Page 737 of 1807

R10305
GL2
VGS
GGNDGL1
Rear Side
Front Side DI-446
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
674 Author: Date:
1997 SUPRA (RM502U)
3. DECELERATION SENSOR OPERATION DIAGNOSIS
SYSTEM
CAUTION:
While checking the deceleration sensor operating diagno-
sis system, the Anti-lock Brake System does not work and
brake system works as a conventional brake system.
(a) Deceleration sensor inspection check of deceleration
sensor output:
(1) Connect 3 dry batteries of 1.5 V in series.
(2) Connect VGS terminal to the batteries' positive (+)
terminal, and GGND terminal to the batteries' nega-
tive (-) terminal, apply about 4.5 V between VGS-
GGND terminals.
NOTICE:
Do not apply voltage of 6 V or more to terminals VGS and
GGND.
(3) Check the output of GL1 and GL2 terminals.
SymbolsConditionStandard Value
GL1Horizontalabout 2.3 V
GL1Lean forward0.4 - about 2.3 V
GL1Lean rearwardabout 2.3 V - 4.1 V
GL2Horizontalabout 2.3 V
GL2Lean forwardabout 2.3 V - 4.1 V
GL2Lean rearward0.4 - about 2.3 V
HINT:
If the senor is tilted too much it may show the wrong value.
If dropped, the sensor should be replaced with a new one.
The sensor removed from the vehicle should not be
placed upside down.
Page 738 of 1807

DI4V7-01
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
DI-447
675 Author: Date:
1997 SUPRA (RM502U)
DIAGNOSTIC TROUBLE CODE CHART
If a malfunction code is displayed during the DTC check, check the circuit listed for that code. For details
of each code, turn to the page referred to under the ºSee pageº for the respective ºDTC No.º in the DTC chart.
HINT:
Using SST 09843-18020, connect the terminals Tc and E1, and remove the short pin.
If any abnormality is not found when inspect each inspection parts, inspect the ECU.
DTC No.
(See Page)Detection ItemTrouble Area
11
(DI-453)Open circuit in ABS solenoid relay circuitABS solenoid relay
Open or short in ABS solenoid relay circuit
12
(DI-453)Short circuit in ABS solenoid relay circuitABS solenoid relay
B+ short in ABS solenoid relay circuit
13*2
(DI-460)Open circuit in ABS motor relay circuitABS motor relay
Open or short in ABS motor relay circuit
14
(DI-460)Short circuit in ABS motor relay circuitABS motor relay
B+ short in ABS motor relay circuit
21
(DI-466)Open or short circuit in 2-position solenoid circuit for right front
wheelABS actuator
Open or short in SFRH or SFRR circuit
22
(DI-466)Open or short circuit in 2-position solenoid circuit for left front
wheelABS actuator
Open or short in SFLH or SFLR circuit
23
(DI-466)Open or short circuit in 2-position solenoid circuit for right rear
wheelABS actuator
Open or short in SRH (SRRH) or SRR (SRRR) circuit
24*1
(DI-466)
Open or short circuit in 2-position solenoid circuit for left rear
wheelABS actuator
Open or short in SRLH or SRLR circuit
31*2
(DI-469)Right front wheel speed sensor signal malfunction
32*2
(DI-469)Left front wheel speed sensor signal malfunctionRight front, left front, right rear and left rear speed sensor
O htihd iit33*2
(DI-469)Right rear wheel speed sensor signal malfunction
Open or short in each speed sensor circuit
Speed sensor rotor
34*2
(DI-469)Left rear wheel speed sensor signal malfunction
41
(DI-475)Low battery positive voltage
Battery
IC regulator
Open or short in power source circuit
43*1
(DI-479)
Malfunction in deceleration sensor
(constant output)Deceleration sensor
Wire harness for deceleration sensor system
44*1
(DI-480)Open or short in deceleration sensor circuitDeceleration sensor
Open or short in deceleration sensor circuit
45*1
(DI-479)Malfunction in deceleration sensorDeceleration sensor
Wire harness for deceleration sensor system
49
(DI-482)Open circuit in stop light switch circuitOpen in stop light circuit
51*2
(DI-484)
Pump motor is locked
Open in pump motor groundABS pump motor
Always
ON
(DI-485)Malfunction in ECU
IG power source circuitBattery
IC regulator
Open or short in power source circuit
Page 739 of 1807
DI-448
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
676 Author: Date:
1997 SUPRA (RM502U)
*1: Short ABS (2JZ-GTE Engine) only
*2: As DTC cannot be erased by replacing parts alone, do either of the following operations.
Clear DTC (See page DI-442).
At the vehicle speed of 20 km/h (12 mph), drive the vehicle for 30 sec. or more.
Page 740 of 1807
DI4V8-01
W02807
2JZ-GE:
2JZ-GTE:
2JZ-GTE:SPORT AVS (2JZ-GTE Engine):
ABS Control
Relay
ABS Solenoid
Relay
ABS Motor RelayABS ActuatorDeceleration Sensor
ABS Warning Light
ABS ECU
DLC1DLC2
Front Speed Sensor RotorRear Speed SensorRear Speed
Sensor Rotor
Front Speed Sensor
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
DI-449
677 Author: Date:
1997 SUPRA (RM502U)
PARTS LOCATION
Page 741 of 1807

