Page 529 of 1807

CO0ZY-01
Z07402
Drain Plug
Drain Plug CO-2
- COOLINGCOOLANT
1415 Author: Date:
1997 SUPRA (RM502U)
REPLACEMENT
1. DRAIN ENGINE COOLANT
(a) Remove the radiator cap.
CAUTION:
To avoid the danger of being burned, do not remove the ra-
diator cap while the engine and radiator are still hot, as fluid
and steam can be blown out under pressure.
(b) Loosen the 2 drain plugs (for the engine and radiator),
and drain the coolant.
HINT:
To prevent the coolant from spraying over the cylinder block,
connect the rubber hose (inside diameter 6 - 8 mm) in the mar-
ket to the union pipe under.
(c) Close the drain plugs.
Torque:
Engine drain plug
29 N´m (300 kgf´cm, 22 ft´lbf)
2. FILL ENGINE COOLANT
(a) Slowly fill the system with coolant.
Use a good brand of ethylene-glycol base coolant
and mix it according to the manufacturer's direc-
tions.
Using coolant which includes more than 50 % ethyl-
ene-glycol (but not more than 70 %) is recom-
mended.
NOTICE:
Do not use an alcohol type coolant.
The coolant should be mixed with demineralized wa-
ter or distilled water.
Capacity (w/ Heater):
M/TA/T
2JZ-GE7.3 liters
(7.7 US qts, 6.4 lmp. qts)8.3 liters
(8.8 US qts, 7.3 lmp. qts)
2JZ-GTE8.9 liters
(9.4 US qts, 7.8 lmp. qts)8.8 liters
(9.3 US qts, 7.7 lmp. qts)
(b) Install the radiator cap.
(c) Start the engine, and bleed the cooling system.
(d) Refill the reservoir with coolant until it reaches the
ºFULLº line.
3. CHECK ENGINE COOLANT FOR LEAKS
Page 530 of 1807
CO08L-02
- COOLINGWATER PUMP
CO-3
1416 Author: Date:
1997 SUPRA (RM502U)
WATER PUMP
COMPONENTS
Page 531 of 1807
CO-4
- COOLINGWATER PUMP
1417 Author: Date:
1997 SUPRA (RM502U)
Page 532 of 1807
B01771
Air Cleaner and MAF Meter Assembly
No.1 Air Hose
Air Cleaner Duct
Upper Radiator Support
Radiator Assembly
Radiator Reservoir Hose
Electric Cooling
Fan Connector
ECT Switch
Connector
No.2 Fan Shroud
No.2 Air Tube Lower
Radiator
Support
Hose Clamp
Oil Cooler Tube
Engine Under Cover Drive Belt
A/T
x 16Battery
Insulator
Water Pump Pulley
Fan and Fluid Coupling Assembly
PS Pump Pulley
Battery Tray
Battery
MAF Meter Connector
Hold-Down
Clamp
2JZ-GTE
- COOLINGWATER PUMP
CO-5
1418 Author: Date:
1997 SUPRA (RM502U)
Page 533 of 1807
B01432
No.2 Timing Belt CoverDrive Belt Tensioner
No.1 Timing Belt Cover
Crankshaft PulleyOil Filler Cap
x 10
Timing Belt
Timing Belt Guide
No.2 Water Bypass Pipe
Idler PulleyGasket
Drain Hose Water Pump
x 5
Dust Boot Gasket
O-Ring
O-Ring Gasket Thermostat
Timing Belt Tensioner
Generator Connector Generator Wire
Generator
Bracket (A/T) Water Inlet and Lower
Radiator Hose Assembly
Precoated part
Non-reusable part
6 x 2JZ-GTE
Gasket
Water Outlet
ECT Sender
Gauge Connector
ECT Sensor ConnectorTurbo Water Hose Drive Belt
Tension Damper
No.3 Timing Belt Cover
No.3 Turbo Water Hose Gasket
No.1 Water Bypass Pipe
M/T
CO-6
- COOLINGWATER PUMP
1419 Author: Date:
1997 SUPRA (RM502U)
Page 534 of 1807

CO08M-02
P12278
P12300Turn
- COOLINGWATER PUMP
CO-7
1420 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. 2JZ-GTE:
REMOVE NO.1 AIR HOSE
2. 2JZ-GE:
REMOVE AIR CLEANER, MAF METER AND INTAKE
AIR CONNECTOR PIPE ASSEMBLY
(See page EM-57)
3. 2JZ-GTE:
REMOVE AIR CLEANER AND MAF METER
ASSEMBLY (See page EM-58)
4. REMOVE RADIATOR ASSEMBLY
(See page CO-22)
5. 2JZ-GTE M/T:
REMOVE DRIVE BELT TENSIONER DAMPER
(See page EM-15)
6. REMOVE DRIVE BELT, FAN, FLUID COUPLING
ASSEMBLY AND WATER PUMP PULLEY
(a) Loosen the 4 nuts holding the fluid coupling to the water
pump.
(b) Loosen the drive belt tension by turning the drive belt ten-
sioner clockwise, and remove the drive belt.
(c) Remove the 4 nuts, the fan, fluid coupling assembly and
water pump pulley.
7. REMOVE WATER INLET, LOWER RADIATOR HOSE
ASSEMBLY AND THERMOSTAT
(See page CO-14)
8. REMOVE TIMING BELT
(2JZ-GE: See page EM-13)
(2JZ-GTE: See page EM-15)
9. REMOVE IDLER PULLEY
(2JZ-GE: See page EM-13)
(2JZ-GTE: See page EM-15)
10. 2JZ-GTE:
DISCONNECT TURBO WATER HOSES FROM
WATER OUTLET
Page 535 of 1807

Z16746
O-Ring
Water Bypass Outlet
NO.1 Water
Bypass Pipe 2JZ-GE
Z16764
2JZ-GTE
Z16745
2JZ-GE
Z16930
2JZ-GE
No.2 Water Bypass Pipe
2JZ-GTE
No.2 Water Bypass Pipe
No.3 Turbo Water Hose
CO-8
- COOLINGWATER PUMP
1421 Author: Date:
1997 SUPRA (RM502U)
11. 2JZ-GE:
REMOVE WATER BYPASS OUTLET AND NO.1
WATER BYPASS PIPE
(a) Remove the 2 bolts, water bypass outlet and No.1 water
bypass pipe.
(b) Remove the 3 O-rings from the water bypass outlet and
No.1 water bypass pipe.
12. 2JZ-GTE:
REMOVE WATER OUTLET AND NO.1 WATER
BYPASS PIPE
(a) Disconnect the ECT sensor and sender gauge connec-
tors.
(b) Remove the 2 bolts, water outlet and gasket.
(c) Remove the No.1 water bypass pipe and 2 O-rings.
13. REMOVE WATER PUMP
(a) Loosen the nut and remove the bolt, and slightly slide the
generator from the water pump.
(b) 2JZ-GE:
Remove the bolt, and disconnect the clamp bracket.
(c) 2JZ-GE:
Remove the bolt, and disconnect the connector bracket
(for crankshaft position sensor connector).
(d) Remove the 2 nuts, and disconnect the No.2 water by-
pass pipe from the water pump.
(e) 2JZ-GTE:
Disconnect the No.3 turbo water hose from the water
pump.
Page 536 of 1807
P25846
Drain Hose
- COOLINGWATER PUMP
CO-9
1422 Author: Date:
1997 SUPRA (RM502U)
(f) Remove the 6 bolts, water pump and gasket.
(g) Remove the drain hose.
(h) Remove the O-ring from the cylinder block.
