Page 1569 of 1807

ST04I-01
P10952
Terminal 50
Battery Terminal C
P10953
Battery Terminal CDisconnect
P10954
Battery Disconnect
P10955
Terminal 50
Battery Terminal 30
Ammeter ST-14
- STARTINGSTARTER
1521 Author: Date:
1997 SUPRA (RM502U)
TEST
NOTICE:
These tests must be done within 3 to 5 seconds to avoid
burning out the coil.
1. PERFORM PULL-IN TEST
(a) Disconnect the field coil lead wire from terminal C.
(b) Connect the battery to the magnetic switch as shown.
Check that the pinion gear moves outward.
2. PERFORM HOLD-IN TEST
While connected as above with the pinion gear out, disconnect
the negative (-) lead from terminal C.
Check that the pinion gear remains out.
3. INSPECT CLUTCH PINION GEAR RETURN
Disconnect the negative (-) lead from the starter body.
Check that the pinion gear returns inward.
4. PERFORM NO-LOAD PERFORMANCE TEST
(a) Connect the battery and ammeter to the starter as shown.
(b) Check that the starter rotates smoothly and steadily with
the pinion gear moving out. Check that the ammeter
shows the specified current.
Specified current: 90 A or less at 11.5 V
Page 1570 of 1807
P11569
Starter
Relay
ST04K-01
P07170
No
Continuity
5 OhmmeterContinuity
3
2 1
Ohmmeter
P07171
5 Continuity
3
2 1 Ohmmeter
Battery ST-16
- STARTINGSTARTER RELAY
1523 Author: Date:
1997 SUPRA (RM502U)
STARTER RELAY
INSPECTION
1. REMOVE STARTER RELAY (Marking: ST)
LOCATION: In the engine compartment relay box.
Remove the relay box cover and starter relay.
2. INSPECT STARTER RELAY CONTINUITY
(a) Using an ohmmeter, check that there is continuity be-
tween terminals 1 and 2.
If there is no continuity, replace the relay.
(b) Check that there is no continuity between terminals 3 and
5.
If there is continuity, replace the relay.
3. INSPECT STARTER RELAY OPERATION
(a) Apply battery positive voltage across terminals 1 and 2.
(b) Using an ohmmeter, check that there is continuity be-
tween terminals 3 and 5.
If there is no continuity, replace the relay.
4. REINSTALL STARTER RELAY
Page 1571 of 1807

SR13T-01
SR-2
- STEERINGTROUBLESHOOTING
1886 Author: Date:
1997 SUPRA (RM502U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the problem. The numbers indicate the priority of the likely
cause of the problem. Check each part in order. If necessary, repair or replace these parts.
SymptomSuspect AreaSee page
Hard steering
1. Tires (Improperly inflated)
2. Power steering fluid level (Low)
3. Drive belt (Loose)
4. Front wheel alignment (Incorrect)
5. Steering system joints (Worn)
6. Suspension arm ball joints (Worn)
7. Steering column (Binding)
8. Power steering gear
9. PPS systemSA-2
SR-4
-
SA-3
-
SA-30
SA-35
-
-
SR-54
Poor return
1. Tires (Improperly inflated)
2. Front wheel alignment (Incorrect)
3. Steering column (Binding)
4. Power steering gearSA-2
SA-3
-
-
Excessive play
1. Steering system joints (Worn)
2. Suspension arm ball joints (Worn)
3. Intermediate shaft, Universal joint, Sliding yoke (Worn)
4. Front wheel bearing (Worn)
5. Power steering gear
6. PPS system-
SA-30
SA-35
-
SA-12
-
SR-54
Abnormal noise
1. Power steering fluid level (Low)
2. Steering system joints (Worn)
3. Power steering gearSR-4
-
-
Page 1572 of 1807
SR13U-01
R07281
Normal
Abnormal
- STEERINGPOWER STEERING FLUID
SR-3
1887 Author: Date:
1997 SUPRA (RM502U)
POWER STEERING FLUID
BLEEDING
1. CHECK FLUID LEVEL
(See page SR-4)
2. JACK UP FRONT OF VEHICLE AND SUPPORT IT
WITH STANDS
3. TURN STEERING WHEEL
With the engine stopped, turn the steering wheel slowly from
lock to lock several times.
NOTICE:
Take care that some fluid remains in the oil reservoir.
4. LOWER VEHICLE
5. START ENGINE
Run the engine at idle for a few minutes.
6. TURN STEERING WHEEL
(a) With the engine at idling, turn the steering wheel to left or
right full lock and keep it there for 2-3 seconds, then turn
the wheel to the opposite full lock and keep it there for 2-3
seconds.
(b) Repeat (a) several times.
7. STOP ENGINE
8. CHECK FOR FOAMING OR EMULSIFICATION
If the system has to be bled twice specifically because of foam-
ing or emulsification, check for fluid leaks in the system.
9. CHECK FLUID LEVEL
(See page SR-4)
Page 1573 of 1807

