Page 857 of 1807
R05898R14301H07910
P squibAirbag Sensor
Assembly
D squib
P
+
Spiral
Cable
DI-566
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
794 Author: Date:
1997 SUPRA (RM502U)
3 Check P squib circuit.
PREPARATION:
For the connector (on the airbag sensor assembly side) be-
tween the airbag sensor assembly and front passenger airbag
assembly, measure the resistance between P
+ and body
ground.
OK:
Resistance: 1 MW or higher
NG Repair or replace harness or connector be-
tween the airbag sensor assembly and front
passenger airbag assembly.
OK
Page 858 of 1807

AB0069R05902AB0118AB0119AB0057
AB0069
N19819H07911
P squibAirbag Sensor
Assembly
D squibSpiral
Cable
ACC
ON
or
E
1Tc DLC1
Code 11
P+P-
D+D-
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-567
795 Author: Date:
1997 SUPRA (RM502U)
4 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to airbag sensor assembly.
(b) Using a service wire, connect D
+ and D- on spiral cable
side of connector between spiral cable and steering
wheel pad.
(c) Using a service wire, connect P
+ and P- on airbag sensor
assembly side of connector between airbag sensor as-
sembly and front passenger airbag assembly.
(d) Connect negative (-) terminal cable to battery, and wait
at least 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON and wait at least 20
seconds.
(b) Clear malfunction code stored in memory.
(See page DI-557)
(c) Turn the ignition switch to LOCK, and wait at least 20 se-
conds.
(d) Turn the ignition switch to ACC or ON, and wait at least
20 seconds.
(e) Using SST, connect the terminals Tc and E
1 of DLC1.
SST 09843-18020
(f) Check DTC.
OK:
DTC 11 is not output.
HINT:
Codes other than code 11 may be output at this time, but they
are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 859 of 1807

H03221
P squibAirbag Sensor
Assembly
D squib
Spiral
Cable
ACC
ON
E
1Tc DLC1 Code 11or
DI-568
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
796 Author: Date:
1997 SUPRA (RM502U)
5 Check D squib.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least 90 seconds.
(c) Connect the steering wheel pad connector.
(d) Connect negative (-) terminal cable to battery, and wait
at least 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON and wait at least 20
seconds.
(b) Clear malfunction code stored in memory.
(See page DI-557)
(c) Turn the ignition switch to LOCK, and wait at least 20 se-
conds.
(d) Turn the ignition switch to ACC or ON, and wait at least
20 seconds.
(e) Using SST, connect the terminals Tc and E
1 of DLC1.
SST 09843-18020
(f) Check DTC.
OK:
DTC 11 is not output.
HINT:
Codes other than code 11 may be output at this time, but they
are not relevant to this check.
NG Replace steering wheel pad.
OK
Page 860 of 1807

H03222
P squib
Spiral
Cable
ACC
ON
E
1Tc DLC1 Code 11orAirbag Sensor
Assembly
D squib
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-569
797 Author: Date:
1997 SUPRA (RM502U)
6 Check P squib.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least 90 seconds.
(c) Connect the front passenger airbag assembly connector.
(d) Connect negative (-) terminal cable to battery, and wait
at least 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON, and wait at least
20 seconds.
(b) Clear malfunction code stored in memory.
(See page DI-557)
(c) Turn the ignition switch to LOCK, and wait at least 20 se-
conds.
(d) Turn the ignition switch to ACC or ON, and wait at least
20 seconds.
(e) Using SST, connect the terminals Tc and E
1 of DLC1.
SST 09843-18020
(f) Check DTC.
OK:
DTC 11 is not output.
HINT:
Codes other than code 11 may be output at this time, but they
are not relevant to this check.
NG Replace front passenger airbag assembly.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 861 of 1807
R05899R14301H07912
P squib
Spiral
CableAirbag Sensor
Assembly
D squib
D+
DI-570
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
798 Author: Date:
1997 SUPRA (RM502U)
7 Check spiral cable.
PREPARATION:
Disconnect the connector between airbag sensor assembly
and spiral cable.
CHECK:
Measure the resistance between D+ on spiral cable side of con-
nector between spiral cable and steering wheel pad and body
ground.
OK:
Resistance: 1 MW or higher
NG Repair or replace spiral cable.
OK
Repair or replace harness or connector be-
tween airbag sensor assembly and spiral
cable.
Page 862 of 1807

AB0119R05901R14288H07913
P squib
Spiral
CableAirbag Sensor
Assembly
D squib
ON
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-571
799 Author: Date:
1997 SUPRA (RM502U)
DTC 12 Short in Squib Circuit (to B+)
CIRCUIT DESCRIPTION
The squib circuit consists of the airbag sensor assembly, spiral cable, steering wheel pad and front passen-
ger airbag assembly. It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see FUNCTION OF COMPONENTS on page RS-2.
DTC 12 is recorded when a B+ short is detected in the squib circuit.
DTC No.DTC Detecting ConditionTrouble Area
12
Short circuit in squib wire harness (to B+).
Squib malfunction.
Spiral cable malfunction.
Airbag sensor assembly malfunction.Steering wheel pad (D squib)
Front passenger airbag assembly (P squib)
Spiral cable
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
Refer to page DI-564 for the WIRING DIAGRAM.
INSPECTION PROCEDURES
1 Preparation (See step 1 on page DI-595).
2 Check D squib circuit.
CHECK:
For the connector (on the spiral cable side) between the spiral
cable and steering wheel pad, measure the voltage between D
+
and body ground.
OK:
Voltage: 0 V
NG Go to step 7.
OK
DI4WL-01
Page 863 of 1807
AB0119R05898R14288H07914
P squib
Spiral
CableAirbag Sensor
Assembly
D squib
ON
P
+
(+)
(-)
DI-572
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
800 Author: Date:
1997 SUPRA (RM502U)
3 Check P squib circuit.
CHECK:
For the connector (on the airbag sensor assembly side) be-
tween airbag sensor assembly and front passenger airbag as-
sembly, measure the voltage between P
+ and body ground.
OK:
Voltage: 0 V
NG Repair or replace harness or connector be-
tween the airbag sensor assembly and front
passenger airbag assembly.
OK
Page 864 of 1807

AB0069R05902AB0069AB0118AB0119FI1389N19819H07915
P squibAirbag Sensor
Assembly
D squib
Spiral
Cable
ACC
ON
or
E
1
Tc DLC1
Code 12
P+P-
D+D-
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-573
801 Author: Date:
1997 SUPRA (RM502U)
4 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to airbag sensor assembly.
(b) Using a service wire, connect D
+ and D- on spiral cable
side of connector between spiral cable and steering
wheel pad.
(c) Using a service wire, connect P
+ and P- on airbag sensor
assembly side of connector between airbag sensor as-
sembly and front passenger airbag assembly.
(d) Connect negative (-) terminal cable to battery, and wait
at least 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON and wait at least 20
seconds.
(b) Clear malfunction code stored in memory.
(See page DI-557)
(c) Turn the ignition switch to LOCK, and wait at least 20 se-
conds.
(d) Turn the ignition switch to ACC or ON, and wait at least
20 seconds.
(e) Using SST, connect the terminals Tc and E
1 of DLC1.
SST 09843-18020
(f) Check DTC.
OK:
DTC 12 is not output.
HINT:
Codes other than code 12 may be output at this time, but they
are not relevant to this check.
+
NG Replace airbag sensor assembly.
OK
