Page 345 of 1807
BR0H1-01
R10605
Left Wheel
Right Wheel
- BRAKEFRONT BRAKE CALIPER (2JZ-GTE)
BR-39
1839 Author: Date:
1997 SUPRA (RM502U)
INSPECTION
1. MEASURE PAD LINING THICKNESS
(See page BR-32)
Standard thickness: 12.0 mm (0.472 in.)
Minimum thickness: 1.0 mm (0.039 in.)
2. MEASURE DISC THICKNESS
(See page BR-32)
Standard thickness: 30.0 mm (1.181 in.)
Minimum thickness: 28.0 mm (1.102 in.)
3. MEASURE DISC RUNOUT
(See page BR-32)
Maximum disc runout: 0.05 mm (0.0020 in.)
4. IF NECESSARY, ADJUST DISC RUNOUT
(See page BR-32)
HINT:
Install a disc marked with ºRº on the right wheel, and a disc
marked with ºLº on the left wheel.
Page 346 of 1807
BR0H6-01
F02617
Anti-rattle Spring
Pin
Anti-squeal Shim
Inner Anti-squeal Shim Outer Pad Inner Pad Inner Anti-squeal ShimAnti-squeal Shim
Clip
Disc brake grease
- BRAKEREAR BRAKE PAD (2JZ-GTE)
BR-45
1845 Author: Date:
1997 SUPRA (RM502U)
REAR BRAKE PAD (2JZ-GTE)
COMPONENTS
Page 347 of 1807

BR0H7-01
R07147
Z09011
R07150
BR-46
- BRAKEREAR BRAKE PAD (2JZ-GTE)
1846 Author: Date:
1997 SUPRA (RM502U)
REPLACEMENT
1. REMOVE REAR WHEEL
Remove the wheel and temporarily fasten the disc with the hub
nuts.
2. INSPECT PAD LINING THICKNESS
Check the pad thickness and replace pads if they are not within
specification.
Minimum thickness: 1.0 mm (0.039 in.)
3. REMOVE THESE PARTS
(a) Clip and 2 pins
(b) Anti-rattle spring
(c) 2 pads
(d) 4 anti-squeal shims
NOTICE:
The anti-rattle springs and clip can be used again provided
that they have sufficient rebound, no deformation, cracks
or wear, and have had all rust, dirt and foreign particles
cleaned off.
4. CHECK DISC THICKNESS AND RUNOUT
(See page BR-57)
5. INSTALL NEW PADS
NOTICE:
When replacing worn pads, the anti-squeal shims must be
replaced together with the pads.
(a) Draw out a small amount of brake fluid from the reservoir.
(b) Press in the pistons with a hammer handle or equivalent.
HINT:
Always change the pads on one wheel at a time as there
is a possibility of the opposite piston flying out.
If the piston is difficult to push in, loosen the bleeder plug
and push in the piston while letting some brake fluid es-
cape.
Page 348 of 1807
R11394
- BRAKEREAR BRAKE PAD (2JZ-GTE)
BR-47
1847 Author: Date:
1997 SUPRA (RM502U)
(c) Install the 2 anti-squeal shims on each pad.
HINT:
Apply disc brake grease to both sides of the inner anti-
squeal shim (See page BR-45).
Make sure that the arrow on the shims points upward.
(d) Install the 2 pads with pad wear indicator plates facing
downward.
NOTICE:
Do not allow oil or grease to get on the rubbing face.
6. INSTALL ANTI-RATTLE SPRING AND 2 PINS
7. INSTALL CLIP
Page 349 of 1807
BR0HE-02
W00804
Non-reusable part
Lithium soap base glycol grease
Disc brake greaseBreeder PlugCaliper
Anti-rattle
Spring
Gasket Gasket
DiscClip
Pad
Piston Seal
Piston
BootSet Ring
Inner Anti-squeal
ShimAnti-squeal
Shim
Pin BR-54
- BRAKEREAR BRAKE CALIPER (2JZ-GTE)
1854 Author: Date:
1997 SUPRA (RM502U)
REAR BRAKE CALIPER (2JZ-GTE)
COMPONENTS
Page 350 of 1807
BR0HF-01
R07153
R07154
- BRAKEREAR BRAKE CALIPER (2JZ-GTE)
BR-55
1855 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. REMOVE REAR WHEEL
2. DISCONNECT FLEXIBLE HOSE
(a) Remove the union bolt and 2 gaskets from the caliper,
then disconnect the flexible hose from the caliper.
Torque: 30 N´m (310 kgf´cm, 22 ft´lbf)
HINT:
At the time of installation, please refer to the following item.
Install the flexible hose lock securely in the lock hole in the cali-
per.
(b) Use a container to catch the brake fluid.
3. REMOVE CALIPER
Remove the 2 mounting bolts and caliper.
Torque: 104 N´m (1,065 kgf´cm, 77 ft´lbf)
4. REMOVE THESE PARTS
(a) Clip
(b) 2 pins
(c) Anti-rattle spring
(d) 2 pads
(e) 4 anti-squeal shims
Page 351 of 1807
BR0HG-01
Z09008
150 mm
(5.91 in.)50 mm
(1.97 in.)
16 mm
(0.630 in.) BR-56
- BRAKEREAR BRAKE CALIPER (2JZ-GTE)
1856 Author: Date:
1997 SUPRA (RM502U)
DISASSEMBLY
1. REMOVE CYLINDER BOOT SET RINGS AND BOOTS
(See step 1 on page BR-38)
2. REMOVE PISTONS FROM CYLINDER
(See step 2 on page BR-38)
3. REMOVE PISTON SEALS
(See step 3 on page BR-38)
Page 352 of 1807
BR0HH-01
- BRAKEREAR BRAKE CALIPER (2JZ-GTE)
BR-57
1857 Author: Date:
1997 SUPRA (RM502U)
INSPECTION
1. MEASURE PAD LINING THICKNESS (See page BR-32)
Standard thickness: 11.0 mm (0.433 in.)
Minimum thickness: 1.0 mm (0.039 in.)
2. MEASURE DISC THICKNESS (See page BR-32)
Standard thickness: 16.0 mm (0.630 in.)
Minimum thickness: 15.0 mm (0.591 in.)
3. MEASURE DISC RUNOUT (See page BR-32)
Maximum disc runout: 0.05 mm (0.0020 in.)
4. IF NECESSARY, ADJUST DISC RUNOUT (See page BR-32)
