Page 1361 of 1807
EM-8
- ENGINE MECHANICAL (2JZ-GTE)VALVE CLEARANCE
111 3 Author: Date:
1997 SUPRA (RM502U)
10. RECONNECT ENGINE WIRE PROTECTOR TO NO.4
TIMING BELT COVER
11. REINSTALL IAC VALVE PIPE
12. RECONNECT ENGINE WIRE PROTECTOR TO COWL
TOP PANEL
13. REINSTALL IGNITION COILS ASSEMBLIES
(See page IG-7)
Page 1362 of 1807
V00719
Adjusting Shim Selection Chart (Intake)
New shim thickness mm (in.)
Installed shim thickness
Measured clearance
mm (in.)mm (in.)
Shim
No.Thickness ThicknessShim
No.
HINT: New shims have the thickness in
millimeters imprinted on the face. Intake valve clearance (Cold):
0.15 - 0.25 mm (0.006 - 0.010 in.)
EXAMPLE: The 2.800 mm (0.1102 in.) shim is installed, and
the measured clearance is 0.450 mm (0.0177 in.)
Replace the 2.800 mm (0.1102 in.) shim with a new No.12 shim.
- ENGINE MECHANICAL (2JZ-GTE)VALVE CLEARANCE
EM-9
111 4 Author: Date:
1997 SUPRA (RM502U)
Page 1363 of 1807
V00720
Adjusting Shim Selection Chart (Exhaust)
New shim thickness mm (in.)
Installed shim thickness
Measured clearance
mm (in.)mm (in.)
Shim
No.Thickness ThicknessShim
No.
HINT: New shims have the thickness in
millimeters imprinted on the face. Exhaust valve clearance (Cold):
0.25 - 0.35 mm (0.010 - 0.014 in.)
EXAMPLE: The 2.800 mm (0.1102 in.) shim is installed, and
the measured clearance is 0.450 mm (0.0177 in.)
Replace the 2.800 mm (0.1102 in.) shim with a new No.10 shim.
EM-10
- ENGINE MECHANICAL (2JZ-GTE)VALVE CLEARANCE
111 5 Author: Date:
1997 SUPRA (RM502U)
Page 1364 of 1807

EM0AF-02
A02173
Sensor
Inward
Part
P18867
A02168
10 mm
Hexagon WrenchAdhesive
A02171
A02172
- ENGINE MECHANICAL (2JZ-GTE)TIMING BELT
EM-21
1126 Author: Date:
1997 SUPRA (RM502U)
INSTALLATION
1. INSTALL CRANKSHAFT TIMING PULLEY
(a) Align the pulley set key with the key groove of the pulley.
(b) Slide on the timing pulley facing the flange side inward.
NOTICE:
Do not scratch the sensor part of the crankshaft timing
pulley.
(c) Install the timing belt plate with the bolt.
Torque: 7.8 N´m (80 kgf´cm, 69 in.´lbf)
2. INSTALL IDLER PULLEY
(a) Apply adhesive to 2 or 3 threads of the pivot bolt.
Adhesive:
Part No. 08833-00080, THREE BOND 1344,
LOCTITE 242 or equivalent
(b) Using a 10 mm hexagon wrench, install the plate washer
and pulley with the pivot bolt.
Torque: 35 N´m (350 kgf´cm, 26 ft´lbf)
(c) Check that the pulley bracket moves smoothly.
3. TEMPORARILY INSTALL TIMING BELT
NOTICE:
The engine should be cold.
(a) Using the crankshaft pulley bolt, turn the crankshaft, and
align the timing marks on the crankshaft timing pulley and
on the oil pump body.
(b) Remove any oil or water on the crankshaft timing pulley
and idler pulley, and keep them clean.
(c) Install the timing belt on the crankshaft timing pulley and
idler pulley.
HINT:
(When re-using timing belt):
Align the match marks of the crankshaft timing pulley and timing
belt, and install the belt with the arrow pointing in the direction
of engine revolution.
Page 1365 of 1807

S00263
S00268
SST
SST
P03960
A02559
SST
S00394
EM-22
- ENGINE MECHANICAL (2JZ-GTE)TIMING BELT
1127 Author: Date:
1997 SUPRA (RM502U)
4. INSTALL TIMING BELT GUIDE
Install the guide, facing the cup side outward.
5. INSTALL NO.1 TIMING BELT COVER
6. INSTALL CRANKSHAFT PULLEY
(a) Align the pulley set key with the key groove of the pulley,
and slide on the pulley.
(b) Using SST, install the bolt.
SST 09213-70010, 09330-00021
Torque: 324 N´m (3,300 kgf´cm, 239 ft´lbf)
7. A/T:
CONNECT OIL COOLER TUBES
8. INSTALL CAMSHAFT TIMING PULLEYS
(a) Align the camshaft knock pin with the groove of the pulley,
and slide on the timing pulley.
(b) Temporarily install the timing pulley bolt.
(c) Using SST, tighten the pulley bolt.
SST 09960-10010 (09962-01000, 09963-01000)
Torque: 79 N´m (810 kgf´cm, 59 ft´lbf)
9. SET NO.1 CYLINDER TO TDC/COMPRESSION
(a) Turn the crankshaft pulley, and align its groove with timing
mark º0º of the No.1 timing belt cover.
NOTICE:
Always turn the crankshaft clockwise.
Page 1366 of 1807

