Page 369 of 1807

Manual Name
Pub. No.
(USA and CANADA)
SUPRA Repair Manual
Supra Electrical Wiring Diagram
Manual
1/2 SUPRA New Car Features
(Models except USA and CANADA)
SUPRA Chassis and Body Repair Manual
Supra Electrical Wiring Diagram
Manual
SUPRA New Car Features
(All Countries)
Fundamental Painting Procedures
Fundamental Body Repair ProceduresBRM024E
BRM002E NCF097E RM344E
EWD175Y NCF096U M/Y Version
M/Y Version
FOREWORD
This repair manual has been prepared to provide information on
the repair methods (including cutting and welding operations, but
excluding painting) for collision-damaged body components of the
TOYOTA SUPRA.
Applicable models: JZA80 series
This manual consists of body repair methods, exploded diagrams
and illustrations of the body components and other information re-
lating to body panel replacement such as handling precautions,
etc. However, it should be noted that the front fenders of the
TOYOTA models are bolted on and require no welding.
Body construction will sometimes differ depending on specifica-
tions and country of destination. Therefore, please keep in mind
that the information contained herein is based on vehicles for gen-
eral destinations.
For the repair procedures and specifications other than collisionda-
maged body components of the TOYOTA SUPRA refer to the fol-
lowing repair manuals.
If you require the above manuals, please contact your TOYOTA
Dealer.
All information contained in this manual is the most up-to-date at
the time of publication. However, specifications and procedures are
subject to change without prior notice.
TOYOTA MOTOR CORPORATION
Page 370 of 1807

mm in.
100
2003.94
7.87
QUARTER PANEL (CUT)
(Cut and Join Location)
Normal RoofBODY PANEL. REPLACEMENT RE-34
HOW TO USE THIS MANUAL
Each repair method description provided in Section RE of this manual comprises two pages, divided into
2 blocks (REMOVAL AND INSTALLATION) and includes illustrations to facilitate body repair.
REMOVAL
(Cut and Join Location)
(Cut and Join Location) 200 mm
Cut and Join Location
100 mm
Cut and Join
Location
(Cut and Join Location)
Sport Roof Cut and Join Location
(Cut Location for Supply Parts)
1. Cut and join the parts at the location shown above.
REPLACEMENT PARTS AND METHOD
(CUT)
QUARTER PANEL
Replacement method
(ASSY) Assembly replacement. . . . .
(CUT) Major cutting (less than 1/2 of parts used). . . . . .
(CUT-H) Half cutting (about 1/2 of parts used). . . .
(CUT-P) Partial cutting (most of parts used). . . .
Replacement parts
PARTS LOCATION
REMOVAL DIAGRAM
Describes in detail removal of the damaged parts involving repair by cutting.
REMOVAL GUIDE
Provides additional information to more efficiently help you perform the removal.
INTRODUCTIONIN-2
Page 371 of 1807

mm in.
50.20Normal Roof:
Sport Roof:
1. Before temporarily installing the new parts, apply
body sealer to the wheel arch.
HINT:1) Apply body sealer about 5 mm (0.20 in.) from the
flange, avoiding any oozing.
2) Apply sealer evenly, about 3 - 4 mm (0.12 - 0.16
in.) in diameter.
3) For other sealing points, refer to section AR.BODY PANEL REPLACEMENT
RE-36
INSTALLATION
Butt Weld
Butt Weld
Body Sealer
Butt Weld
Body Sealer
about 5 mm
2. Temporarily install the new parts and check the fit of
the front door, back door and rear combination lamp.
3. Apply foamed material to the pillar section.HINT: For the foamed material application areas, refer to
page AP-4.
INSTALLATION DIAGRAM
Describes in detail installation of the new parts involving repair by welding and/or cutting, but
excluding painting.
INSTALLATION GUIDE
Provides additional information to more efficiently help you perform the installation.
SYMBOLS
See page IN-4.
ILLUSTRATION OF WELD POINTS
Weld method and panel position symbols.
See page IN-5.
INTRODUCTIONIN-3
Page 372 of 1807
SYMBOLSMEANINGILLUSTRATION
SAW CUT OR
ROUGH CUT
REMOVE BRAZE
(See page IN-5) SPOT WELD OR
MIG PLUG WELD WELD POINTS
BRAZE CONTINUOUS MIG
WELD (BUTT WELD
OR TACK WELD)
BODY SEALER
SYMBOLS
The following symbols are used in the welding Diagrams in Section RE of this manual to indicate cutting
areas and the types of weld required.
INTRODUCTIONIN-4
Page 373 of 1807
Remove weld point and panel positionWeld points
REMOVAL
Weld method and panel positionWeld points
INSTALLATION
SYMBOL MEANING ILLUSTRATIONSYMBOL
Spot WeldMEANINGILLUSTRATION
Remove
Weld
Points
(Outside)
Mig Plug
Weld
(Middle)
(Inside)
Spot MIG
Weld
HINT: Panel position syrnbols are as seen from the
working posture.
Illustration of Weld Point Symbols
EXAMPLE:
INTRODUCTIONIN-5
Page 374 of 1807

