Page 1777 of 1807

SS0DF-02
- SERVICE SPECIFICATIONSBODY ELECTRICAL
SS-65
222 Author: Date:
1997 SUPRA (RM502U)
BODY ELECTRICAL
SERVICE DATA
INTEGRATION RELAY (Relay Circuit)
(Light Auto Turn Off System)
B2 - Ground (Constant)Battery positive voltage
B3 - Ground (Constant)Battery positive voltage
A7 - Ground (Ignition switch LOCK or ACC)No voltage
A7 - Ground (Ignition switch ON)Battery positive voltage
A1 - Ground (Constant)Battery positive voltage
DAYTIME RUNNING LIGHT MAIN RELAY
(Wire Harness Side)
2 - Ground (Ignition switch position LOCK or ACC)No voltage
2 - Ground (Ignition switch position ON)Battery positive voltage
11 - Ground (Engine stop)No voltage
11 - Ground (Engine running)Battery positive voltage
15 - Ground (Constant)Battery positive voltage
17 - Ground (Constant)Battery positive voltage
TURN SIGNAL FLASHER
Flashes/Minute60 - 120
INTEGRATION RELAY
(Interior Light System)
1 - Ground (Constant)Battery positive voltage
9 - Ground (Ignition switch position LOCK or ACC)No voltage
9 - Ground (Ignition switch position ON)Battery positive voltage
SPEEDOMETER (USING A SPEEDOMETER TESTER)
USA:
Standard indication (mph)Allowable range (mph)
2018 - 24
4038 - 44
6058 - 66
8078 - 88
10098 - 110
120118 - 132
CANADA:
Standard indication (km/h)Allowable range (km/h)
2017 - 24
4038 - 46
6057.5 - 67
8077 - 88
10096 - 109
120115 - 130
140134 - 151.5
160153 - 173
TACHOMETER (ON-VEHICLE)
Standard indication (rpm)Allowable range (rpm)
Page 1778 of 1807

SS-66
- SERVICE SPECIFICATIONSBODY ELECTRICAL
223 Author: Date:
1997 SUPRA (RM502U)700
630 - 770
1,000915 - 1,115
2,0001,920 - 2,220
3,0002,890 - 3,350
4,0003,940 - 4,400
5,0005,025 - 5,425
6,5006,650 - 6,950
7,0007,025 - 7,625
OD/TRIP METER
(Connector Connected)
1 - Ground (Ignition switch position ON)Battery positive voltage
4 - Ground (Light Control switch position TAIL or HEAD)Battery positive voltage
5 - 7 (Ignition switch ON and drive the vehicle slowly)0V e Battery positive voltage
6 - 7 (Ignition switch ON and drive the vehicle slowly)0V e more than 5V
8 - Ground (Constant)Battery positive voltage
10 - Ground (Ignition SW ON, Light Control SW TAIL or
HEAD and turn the Light Control Rheostat knob to clockwise)6V " 0V
FUEL RECEIVER GAUGE
Between terminalsResistance (W)
A - BApprox. 269.7
A - CApprox. 123.5
B - CApprox. 146.2
FUEL SENDER GAUGE
Float position: mm (in.)Resistance (W)
F: Approx. 33.8 (1.331)Approx. 4.0
1/2: Approx. 44.8 (1.764)Approx. 55.0
E: Approx. 141.1 (5.555)Approx. 107.0
ENGINE COOLANT TEMPERATURE RECEIVER GAUGE
Between terminalsResistance (W)
A - BApprox. 229.7
A - CApprox. 54.0
B - CApprox. 175.7
ENGINE COOLANT TEMPERATURE SENDER GAUGE
Temperature °C (°F)Resistance (W)
50 (122.0)160 - 240
120 (248.0)17.1 - 21.2
LIGHT FAILURE SENSOR
3 - Ground (Light Control SW position OFF)No voltage
3 - Ground (Light Control SW position TAIL or HEAD)Battery positive voltage
4 - Ground (Ignition SW position LOCK or ACC)No voltage
4 - Ground (Ignition SW position ON)Battery positive voltage
7 - Ground (Stop Light SW position OFF)No voltage
7 - Ground (Stop Light SW position ON)Battery positive voltage
8 - Ground (Engine stop)No voltage
8 - Ground (Engine running)Battery positive voltage
INTEGRATION RELAY
Page 1779 of 1807
- SERVICE SPECIFICATIONSBODY ELECTRICAL
SS-67
224 Author: Date:
1997 SUPRA (RM502U) (Seat Belt Warning)
1 - Ground (Constant)Battery positive voltage
9 - Ground (Ignition SW LOCK or ACC)No voltage
9 - Ground (Ignition SW ON)Battery positive voltage
ANTENNA MOTOR CONTROL RELAY
(Wire Harness Side)
1 - Ground (Constant)Battery positive voltage
4 - Ground (Ignition switch position ON)Battery positive voltage
5 - Ground (Ignition position ACC or ON)Battery positive voltage
7 - Ground (Ignition SW position ACC or ON and radio SW ON)Battery positive voltage
8 - Ground (Ignition SW position ACC or ON)Battery positive voltage
Page 1780 of 1807

