1997 TOYOTA SUPRA Service Repair Manual

Page 465 of 1807

TOYOTA SUPRA 1997  Service Repair Manual RADIATOR UPPER SUPPORT (ASSY)
REMOVAL
BODY PANEL REPLACEMENTRE-2

Page 466 of 1807

TOYOTA SUPRA 1997  Service Repair Manual INSTALLATION
1. Temporarily install the new parts and mea-
sure each part in accordance with the body
dimension diagram.
HINT: First install the hood lock support.
BODY PANEL REPLACEMENTRE-3

Page 467 of 1807

TOYOTA SUPRA 1997  Service Repair Manual REAR FLOOR PAN TO QUARTER PANEL
EXTENSION (ASSY)
REMOVAL (With the body lower back panel removed.)
(Right Side)
(Left Side)
1. Push down on the rear floor pan to quarter
panel extension and remove it.

Page 468 of 1807

TOYOTA SUPRA 1997  Service Repair Manual (Left Side)
INSTALLATION
(Right Side)
BODY PANEL REPLACEMENTRE-57

Page 469 of 1807

TOYOTA SUPRA 1997  Service Repair Manual mm in.
20
0.79
REAR FLOOR SIDE REAR MEMBER (ASSY)
20 mm
REMOVAL (With the rear floor pan and rear floor pan to
quarter panel extension removed.)
Cut and Join Location
(Rear Floor Side Member
Reinforce

Page 470 of 1807

TOYOTA SUPRA 1997  Service Repair Manual mm in.
25 0.98
INSTALLATION
LH:
Butt Weld
(Rear Floor Side Member
Reinforcement)
Assembly Mark
Tack Weld
(25 mm each)
1. When temporarily installing the new parts,
determine the installation position

Page 471 of 1807

TOYOTA SUPRA 1997  Service Repair Manual REAR FLOOR NO. 2 CROSSMEMBER (ASSY)
REMOVAL
BODY PANEL REPLACEMENTRE-60

Page 472 of 1807

TOYOTA SUPRA 1997  Service Repair Manual INSTALLATION
1. Temporarily install the new parts and measure
each part in accordance with the body dimen-
sion diagram.
BODY PANEL REPLACEMENTRE-61
