Page 297 of 1807
N19392
A
BC
A-A
B-B
C-C A
BC
H
HH
- BODYQUARTER WINDOW GLASS
BO-41
2121 Author: Date:
1997 SUPRA (RM502U)
5. APPLY ADHESIVE
(a) Cut off the tip of the cartridge nozzle.
Part No. 08850-00801 or equivalent
HINT:
After cutting off the tip, use all adhesive within the time de-
scribed in the table below.
TemperatureTackfree time
35 °C (95 °F)15 minute
20 °C (68 °F)100 minute
5 °C (41 °F)8 hour
(b) Load the cartridge into the sealer gun.
(c) Coat the glass with adhesive as shown.
H: 12 mm (0.47 in.)
6. INSTALL QUARTER WINDOW GLASS
(a) Install the 3 nuts and glass to the body.
7. INSPECT FOR LEAKS AND REPAIR
(a) Perform a leak test after the hardening time has elapsed.
(b) Seal any leak with sealant.
Part No. 08833-00030 or equivalent
8. INSTALL REMOVED PARTS IN REVERSE ORDER TO
REMOVAL ORDER
Page 298 of 1807
BO0QW-01
Z13437
Outside MouldingRear Wiper Arm and Blade
Back Door Glass
Back Door Opening Trim
Back Door Trim Board
Non-reusable part
11 (110, 8.0)
N´m (kgf´cm, ft´lbf)
: Specified torque BO-42
- BODYBACK DOOR GLASS
2122 Author: Date:
1997 SUPRA (RM502U)
BACK DOOR GLASS
COMPONENTS
Page 299 of 1807
BO0QX-01
N08507: 13 Clips
N08528
- BODYBACK DOOR GLASS
BO-43
2123 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. DISCONNECT DEFOGGER CONNECTOR
2. REMOVE THESE PARTS:
(a) Rear wiper arm and blade
(b) Back door trim board
(c) Back door opening trim
3. REMOVE BACK DOOR MOULDING
Using a knife, cut off the moulding as shown.
NOTICE:
Do not damage the body with the knife.
4. REMOVE BACK DOOR GLASS
HINT:
Remove the glass in the same manner as the windshield.
(See page BO-32)
Page 300 of 1807
BO0QY-01
N08529
N08533
Primer G
N08534
AdhesiveH BO-44
- BODYBACK DOOR GLASS
2124 Author: Date:
1997 SUPRA (RM502U)
INSTALLATION
HINT:
Refer to the installation of the windshield, install the back win-
dow glass by the following operations.
1. INSTALL BACK DOOR MOULDING
Place the moulding around the glass and install it by hand.
HINT:
Always remove the back door glass to install the moulding.
2. INSTALL BACK DOOR GLASS
(a) Coat contact surface of the glass with primer ºGº.
(b) Apply adhesive.
H: 12 mm (0.47 in.)
3. INSTALL THESE PARTS:
(a) Back door opening trim
(b) Back door trim board
(c) Rear wiper arm and blade
Torque: 11 N´m (110 kgf´cm, 8.0 ft´lbf)
4. CONNECT DEFOGGER CONNECTOR
Page 301 of 1807
BO0R5-01
N08518
Level
RH
Center
LH
RH/LH SideCenter
- BODYSPORT ROOF
BO-45
2125 Author: Date:
1997 SUPRA (RM502U)
SPORT ROOF
ON-VEHICLE INSPECTION
INSPECT REMOVABLE ROOF PANEL ALIGNMENT
(a) With the removable roof installed, check for water leak-
age.
(b) Check for a difference in clearance and level between the
removable roof panel and roof panel.
Clearance:
Front side: 6.0±1.5 mm (0.236±0.06 in.)
Rear side: 6.0±1.5 mm (0.236±0.06 in.)
Level: (Rear side)
RH/LH side: +1.5 ~ -2.0 mm (+ 0.06 ~-0.08 in.)
Center: +1.0 ~ -2.0 mm (+0.04 ~ -0.08 in.)
Zero level : upper surface of roof panel
Page 302 of 1807
BO0R6-01
N19394
Removable Roof Moulding RH
Roof Side Rail Weatherstrip RH
Removable Roof PanelShim
Bracket No.2 RH
Bracket No.2 LHShim
Roof Headlining
Removable Roof Lock
Roof Side Rail Weatherstrip LH
Removable Roof Moulding LH
Non-reusable part BO-46
- BODYSPORT ROOF
2126 Author: Date:
1997 SUPRA (RM502U)
COMPONENTS
Page 303 of 1807
BO0R7-01
- BODYSPORT ROOF
BO-47
2127 Author: Date:
1997 SUPRA (RM502U)
DISASSEMBLY
REMOVE THESE PARTS:
(a) Roof side rail weatherstrip
(b) Removable roof moulding
(c) Roof headlining
(d) Removable roof lock
(e) Bracket No.2
Page 304 of 1807
BO0R8-01
BO1839
BO1843
Shim BO-48
- BODYSPORT ROOF
2128 Author: Date:
1997 SUPRA (RM502U)
ADJUSTMENT
1. REMOVE ROOF HEADLINING
(a) Removable roof headlining - for clearance adjustment.
(b) Rear roof headlining - for level adjustment.
2. ADJUST CLEARANCE
Adjust the removable roof bracket by loosening the removable
roof bracket bolts.
If the clearance is not within the specification, repair the body
panel.
3. ADJUST LEVEL
Select the shim that makes the difference between the rear side
of removable roof panel and rear roof panel a minimum.
Shim thickness:
1.0 mm (0.039 in.)
2.0 mm (0.079 in.)
4. INSTALL ROOF HEADLINING
Installation is in the reverse order to removal.
