Page 1473 of 1807
SF-14
- SFI (2JZ-GTE)FUEL PUMP
1340 Author: Date:
1997 SUPRA (RM502U)
Fuel return hose
Fuel breather hose
2. INSTALL SERVICE HOLE COVER
3. INSTALL SPARE WHEEL
4. INSTALL SPARE WHEEL COVER
5. INSTALL FLOOR CARPET
6. CHECK FOR FUEL LEAKS
Page 1474 of 1807
SF0GN-01
P18725
Fuel Pressure Regulator
O - Ring
Cruise Control Actuator Cable
Throttle Body
Sub-Throttle
Position Sensor
Connector
Air Hose
Water Bypass HosePS Air HoseVacuum Sensing Hose
Gasket
Fuel Return Pipe
Gasket
Accelerator
Throttle Position Sensor Connector
EVAP Hose
Sub-Throttle Actuator Connector Gasket
Non-reusable part
- SFI (2JZ-GTE)FUEL PRESSURE REGULATOR
SF-15
1341 Author: Date:
1997 SUPRA (RM502U)
FUEL PRESSURE REGULATOR
COMPONENTS
Page 1475 of 1807
SF0GO-01
P11323
Fuel
Return
Pipe
Vacuum
Sensing
Hose
P11324
SF-16
- SFI (2JZ-GTE)FUEL PRESSURE REGULATOR
1342 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. REMOVE THROTTLE BODY
(See page SF-43)
2. DISCONNECT VACUUM SENSING HOSE FROM
FUEL PRESSURE REGULATOR
3. DISCONNECT FUEL RETURN PIPE FROM FUEL
PRESSURE REGULATOR
Remove the union bolt and 2 gaskets, and disconnect the re-
turn pipe from the pressure regulator.
CAUTION:
Put a shop rag under the pressure regulator.
Slowly loosen the union bolt.
4. REMOVE FUEL PRESSURE REGULATOR
(a) Remove the 2 bolts, and pull out the pressure regulator.
(b) Remove the O-ring from the pressure regulator.
Page 1476 of 1807
SF0GP-01
B02654
New O-Ring
P13049
Pressure
Regulator
New
O - Ring
Delivery
Pipe
CORRECT WRONGWRONG
P11324
- SFI (2JZ-GTE)FUEL PRESSURE REGULATOR
SF-17
1343 Author: Date:
1997 SUPRA (RM502U)
INSTALLATION
1. INSTALL FUEL PRESSURE REGULATOR
(a) Apply a light coat of gasoline to a new O-ring, and install
it to the pressure regulator.
(b) Attach the pressure regulator to the delivery pipe.
(c) Check that the pressure regulator rotates smoothly.
NOTICE:
If it does not rotate smoothly, the O-ring may be pinched,
so remove the pressure regulator and do steps (b) and (c)
above again.
(d) Install the pressure regulator with the 2 bolts.
Torque: 9.0 N´m (90 kgf´cm, 80 in.´lbf)
2. CONNECT FUEL RETURN PIPE TO FUEL PRESSURE
REGULATOR
Install the return pipe with 2 new gaskets and the union bolt.
Torque: 28 N´m (280 kgf´cm, 21 ft´lbf)
3. CONNECT VACUUM SENSING HOSE TO FUEL
PRESSURE REGULATOR
4. INSTALL THROTTLE BODY
(See page SF-48)
5. CHECK FOR FUEL LEAKS
(See page SF-1)
Page 1477 of 1807

P11358Sound Scope
SF0GQ-01
P11359
P11416
Ohmmeter SF-18
- SFI (2JZ-GTE)INJECTOR
1344 Author: Date:
1997 SUPRA (RM502U)
INJECTOR
ON-VEHICLE INSPECTION
1. INSPECT INJECTOR OPERATION
Check operation sound from each injector.
(1) With the engine running or cranking, use a sound
scope to check that there is normal operating noise
in proportion to engine speed.
(2) If you have no sound scope, you can check the in-
jector transmission operation with your finger.
If no sound is heard or unusual vibration is felt, check the wiring
connector, injector or injection signal from the ECM.
2. INSPECT INJECTOR RESISTANCE
(a) Disconnect the throttle body without disconnecting the
water bypass hoses from the air intake chamber.
(See page SF-42)
(b) Disconnect the 6 injector connectors.
(c) Using an ohmmeter, measure the resistance between the
injector terminals.
Resistance: Approx. 1.95 W at 20°C (68°F)
If the resistance is not as specified, replace the injector.
(d) Reconnect the 6 injector connectors.
(e) Reinstall the throttle body to the air intake chamber.
(See page SF-48)
Page 1478 of 1807

