Page 969 of 1807
I02716
Full Open Side
Control Plate4
1
32
(+)
(-)
I02717
Full Close Side
Control Plate4
1
32
(+)
(-)
DI-678
- DIAGNOSTICSCRUISE CONTROL SYSTEM
906 Author: Date:
1997 SUPRA (RM502U)
2 Check actuator operation.
PREPARATION:
Disconnect the actuator connector.
CHECK:
Connect the positive lead from the battery to terminals 3 and
1 of actuator, connect the negative lead to terminals 4 and
2 of actuator.
OK:
Control arm moves to full open side
CHECK:
Connect the positive lead from the battery to the terminals
4 and 2 of actuator, connect the negative lead to terminals
3 and 1 of actuator.
OK:
Control arm moves to full close side
NG Replace actuator.
OK
3 Check harness and connector between actuator and cruise control ECU
(See page IN-28).
NG Repair or replace harness or connector.
OK
Check and replace cruise control ECU
(See page IN-28).
Page 970 of 1807
I00292
Vehicle Speed Sensor
ECUCombination Meter
Cruise Control ECU
4 pulse/
1 rotation
of rotor shaft4 pulse/
1 rotation
of rotor shaft
I02718
Speedometer
(Combination Meter)L-R 2
II1V103
No.1 Vehicle Speed Sensor
(Combination Meter) T65Telltale Light RH
ODO and TRIP
Meter Circuit6
T6P5
IF2P20
C16Cruise Control ECU
SPD
W
WW W
- DIAGNOSTICSCRUISE CONTROL SYSTEM
DI-679
907 Author: Date:
1997 SUPRA (RM502U)
DTC 21 Open in Vehicle Speed Sensor Circuit
CIRCUIT DESCRIPTION
The vehicle speed sensor circuit is sent to cruise control ECU as vehicle speed signal. For each rotation of
the shaft, the vehicle speed sensor sends a signal through the combination meter to the cruise control ECU
(See the following). The ECU calculates the vehicle speed from this pulse frequency.
DTC No.Detection ItemTrouble Area
21Speed signal is not input to the cruise control ECU while cruise
control is set.Vehicle speed sensor
Combination meter
Cruise control ECU
WIRING DIAGRAM
DI4XT-01
Page 971 of 1807
Input SignalIndicator Light
Blinking Pattern
Drive at about
40 km/h (25 mph)
or below
Drive at about
40 km/h (25 mph)
or higherLightON
OFF
LightON
OFF
DI-680
- DIAGNOSTICSCRUISE CONTROL SYSTEM
908 Author: Date:
1997 SUPRA (RM502U)
INSPECTION PROCEDURE
1 Input signal check.
CHECK:
(a) See input signal check on page
(b) Check indicator light operation when driving with vehicle
speed above 40 km/h (25 mph), and with vehicle speed
below 40 km/h (25 mph).
OK:
Vehicle speed above 40 km/h (25 mph):
Indicator light blinks
Vehicle speed below 40 km/h (25 mph):
Indicator light stays on
OK Check and replace cruise control ECU
(See page IN-28).
NG
2 Check harness and connector between speed meter and cruise control ECU
(See page IN-28).
NG Repair or replace harness or connector.
OK
3 Check vehicle speed sensor (See page BE-43).
NG Replace vehicle speed sensor.
OK
Check and replace cruise control ECU
(See page IN-28).
Page 972 of 1807
- DIAGNOSTICSCRUISE CONTROL SYSTEM
DI-681
909 Author: Date:
1997 SUPRA (RM502U)
DTC 23 Vehicle Speed Signal Abnormal
CIRCUIT DESCRIPTION
See page DI-679.
DTC No.Detection ItemTrouble Area
23
Vehicle speed sensor pulse is abnormal. (When sped signal
is not input to the ECU below 0.2 sec., code will be dis-
played.)Vehicle speed sensor
Cruise control ECU
WIRING DIAGRAM
See page DI-679.