DI7HM-01
W01411
1 2 3 4 5 6
7 8 9 10 11 121 2 3 4 5 6 7 8 9 10 11
12 13 14 15 16 17 18 19 20 21 22 A18
A19
DI-450
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
678 Author: Date:
1997 SUPRA (RM502U)
TERMINALS OF ECU
NORMAL ABS (2JZ-GE Engine):
Symbols (Terminal No.)STD Voltage (V)Condition
IG1 (A18-2) - GND (A19-2,13)10 - 14IG switch ON
SR (A19-18) - R+ (A19-8)Below 1.5IG switch ON, ABS warning light OFF
MR (A19-7) - R+ (A19-8)10 - 14IG switch ON
SFRH (A19-4) - GND (A19-2,13)10 - 14IG switch ON, ABS warning light OFF
SFRR (A19-1) - GND (A19-2,13)10 - 14IG switch ON, ABS warning light OFF
SFLH (A19-10) - GND (A19-2,13)10 - 14IG switch ON, ABS warning light OFF
SFLR (A19-11) - GND (A19-2,13)10 - 14IG switch ON, ABS warning light OFF
SRR (A19-22) - GND (A19-2,13)10 - 14IG switch ON, ABS warning light OFF
SRH (A19-21) - GND (A19-2,13)10 - 14IG switch ON, ABS warning light OFF
AST (A19-16) - GND (A19-2,13)10 - 14IG switch ON, ABS warning light OFF
WA (A18 4) GND (A19 2 13)Below 2.0IG switch ON, ABS warning light ONWA (A18-4) - GND (A19-2,13)10 - 14IG switch ON, ABS warning light OFF
STP (A18 12) GND (A19 2 13)Below 1.5Stop light switch OFFSTP (A18-12) - GND (A19-2,13)8 - 14Stop light switch ON
D/G (A18-11) - GND (A19-2,13)10 - 14IG switch ON, ABS warning light OFF
MT (A19-9) - GND (A19-2,13)Below 1.5IG switch ON
Tc (A18-9) - GND (A19-2,13)10 - 14IG switch ON
Ts (A18-8) - GND (A19-2,13)10 - 14IG switch ON
FR+ (A19-3) - FR- (A19-14)AC generationIG switch ON
Slowly turn right front wheel
FL+ (A19-19) - FL- (A19-20)AC generationIG switch ON
Slowly turn left front wheel
RR+ (A18-1) - RR- (A18-7)AC generationIG switch ON
Slowly turn right rear wheel
RL+ (A18-3) - RL- (A18-10)AC generationIG switch ON
Slowly turn left rear wheel
Page 742 of 1807

