807
LU053-01
B03055
Push
- LUBRICATIONOIL NOZZLE (2JZ-GTE)
LU-25
1472 Author: Date:
1997 SUPRA (RM502U)
INSPECTION
INSPECT RELIEF VALVES (OIL NOZZLES)
Push the valve with a wooden stick to check if it is stuck.
If stuck, replace the relief valve.
Page 1392 of 1807
LU054-01
P11778
5 mm
Hexagon
Wrench LU-26
- LUBRICATIONOIL NOZZLE (2JZ-GTE)
1473 Author: Date:
1997 SUPRA (RM502U)
INSTALLATION
1. INSTALL OIL NOZZLES (WITH RELIEF VALVES)
Using a 5 mm hexagon wrench, install the oil nozzle with the
bolt. Install the 6 oil nozzles.
Torque: 9.0 N´m (90 kgf´cm, 80 in.´lbf)
2. INSTALL CRANKSHAFT
(See page EM-88)