SF0GR-01
S04780
Engine Wire
Protector
Air Intake Chamber Stay
IAC Valve Connector
VSV Connector for EGR
Turbo Pressure Sensor Connector
VSV Connector for Fuel Pressure Control
Water Bypass HoseControl Cable Bracket and Cable
Vacuum HoseIAC Valve Pipe
EVAP Hose
Gasket
EGR Pipe
Brake Booster
Vacuum Hose
Engine
Wire
Protector
Engine Wire Bracket
Engine Wire ClampGround
Cable
EGR Gas Temperature
Sensor Connector
Manifold Stay
No.4 Water Bypass Pipe
Water Bypass Hose Air Intake
Chamber
PS Air Hose Injector Connector
Engine Wire
Clamp
InsulatorInjector O - Ring
Vacuum Sensing Hose
Spacer
Delivery Pipe
Fuel Return Pipe
Sub-Throttle Position
Sensor ConnectorInjector Holder
x3
Fuel Inlet Pipe
PCV Hose
Oil Dipstick and Guide for A/T Gasket
Gasket
Air Hose
PS Air Hose
Water Bypass Hose
Sub - Throttle Actuator
Connector
Engine Under Cover Gasket Insulator
Spacer
Fuel Return Hose Throttle Body
Throttle Position
Sensor ConnectorOil Dipstick and Guide
for Engine O - Ring
O - Ring Gasket
Gasket
Non - reusable part
- SFI (2JZ-GTE)INJECTOR
SF-19
1345 Author: Date:
1997 SUPRA (RM502U)
COMPONENTS
Page 1479 of 1807

SF0GS-02
P12565
Pull
O-Ring
S00910
Engine Wire Clamp
O-Ring
Pull
Fuel
Return
Hose
P11322
Chamber
StagCable
Bracket
P11321(1) (2) (3)(4) SF-20
- SFI (2JZ-GTE)INJECTOR
1346 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. REMOVE ENGINE UNDER COVER
2. REMOVE THROTTLE BODY
(See page SF-43)
3. REMOVE OIL DIPSTICK AND GUIDE FOR A/T
(a) Remove the bolt.
(b) Pull out the dipstick guide together with the dipstick.
HINT:
At the time of installation, please refer to the following items.
Apply clean transmission oil to the O-ring, and push in the dip-
stick guide.
(c) Remove the O-ring from the dipstick guide.
HINT:
At the time of installation, please refer to the following items.
Use a new O-ring.
4. REMOVE OIL DIPSTICK AND GUIDE FOR ENGINE
(a) Disconnect the fuel return hose from the clamp of the dip-
stick guide.
(b) Remove the bolt.
(c) Pull out the dipstick guide together with the dipstick.
HINT:
At the time of installation, please refer to the following items.
Apply clean engine oil to the O-ring, and push in the dipstick
guide.
(d) Remove the O-ring from the dipstick guide.
HINT:
At the time of installation, please refer to the following items.
Use a new O-ring.
5. REMOVE AIR INTAKE CHAMBER STAY
Remove the bolt, nut and chamber stay.
Torque: 19 N´m (195 kgf´cm, 14 ft´lbf)
6. DISCONNECT CONTROL CABLE BRACKET FROM
AIR INTAKE CHAMBER
Remove the 2 bolts, and disconnect the cable bracket from the
air intake chamber.
Torque: 19 N´m (195 kgf´cm, 14 ft´lbf)
7. DISCONNECT CONNECTORS AND HOSES
(a) Disconnect these connectors:
(1) IAC valve connector
(2) Turbo pressure sensor connector
(3) VSV connector for fuel pressure control
(4) VSV connector for EGR
Page 1480 of 1807

P11991
P11317
(1)
(2)
(3) Clamp
P11318(4)
(5)
S04464
(10)
(8)
(6)(7)(9) (11)
S04463
EGR Gas
Temperature
Sensor
Connector
EGR Pipe
- SFI (2JZ-GTE)INJECTOR
SF-21
1347 Author: Date:
1997 SUPRA (RM502U)
(b) Remove the bolt, and disconnect the engine wire protec-
tor from the body.
(c) Disconnect these hoses:
(1) Air hose from IAC valve
Disconnect the IAC valve pipe from the clamp on
the cylinder head cover, and disconnect the air hose
from the IAC valve.
(2) Air hose (from air intake chamber) from
vacuum pipe on IAC valve pipe
(3) Air hose for EGR from valve pipe
(4) PCV hose from PCV valve
(5) Vacuum sensing hose from fuel pressure
regulator
(6) Water bypass hose (from IAC valve) from No.4 wa-
ter bypass pipe
(7) EVAP hose (from air intake chamber) from
vacuum pipe on manifold stay
(8) EVAP hose (from vacuum pipe on No.4 water
bypass pipe) from No.2 vacuum pipe
(9) EVAP hose (from charcoal canister) from No.2
vacuum pipe
(10) PS air hose from air intake chamber
(11) Brake booster vacuum hose from union on air in-
take chamber
8. DISCONNECT EGR GAS TEMPERATURE SENSOR
CONNECTOR
(a) Disconnect the connector from the No.2 vacuum pipe.
(b) Disconnect the sensor connector from the wiring connec-
tor.
9. REMOVE EGR PIPE
(a) Remove the union bolt holding the EGR pipe to the EGR
valve.
Torque: 64 N´m (650 kgf´cm, 47 ft´lbf)
