Page 1305 of 1807
P11927
New
GasketNew
Gasket Protrusion
Z09290
14
8 11
12
109
7
1
2
46 3
5 13
- ENGINE MECHANICAL (2JZ-GTE)CYLINDER HEAD
EM-53
1158 Author: Date:
1997 SUPRA (RM502U)
22. INSTALL EXHAUST MANIFOLD
(a) Place 2 new gaskets to the cylinder head facing the pro-
trusion as shown.
(b) Install the exhaust manifold with 12 new nuts, in several
passes, in the sequence shown.
Torque: 39 N´m (400 kgf´cm, 29 ft´lbf)
23. INSTALL TURBOCHARGER (See page TC-20)
Page 1306 of 1807
EM0AU-03
A03678
No.1 Air Hose
Air Cleaner DuctHood
Air Cleaner and MAF
Meter Assembly
Cruise Control Actuator Cable
Water Pump Pulley Heater Water Hose
Actuator Cable
EVAP Hose
Break Booster
Hold-Down
Clamp
Battery
Insulator Vacuum Hose
Battery
Battery TrayFan and Fluid
Coupling Assembly
Drive Belt
Drive Belt Tension
Damper (M/T)
No.5 Air Hose
Upper Radiator Support
Radiator Lower
Hose
Reservoir Inlet Hose
Electric Cooling Fan Connector
ECT Switch (for Electric Cooling Fan) Connector
Radiator Assembly
Engine Under Cover No.2 Air Tube
No.2 Fan ShroudClipCharcoal Canister EM-54
- ENGINE MECHANICAL (2JZ-GTE)ENGINE UNIT
1159 Author: Date:
1997 SUPRA (RM502U)
ENGINE UNIT
COMPONENTS
Page 1307 of 1807
Z16797
PS Solenoid Valve Connector
Ground Strap
MAF Meter
Connector
Generator
WireStarter Wire
Solenoid Connector
Noise Filter Connector
Igniter Connector
Connector
(from engine room main wire)
A/C Compressor
ConnectorGround Strap
Scuff PlateTRAC ECU Connector Connector
(from connector cassette)
ECM
ConnectorFloor Carpet ECM
ECM ProtectorConnector
(from instrument
panel wire)
- ENGINE MECHANICAL (2JZ-GTE)ENGINE UNIT
EM-55
1160 Author: Date:
1997 SUPRA (RM502U)
Page 1308 of 1807
S00926
Upper Console Panel
Shift & Select Lever BootShift Lever
Shift Lever Knob
Shift Control Rod
Fuel Return Hose
Fuel Inlet Hose A/T
PS Vane Pump
A/C CompressorGround Strap
PS Pump Bracket M/T
Clutch Release Cylinder (M/T)Rear Support Member
Exhaust Pipe AssemblyPropeller Shaft
PS Pressure Feed Hose
No.2 Front Exhaust Pipe
Pipe Support BracketHeated Oxygen SensorHeat InsulatorCenter Floor
Crossmember Brace Ring
Ring Gasket
Gasket
Gasket
Non-reusable partSport Roof EM-56
- ENGINE MECHANICAL (2JZ-GTE)ENGINE UNIT
1161 Author: Date:
1997 SUPRA (RM502U)
Page 1309 of 1807
A02167
Starter ConnectorServise Hole Cover
Oil Cooler Pige
Hole Plugx 6
O-Ring Oil Dipstick and Guide
(for Transmission) Wire BracketEngine Wire Service Hole CoverTransmission Wire Bracket
Starter
Throttle Cable
Starter
Starter Connector
Transmissionx5 M/T
A/T
Non-reusable part
x6
x5
Engine Wire
- ENGINE MECHANICAL (2JZ-GTE)ENGINE UNIT
EM-57
1162 Author: Date:
1997 SUPRA (RM502U)
Page 1310 of 1807

EM0AV-02
P11544
(2)(3)
(1) EM-58
- ENGINE MECHANICAL (2JZ-GTE)ENGINE UNIT
1163 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. REMOVE HOOD
2. REMOVE RADIATOR ASSEMBLY
(See page CO-22)
3. DRAIN ENGINE OIL
4. DRAIN FUEL FROM FUEL TANK
5. REMOVE NO.1 AIR HOSE
6. DISCONNECT CONTROL CABLES FROM
THROTTLE BODY
Disconnect these cables:
Accelerator cable
Cruise control actuator cable
7. REMOVE AIR CLEANER AND MAF METER
ASSEMBLY
(a) Remove the 3 bolts.