W02803
1 2 3 4 5
6
7
8
9 10 11
121
2 3 4 5
6 7 8 9
10
11 12 13
14 15 16
17 18
19 20 21 22 A21
A20
23
24 25 26
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
DI-451
679 Author: Date:
1997 SUPRA (RM502U)
Sport ABS (2JZ-GTE Engine):
Symbols (Terminal No.)STD Voltage (V)Condition
IG1 (A20-13) - GND (A20-12,25)10 - 14IG switch ON
SR (A21-7) - R+ (A20-26)10 - 14IG switch ON, ABS warning light OFF
MR (A21-1) - R+ (A20-26)Below 1.0IG switch ON
SFRH (A20-2) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
SFRR (A20-1) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
SFLH (A21-5) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
SFLR (A21-6) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
SRRH (A21-11) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
SRRR (A21-12) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
SRLH (A20-15) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
SRLR (A20-14) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
AST (A21-4) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
WA (A20 11) GND (A20 12 25)Below 2.0IG switch ON, ABS warning light ONWA (A20-11) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
STP (A20 5) GND (A20 12 25)Below 1.5Stop light switch OFFSTP (A20-5) - GND (A20-12,25)8 - 14Stop light switch ON
D/G (A20-24) - GND (A20-12,25)10 - 14IG switch ON, ABS warning light OFF
MT (A21-10) - GND (A20-12,25)Below 1.5IG switch ON
Tc (A20-8) - GND (A20-12,25)10 - 14IG switch ON
Ts (A20-21) - GND (A20-12,25)10 - 14IG switch ON
FR+ (A21-3) - FR- (A21-9)AC generationIG switch ON
Slowly turn right front wheel
FL+ (A21-8) - FL- (A21-2)AC generationIG switch ON
Slowly turn left front wheel
RR+ (A20-10) - RR- (A20-23)AC generationIG switch ON
Slowly turn right rear wheel
RL+ (A20-22) - RL- (A20-9)AC generationIG switch ON
Slowly turn left rear wheel
FRO (A20-7) - GND (A20-12,25)Pulse generationVehicle driving at about 30 km/h (19 mph)
FLO (A20-20) - GND (A20-12,25)Pulse generationVehicle driving at about 30 km/h (19 mph)
RRO (A20-6) - GND (A20-12,25)Pulse generationVehicle driving at about 30 km/h (19 mph)
RLO (A20-19) - GND (A20-12,25)Pulse generationVehicle driving at about 30 km/h (19 mph)
GL1 (A20-4) - GND (A20-12,25)0.5 - 4.5 VIG switch ON
GL2 (A20-16) - GND (A20-12,25)0.5 - 4.5 VIG switch ON
VGS (A20-3) - GND (A20-12,25)4.5 - 5.5 VIG switch ON
Page 743 of 1807

DI4VA-01
DI-452
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
680 Author: Date:
1997 SUPRA (RM502U)
PROBLEM SYMPTOMS TABLE
If a normal code is displayed during the DTC check but the problem still occurs, check the circuits for each
problem symptom in the order given in the table below and proceed to the relevant troubleshooting page.
NOTICE:
When removing the ECU, turn the IG switch OFF.
SymptomsInspection CircuitSee page
ABS does not operate.
Only when 1. - 4. are all normal and the problem is still occurring, replace the ABS
ECU.
1. Check the DTC, reconfirming that the normal code is output.
2. IG power source circuit.
3. Speed sensor circuit.
4. Check the ABS actuator with a checker.
If abnormal, check the hydraulic circuit for leakage (See page DI-498).
DI-442
DI-475
DI-469
BR-66 or XXX
ABS does not operate
efficiently.
Only when 1. - 4. are all normal and the problem is still occurring, replace the ABS
ECU.
1. Check the DTC, reconfirming that the normal code is output.
2. Speed sensor circuit.
3. Stop light switch circuit.
4. Check the ABS actuator with a checker.
If abnormal, check the hydraulic circuit for leakage (See page DI-498).
DI-442
DI-469
DI-482
BR-66 or BR-66
ABS warning light
abnormal.1. ABS warning light circuit.
2. ABS ECU.DI-488
DTC check cannot be done.
Only when 1. and 2. are all normal and the problem is still occurring, replace the
ABS ECU.
1. ABS warning light circuit.
2. Tc terminal circuit.
DI-488
DI-494
Speed sensor signal check
cannot be done.1. Ts terminal circuit.
2. ABS ECU.DI-496XXX
Page 744 of 1807

DI4VB-01
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
DI-453
681 Author: Date:
1997 SUPRA (RM502U)
CIRCUIT INSPECTION
DTC 11, 12 ABS Solenoid Relay Circuit
CIRCUIT DESCRIPTION
This relay supplies power to each ABS solenoid. After the ignition switch is turned ON, if the initial check is
OK, the relay goes on.
DTC No.DTC Detecting ConditionTrouble Area
11
Conditions (1) and (2) continue for 0.2 sec. or more:
(1) ABS solenoid relay terminal (SR)
voltage: Below 1.5V
(2) Solenoid relay monitor terminal (AST)
voltage: 0 V
ABS solenoid relay
Open or short in ABS solenoid relay circuit
12
Conditions (1) and (2) continue for 0.2 sec. or more:
(1) ABS solenoid relay terminal (SR)
voltage: Battery positive voltage
(2) Solenoid relay monitor terminal (AST)
voltage: Battery positive voltage
ABS solenoid relay
B+ short in ABS solenoid relay circuit
Fail safe function:
If trouble occurs in the ABS solenoid relay circuit, the ECU cuts off current to the ABS solenoid relay and
prohibits ABS control.