INSPECTION PROCEDURE
1 Check vehicle speed sensor (See page BE-43).
NG Replace vehicle speed sensor.
OK
Check and replace cruise control ECU
(See page IN-28).
DI4XU-01
Page 973 of 1807
I02719
W-B
IEW-BJ/B No.1
1
1J13
1HCruise Control ECU
W-B
W-B13
C16
C14 17
Cruise Control Switch CANCELSET/
COASTRESUME/
ACCEL E
MAIN
CMS15
C14
5
C14R-Y
L19
C16
18
C16GND
W-B
CMS
CCS DI-682
- DIAGNOSTICSCRUISE CONTROL SYSTEM
910 Author: Date:
1997 SUPRA (RM502U)
DTC 32 Control Switch Circuit
(Cruise Control Switch)
CIRCUIT DESCRIPTION
This circuit carries the SET/COAST, RESUME/ACCEL and CANCEl signals (each voltage) to the ECU.
DTC No.Detection ItemTrouble Area
32Short in control switch circuit
Cruise control switch
Harness or connector between control switch and cruise
control ECU.
Cruise control ECU
WIRING DIAGRAM
DI4XV-01
Page 974 of 1807

Input SignalIndicator Light
Blinking Pattern
SET/COAST
switch
RESUME/ACCEL
switch
CANCEL switch2 Pulses
ON
OFF
ON
OFF3 Pulses
ON
OFFSW OFF
SW ON
N16045
3 4
- DIAGNOSTICSCRUISE CONTROL SYSTEM
DI-683
911 Author: Date:
1997 SUPRA (RM502U)
INSPECTION PROCEDURE
1 Input signal check.
PREPARATION:
See input signal check on page DI-662.
CHECK:
Check the indicator light operation when each of the SET/
COAST, RESUME/ACCEL and CANCEL is turned on.
OK:
SET/COAST, RESUME/ACCEL switch
The signals shown in the table on the left should be
output when each switch is ON. The signal should
disappear when the switch is turned OFF.
CANCEL switch
The indicator light goes off when the cancel switch is
turned on.
OK Wait and see.
NG
2 Check control switch.
PREPARATION:
(a) Remove steering wheel center pad (See page SR-1 1).
(b) Disconnect control switch connector.
CHECK:
Measure resistance between terminals 3 and 4 of control switch
connector when control switch is operated.
Switch positionResistance (W)
Neutral8 (No continuity)
RES/ACC50 - 80
SET/COAST180 - 220
CANCEL400 - 440
OK Repair control switch.
NG
Page 975 of 1807
DI-684
- DIAGNOSTICSCRUISE CONTROL SYSTEM
912 Author: Date:
1997 SUPRA (RM502U)
3 Check harness and connector between cruise control switch and cruise control
ECU (See page IN-28).
NG Repair or replace harness or connector.
OK
4 Input signal check (See step 1).
OK Wait and see.
NG
Check and replace cruise control ECU
(See page IN-28).
Page 976 of 1807
I02720
IDL164
E9R-B*
1
R*2
R-B*1
2*2T2
IDL
Throttle Position Sensor3
IJ1R-B21
C16
IDL Cruise Control ECU
3*1
R-B*1
R*2R*2
*1: 2JZ-GE Engine
*2: 2JZ-GTE Engine ECM
- DIAGNOSTICSCRUISE CONTROL SYSTEM
DI-685
913 Author: Date:
1997 SUPRA (RM502U)
DTC 51 Idle Signal Circuit
CIRCUIT DESCRIPTION
When the idle switch in turned ON, a signal is sent to the ECU. The ECU uses this signal to correct the dis-
crepancy between the throttle valve position and the actuator position sensor value to enable accurate
cruise control at the set speed. If the idle switch is malfunctioning, problem symptoms also occur in the en-
gine, so also inspect the engine.
DTC No.Detection ItemTrouble Area
51Short in idle signal circuit
Harness or connector between cruise control ECU and
throttle position sensor
Throttle position sensor
Cruise control ECU
WIRING DIAGRAM
DI4XW-01