(b) Loosen the hose clamp, disconnect the air hose from the
intake air connector.
(c) Disconnect the MAF meter wire from the clamp on the air
cleaner case.
(d) Disconnect the MAF meter connector, and remove the air
cleaner and MAF meter assembly.
8. M/T:
REMOVE DRIVE BELT TENSIONER DAMPER
(See page EM-15)
9. REMOVE DRIVE BELT, FAN, FLUID COUPLING
ASSEMBLY AND WATER PUMP PULLEY
(See page CO-7)
10. REMOVE CHARCOAL CANISTER
11. DISCONNECT HEATER WATER HOSES
12. DISCONNECT BRAKE BOOSTER VACUUM HOSE
13. DISCONNECT EVAP HOSE
14. DISCONNECT WIRES AND CONNECTORS
(a) Disconnect these connectors:
(1) Solenoid resistor connector
(2) Noise filter connector
(3) Igniter connectors
(b) Disconnect the engine wire from the PS oil reservoir pro-
tector
.
Page 1311 of 1807

P11919
P11910
Starter
WireDisconnect
P11643
Fuel Inlet Hose
P12534Fuel Return Hose
P11642
(2)
(1)
- ENGINE MECHANICAL (2JZ-GTE)ENGINE UNIT
EM-59
1164 Author: Date:
1997 SUPRA (RM502U)
(c) Disconnect the connector from the engine room main
wire.
(d) Disconnect the engine wire from the 2 wire clamps.
(e) Remove the rubber cap and nut, and disconnect the gen-
erator wire.
(f) Disconnect the wire clamp and PS solenoid valve con-
nector.
(g) Remove the bolt and disconnect the ground strap from
the cylinder block.
(h) Disconnect the starter wire from the LH engine mounting
bracket.
(i) Remove the rubber cap and nut, and disconnect the start-
er wire.
15. DISCONNECT FUEL HOSES
(a) Remove the union bolt and 2 gaskets, and disconnect the
fuel inlet hose.
HINT:
Put a suitable container or shop rag under the fuel pipe
support.
Slowly loosen the union bolt.
(b) Suspend the hose union end upward.
(c) Disconnect the fuel return hose from the clamp of the dip-
stick guide.
(d) Disconnect the fuel return hose from the fuel return pipe.
Plug the hose end.
16. DISCONNECT PS PUMP WITHOUT
DISCONNECTING HOSES
(a) Disconnect these hoses:
(1) PS air hose from throttle body
(2) PS air hose from air intake chamber
(b) Remove the 2 bolts, and disconnect the vane pump from
the pump bracket.
HINT:
Put aside the vane pump, and suspend it securely.
(c) Remove the 3 bolts and pump bracket.
Page 1312 of 1807
P11534
P11524
P11540
P11763
P11761
EM-60
- ENGINE MECHANICAL (2JZ-GTE)ENGINE UNIT
1165 Author: Date:
1997 SUPRA (RM502U)
17. DISCONNECT PS PRESSURE FEED HOSE FROM
ENGINE
Remove the 2 clamp bolts and disconnect the pressure feed
hose.
18. DISCONNECT A/C COMPRESSOR WITHOUT
DISCONNECTING HOSES
(a) Remove the 2 bolts.
(b) Disconnect the compressor connector.
(c) Remove the bolt and nut.
(d) Using a torx socket (E10), remove the stud bolt, and dis-
connect the compressor from the engine.
HINT:
Put aside the compressor, and suspend it securely.
19. DISCONNECT ENGINE WIRE FROM COWL PANEL
(a) Remove the bolt, and disconnect the ground strap.
(b) Remove the 2 bolts, and disconnect the engine wire pro-
tector.
(c) Remove the 2 bolts holding the engine wire retainer to the
cowl panel.