Steering Wheel Pad
(with Airbag) Junction Block No. 1Center Airbag Sensor Assembly Front Airbag Sensor LHFront Passenger Airbag Assembly Front Airbag Sensor RHSRS Warning Light
Spiral Cable
Locations of SRS Components
HANDLING PRECAUTIONS ON RELATED COMPONENTS
1. SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
Servicing vehicle with a Supplemental Restraint System (referrerd to as the SRS in the remainder of this
manual) installed.
When handling SRS components (removal, installation or inspection, etc.), always follow the directions
given in the repair manual for the relevant model year to prevent the occurrence of accidents and airbag
malfunction.
Also take the following precautions when repairing the body:
Work must be started after 90 seconds or longer from the time the ignition switch is set to the LOCK
position and the negative (-) terminal cable is disconnected from the battery.
(The airbag system is equipped with a backup power source so that if work is started within 20 seconds
of disconnecting the negative (-) terminal cable of the battery, the airbag may be deployed.)
When the negative (-) terminal cable is disconnected from the battery, memory of the clock and audio
systems will be cancelled. So before starting work, make a record of the contents memorized by each
memory system. Then when work is finished, reset the clock and audio systems as before.
When the vehicle has tilt and telescopic steering, power seat, outside rear view mirror and power shoul-
der belt anchorage, which are all equipped with memory function, it is not possible to make a record of
the memory contents. So when the operation is finished, it will be necessary to explain this fact to the
customer, and request the customer to adjust the features and reset the memory.
When using electric welding, first disconnect the SRS connector (yellow color and 2 pins) under the
steering column near the combination switch connector on the glove compartment finish plate and lower
the front scuff plate before starting work.
INTRODUCTIONIN-6
Page 375 of 1807

Front Fender Area
Before repairing the body, remove the SRS parts if, during repair, shocks are likely to be applied to
the sensors due to vibrations of the body or direct tapping with tools or other parts.
Do not expose the SRS parts directly to hot air or flames.
NOTICE:
1) The maximum ambient temperature tolerance is 120
°C (248°F) for the front airbag sensor,
105
°C (221°F) for the center airbag sensor assembly and 93°C (200°F) for the steering wheel
pad, and front passenger airbag assembly. If it is possible that the ambient temperature may
reach or exceed the temperature limit, remove the sensors and the steering wheel pad from
the vihicle or protect them with a hot insulation material before starting work.
2) Prior to welding, remove adjacent SRS parts from the vehicle or protect there with fire-proof
covers.
If the front fender or periphery of the vehicle is damaged, visually inspect for damage to the front
airbag sensor using the inspection procedures described in section RS of the repair manual for the
relevant model year.
Also check that the dimensions of the body where the front airbag sensor is installed match those
in the body dimension drawings.
(The airbag may malfunction, or may not work, if the mounting angle or dimensions of the sensor
mount are not correct.)
If the vehicle is damaged, visually inspect for damage to the steering wheel pad using the inspection
procedures described in section RS of the repair manual for the relevant model year.
When removing or handling the steering wheel pad, and front passenger airbag assembly keep the
pad upper surface facing upward. Also, lock the lock lever of the twin lock type connector at the rear
of the pad and take care not to damage the connector.
(Storing the pad or front passenger airbag assembly with its metalic surface up may lead to a serious
accident if the airbag inflates for some reason.)
Store the steering wheel pad and the front passenger airbag assembly where the ambient tempera-
ture remains below 93°C (200°F), without high humidity and away from electrical noise.
Be careful not to let painting materials contact the SRS parts.
Information labels are attached to the periphery of the SRS components. Follow the NOTICES.
Store the airbag assembly where the ambient temperature remains below 93°C (200°F), without high
humidity and away from electrical noise.
INTRODUCTIONIN-7
Page 376 of 1807

Shift Lock ECUEngine Control
Module
(Engine ECU)Center Airbag
Sensor Assembly ABS
Deceleration
Sensor ABS and Traction ECU
(for 2JZ-GTE)Stereo Power
Amplifier Integration
RelayJ/B No. 1Traction ECU
(for 2JZ-GTE)
R/B No. 4 Daytime Running
Light Relay (Main)
(for Canada)Blower Control
RelayPPS ECU A/C AmplifierTheft Deterrent
ECU Cruise Control ECU Auto Antenna Control Relay
ABS ECU
(for 2JZ-GE)
Component to be alignedSection of repair manual
for relevant model year
Front Wheels
Suspension and Axle (SA) section
Rear Wheels
Suspension and Axle (SA) section
Propeller Shaft
Propeller Shaft (PR) section
3. DRIVE TRAIN AND CHASSIS2. BRAKE SYSTEM
The brake system is one of the most important safety components. Always follow the directions and
notes given in section BR of the repair manual for the relevant model year when handling brake
system parts.
NOTICE: When repairing the brake master cylinder or TRAC system, bleed the air out of the TRAC
system.
The drive train and chassis are components-that can have great effects on the running performance
and vibration resistance of the vehicle. After installing components in the sections listed in the table
below, perform alignments to ensure correct mounting angles and dimensions. Particularly accurate
repair of the body must also be done to ensure correct alignment.
HINT: Correct procedures and special tools are required for alignment. Always follow the directions
given in the repair manual for the relevant model year during alignment and section DI of this manual.
4. ECU (ELECTRONIC CONTROL UNIT)
Locations of ECUs
INTRODUCTIONIN-8