A02558SST
A02562
Z02446
1.5 mm
Hexagon
Wrench
P04459
P11756
- ENGINE MECHANICAL (2JZ-GTE)TIMING BELT
EM-23
1128 Author: Date:
1997 SUPRA (RM502U)
(b) Using SST, align the timing marks of the camshaft timing
pulleys and No.4 timing belt cover.
SST 09960-10010 (09962-01000, 09963-01000)
10. INSTALL TIMING BELT
HINT:
(When re-using timing belt):
Align the matchmarks of the timing belt and camshaft timing
pulleys.
(a) Remove any oil or water on the camshaft timing pulley,
and keep it clean.
(b) Install the timing belt, checking the tension between the
crankshaft timing pulley and exhaust camshaft timing
pulley.
11. SET TIMING BELT TENSIONER
(a) Using a press, slowly press in the push rod using 981 -
9,807 N (100 - 1,000 kgf, 220 - 2,205 lbf) of force.
(b) Align the holes of the push rod and housing, pass a 1.5
mm hexagon wrench through the holes to keep the push
rod retracted.
(c) Release the press.
(d) Install the dust boot onto the tensioner.
12. INSTALL TIMING BELT TENSIONER
(a) Temporarily install the tensioner with the 2 bolts.
(b) Alternately tighten the 2 bolts.
Torque: 26 N´m (270 kgf´cm, 20 ft´lbf)
Page 1367 of 1807

P02587
P02154
P11647
S00259
SST
A
BA EM-24
- ENGINE MECHANICAL (2JZ-GTE)TIMING BELT
1129 Author: Date:
1997 SUPRA (RM502U)
(c) Remove the 1.5 mm hexagon wrench from the tensioner.
13. CHECK VALVE TIMING
(a) Slowly turn the crankshaft pulley 2 revolutions from TDC
to TDC.
NOTICE:
Always turn the crankshaft clockwise.
(b) Check that each pulley aligns with the timing marks as
shown in the illustration.
If the marks do not align, remove the timing belt and reinstall it.
14. INSTALL DRIVE BELT TENSIONER
Install the tensioner with the 3 bolts.
Torque: 21 N´m (210 kgf´cm, 15 ft´lbf)
NOTICE:
Be careful not to drop the bolts inside the timing belt cover.
15. INSTALL NO.2 TIMING BELT COVER
16. INSTALL NO.3 TIMING BELT COVER
17. INSTALL PS PUMP
(a) Temporarily install the pump pulley with the nut.
(b) Using SST, tighten the pulley nut.
SST 09960-10010 (09962-01000, 09963-01000)
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
18. INSTALL WATER PUMP PULLEY, FAN, FLUID
COUPLING ASSEMBLY AND DRIVE BELT
(See page CO-1 1)
19. M/T:
INSTALL DRIVE BELT TENSIONER DAMPER
Torque: 20 N´m (200 kgf´cm, 14 ft´lbf)
20. INSTALL RADIATOR ASSEMBLY
(See page CO-28)
21. ROAD TEST
Check for abnormal noise, shock, slippage, correct shift points
and smooth operation.
Page 1368 of 1807

B00319
Recommended Viscosity (SAE):
TEMPERATURE RANGE ANTICIPATED BEFORE NEXT OIL CHANGE °F
°C-20
-29 0
-1820
-740
460
1680
27100
38 10W-30
5W-30 PREFERRED
2JZ-GE
Z09522
Recommended Viscosity (SAE):
10W - 30
5W - 30
-20
-29 -18 -7 4 16 27
38 0 20 40 60 80 100
°C °F
TEMPERATURE RANGE ANTICIPATED BEFORE NEXT OIL CHANGE
2JZ-GTE
LU0JY-01
Z13413
2JZ-GTE
Z16754
2JZ-GTE M/T
P11837
- LUBRICATIONOIL AND FILTER
LU-1
1448 Author: Date:
1997 SUPRA (RM502U)
OIL AND FILTER
INSPECTION
1. CHECK OIL QUALITY
Check the oil for deterioration, entry of water, discoloring or thin-
ning.
If oil quality is visibly poor, replace the oil.
Oil grade (2JZ-GE):
API grade SH Energy-Conserving II or SJ, Energy-
Conserving or ILSAC multigrade engine oil.
SAE 5W-30 is the best choice for your vehicle, for
good fuel economy, and good starting in cold weath-
er.
Oil grade (2JZ-GTE):
API grade SH Energy-Conserving II or SJ, Energy-
Conserving or ILSAC multigrade engine oil.
Recommended viscosity is as shown in the illustra-
tion.
2. CHECK ENGINE OIL LEVEL
The oil level should be between the low level and full level marks
on the dipstick.
If low, check for the leakage and add oil up to full level mark.
3. REMOVE ENGINE UNDER COVER
4. 2JZ-GTE:
REMOVE NO.2 AIR TUBE
Loosen the 2 hose clamps, and remove 2 bolts and air tube.
5. 2JZ-GTE M/T:
REMOVE DRIVE BELT TENSION DAMPER
Remove the 2 nuts and tensioner damper.
6. REMOVE DRIVE BELT
Loosen the drive belt tension by turning the drive belt tensioner
clockwise, and remove the drive belt.