SR13V-01
R00441
R07281
Normal Abnormal
R10552
5 mm (0.20 in.)
or less
Engine Idling Engine Stopped SR-4
- STEERINGPOWER STEERING FLUID
1888 Author: Date:
1997 SUPRA (RM502U)
INSPECTION
1. CHECK FLUID LEVEL
(a) Keep the vehicle level.
With the engine stopped, check the fluid level in the oil
reservoir.
If necessary, add fluid.
Fluid: ATF DEXRON® II or III
HINT:
Check that the fluid level is within the HOT LEVEL range on the
dipstick of the reservoir cap. If the fluid is cold, check that it is
within the COLD LEVEL range.
(b) Start the engine and run it at idle.
(c) Turn the steering wheel from lock to lock several times to
boost fluid temperature.
Fluid temperature: 80°C (176°F)
(d) Check for foaming or emulsification.
If there is foaming or emulsification, bleed power steering sys-
tem.
(See page SR-3)
(e) With the engine idling, measure the fluid level in the oil
reservoir.
(f) Stop the engine.
(g) Wait a few minutes and remeasure the fluid level in the
reservoir.
Maximum fluid level rise: 5mm (0.20 in.)
If a problem is found, bleed power steering system.
(See page SR-3)
(h) Check the fluid level.
Page 1574 of 1807
Z16580
INSSTSST
OUTPressure Feed Tube
Attachment
PS Vane Pump 2JZ-GE:
2JZ-GTE:
Attachment Attachment PS Vane Pump Attachment
Pressure Feed Tube
- STEERINGPOWER STEERING FLUID
SR-5
1889 Author: Date:
1997 SUPRA (RM502U)
2. CHECK STEERING FLUID PRESSURE
(a) Disconnect the pressure feed tube from the PS vane
pump.
(See page SR-26)
(b) Connect SST over a new gasket, as shown below.
SST 09640-10010 (09641-01010, 09641-01030,
09641-01060)
NOTICE:
Check that the valve of the SST is in the open position.
(c) Bleed the power steering system.
(See page SR-3)
(d) Start the engine and run it at idle.
(e) Turn the steering wheel from lock to lock several times to
boost fluid temperature.
Fluid temperature: 80°C (176°F)
Page 1575 of 1807

Z15498
PS GearOil
Reservior
PS Vane
Pump Closed
SST
Z15499
PS GearOil
Reservior
PS Vane
Pump
SST Open
Z15500
PS GearOil
Reservior
PS Vane
Pump
SST Open SR-6
- STEERINGPOWER STEERING FLUID
1890 Author: Date:
1997 SUPRA (RM502U)
(f) With the engine idling, close the valve of the SST and ob-
serve the reading on the SST.
Minimum fluid pressure:
7,355 kPa (75 kgf.cm
2, 1,067 psi)
NOTICE:
Do not keep the valve closed for more than 10 se-
conds.
Do not let the fluid temperature become too high.
(g) With the engine idling, open the valve fully.
(h) Measure the fluid pressure at engine speeds of 1,000 rpm
and 3,000 rpm.
Difference fluid pressure:
490 kPa (5 kgf.cm
2, 71 psi) or less
NOTICE:
Do not turn the steering wheel.
(i) With the engine idling and valve fully opened, turn the
wheel to full lock.
Minimum fluid pressure:
7,355 kpa (75 kgf,cm
2, 1,067 psi)
NOTICE:
Do not maintain lock position for more than 10 se-
conds.
Do not let the fluid temperature become too high.
(j) Disconnect the SST.
(k) Connect the pressure feed tube.
(See page SR-34)
(l) Bleed the power steering system.
(See page SR-3)
Page 1576 of 1807
Z13450
2JZ-GE:
2JZ-GTE:SR0CK-01
- STEERINGAIR CONTROL VALVE
SR-7
1891 Author: Date:
1997 SUPRA (RM502U)
AIR CONTROL VALVE
INSPECTION
CHECK IDLE-UP
(a) Turn the air conditioner switch off.
(b) Start the engine and run it at idle.
(c) Fully turn the steering wheel.
(d) Check that the engine speed decreases when the vacu-
um hose of the air control valve is pinched.
(e) Check that the engine speed increases when the hose is
released.