SS0D7-01
SS-68
- SERVICE SPECIFICATIONSBODY
225 Author: Date:
1997 SUPRA (RM502U)
BODY
TORQUE SPECIFICATION
Part tightenedN´mkgf´cmft´lbf
FRONT BUMPER---
Reinforcement x Body5.96052 in.´lbf
Front bumper cover x Body5.96052 in.´lbf
REAR BUMPER---
Reinforcement x Body4243031
Rear bumper cover x Body5.96052 in.´lbf
HOOD---
Hood hinge x Hood131309.4
Hood lock x Body8.89078 in.´lbf
FRONT DOOR---
Door hinge x Body5253038
Door hinge x Door panel2526019
Window regulator x Door glass7.47667 in.´lbf
Door lock x Door panel5.05144 in.´lbf
Window regulator x Door panel7.47667 in.´lbf
Window guide lower plate x Door panel5.45548 in.´lbf
Door window upper stop x Door panel1111 58.3
BACK DOOR---
Back door hinge x Body2121015
Back door hinge x Back door131309.4
Door lock x Body1919514
Door lock striker x Body131309.4
Back door damper stay x Body5.96052 in.´lbf
Back door damper stay x Back door7.88069 in.´lbf
WIPER AND WASHER---
Front Wiper---
Wiper arm x Wiper link2222516
Rear Wiper---
Wiper arm x Wiper motor1111 08.0
INSTRUMENT PANEL---
Steering column x Instrument panel reinforcement2526019
Front passenger airbag assembly x Instrument panel reinforcement2121015
Front passenger airbag assembly x Instrument panel8.89078 in.´lbf
Steering wheel x Steering column3536026
Steering wheel pad x Steering wheel7.17262 in.´lbf
FRONT SEAT---
Seat adjuster x Body3737527
Seat adjuster x Seatback1818513
Seat adjuster x Seat cushion1818513
REAR SEAT---
Seatback x Body2526019
Reclining adjuster x Seatback1818513
Page 1781 of 1807
- SERVICE SPECIFICATIONSBODY
SS-69
226 Author: Date:
1997 SUPRA (RM502U) SEAT BELT
---
Front Seat Belt---
Shoulder anchor x Body4344032
Outer belt anchor x Body4344032
Retractor x Body (Upper Side)7.88069 in.´lbf
Retractor x Body (Lower Side)4344032
Inner belt x Seat4344032
Rear Seat Belt---
Shoulder anchor x Body4344032
Outer belt anchor x Body4344032
Retractor x Body4344032
Inner belt x Body4344032
Page 1782 of 1807
SS0CW-01
SS-70
- SERVICE SPECIFICATIONSAIR CONDITIONING
227 Author: Date:
1997 SUPRA (RM502U)
AIR CONDITIONING
SERVICE DATA
Refrigerant charge volume700 ± 50 g (24.96 ± 1.76 oz.)
Idle speed
2JZ-GE (M/T)
Magnetic clutch not engagedApprox. 700 rpm
Magnetic clutch engagedApprox. 900 rpm
2JZ-GE (A/T)
Magnetic clutch not engagedApprox. 700 rpm
Magnetic clutch engagedApprox. 800 rpm
2JZ-GTE
Magnetic clutch not engagedApprox. 650 rpm
Magnetic clutch engagedApprox. 800 rpm
Magnetic clutch clearance0.5 ± 0.15 mm (0.020 ± 0.0059 in.)
Page 1783 of 1807
SS0CX-01
- SERVICE SPECIFICATIONSAIR CONDITIONING
SS-71
228 Author: Date:
1997 SUPRA (RM502U)
TORQUE SPECIFICATION
Part tightnedN´mkgf´cmft´lbf
Compressor x Suction hose101007
Compressor x Discharge hose101007
Compressor x Engine
Stud bolt2626519.2
Other bolts and nut5253038.3
Receiver x Liquid tube5.45548 in.´lbf
Condenser x Liquid tube101007
Condenser x Discharge hose101007
Expansion valve x Evaporator5.45548 in.´lbf
A/C unit x Liquid and suction tube101007
Pressue switch x Liquid tube101007
Condenser upper mounting x Body4.14236 in.´lbf
Pressure plate x Compressor1414010
ECT switch x radiator7.47565 in.´lbf
PS vane pump set bolt5859042
Liquid lines101007
Discharge lines101007
Suction lines101007
Page 1784 of 1807

TC037-01
(Possible Cause)
(Check Procedure and Correction Method)
Check intake air system, and repair or replace parts
as necessary. (See page TC-5)
Check intake air system, and repair or replace parts
as necessary. (See page TC-5)
Check exhaust system, and repair or replace parts
as necessary. (See page TC-5)
Check exhaust system, and repair or replace parts
as necessary. (See page TC-5) Check turbocharging pressure. (See page TC-5)
Turbocharging pressure:
61 - 75 kPa
(0.62 - 0.76 kgf/cm2, 8.8 - 10.8 psi)
If the pressure is below specifications, begin
diagnosis from item 2.
Check rotation of turbine shaft. If it does not turn or
turns with a heavy drag, replace the turbocharger
assembly.
Check axial and radial play of turbine shaft.
(See page TC-18)
Maximum axial play : 0.110 mm (0.0045 in.)
Maximum radial play: 0.173 mm (0.0068 in.)
If the play is greater than maximum, replace the
turbocharger assembly.
3. LEAK IN INTAKE AIR SYSTEM
4. RESTRICTED EXHAUST SYSTEM
6. ERRATIC TURBOCHARGER 5. LEAK IN EXHAUST SYSTEM
OPERATION 1. TURBOCHARGING PRESSURE
TOO LOW
2. RESTRICTED INTAKE SYSTEM
- TURBOCHARGING (2JZ-GTE)TROUBLESHOOTING
TC-1
1201 Author: Date:
1997 SUPRA (RM502U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
HINT:
Before troubleshooting the turbocharger, first check the engine itself. (Valve clearance, engine compression,
ignition timing etc.)
1. INSUFFICIENT ACCELERATION, LACK OF POWER OR EXCESSIVE FUEL CONSUMPTION
