Page 761 of 1807
W02989
IB5
IB5
IB2
IB2
IC2
IC2A19 A21
8 Right Front
Speed Sensor2
1L R
EA3
14 9
198
2 20
110
723
322
109FR+
FR-ABS ECU
5V
FL+
FL-
RR+
RR-
RL+
RL- R
L
W
B
V
LG 1
2
4
5
L
P
3 W
B
V
LG 2
2
2 1
1
1 Left Front
Speed Sensor
Right Rear
Speed Sensor
Left Rear
Speed Sensor
*1
3
*2
A19A21
A19
A21
A19
A21
A18
A20
A18
A20
A18
A20
A18
A20 DI-470
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
698 Author: Date:
1997 SUPRA (RM502U)
WIRING DIAGRAM
*1: NORMAL ABS (2JZ-GE Engine)
*2: SPORT ABS (2JZ-GTE Engine)
Page 762 of 1807
F02629F03325F03327
LOCK
21
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
DI-471
699 Author: Date:
1997 SUPRA (RM502U)
INSPECTION PROCEDURE
1 Check speed sensor.
Front
PREPARATION:
(a) Remove front fender splash shield.
(b) Disconnect speed sensor connector.
CHECK:
Measure resistance between terminals 1 and 2 of speed sensor
connector.
OK:
Resistance: 0.6 - 2.5 kW
CHECK:
Measure resistance between terminals 1 and 2 of speed sensor
connector and body ground.
OK:
Resistance: 1 MW or higher
CHECK:
Check the sensor connector.
OK:
(1) There is not play on the connector connecting
part.
(2) Connectors are connected each other securely.
Page 763 of 1807
F02629F03326F03328
LOCK
1
2
DI-472
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
700 Author: Date:
1997 SUPRA (RM502U)
Rear
PREPARATION:
(a) Remove rear, seat cushion, seat back and quarter trim
panel.
(b) Disconnect speed sensor connector.
CHECK:
Measure resistance between terminals 1 and 2 of speed sensor
connector.
OK:
Resistance: 0.65 - 1.8 kW
CHECK:
Measure resistance between terminals 1 and 2 of speed sensor
connector and body ground.
OK:
Resistance: 1 MW or higher
CHECK:
Check the sensor connector.
OK:
(1) There is not play on the connector connecting
part.
(2) Connectors are connected each other securely.
NG Replace speed sensor.
NOTICE:
Check the speed sensor signal last (See page DI-442).
OK
2 Check for open and short in harness and connector between each speed sensor
and ABS ECU (See page IN-28).
NG Repair or replace harness or connector.
OK
Page 764 of 1807
F03329
R00948
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
DI-473
701 Author: Date:
1997 SUPRA (RM502U)
3 Check sensor rotor and sensor installation.
Front
PREPARATION:
Remove front speed sensor rotor (See page SA-12).
CHECK:
Check sensor rotor serrations.
OK:
No scratches, missing teeth or foreign objects.
CHECK:
Check the front speed sensor installation.
OK:
The installation bolt is tightened properly and there is
no clearance between sensor and steering knuckle.
CHECK:
Check the sensor tip.
OK:
No scratches or foreign objects on the sensor tip.
Rear
PREPARATION:
Remove the drive shaft (See page SA-43).
CHECK:
Check the sensor rotor serrations.
OK:
No scratches or missing teeth.
Page 765 of 1807
BR3795OK
NG
DI-474
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
702 Author: Date:
1997 SUPRA (RM502U)
CHECK:
Check the rear speed sensor installation.
OK:
The installation bolt is tightened properly and there is
no clearance between the sensor and rear axle carri-
er.
CHECK:
Check the sensor tip.
OK:
No scratches or foreign objects on the sensor tip.
NG Replace speed sensor and grease or rotor and
grease.
NOTICE:
Check the speed sensor signal last (See page DI-442).
OK
Check and replace ABS ECU.
Page 766 of 1807
F03330
Battery
B
R/B No.2
ALT
2222AM1 R/B No.2
WR/B No.1
W
2
IG Switch
J/B No.1ABS ECU
IG1
GND1
GND2 ECU IG
444
513 B-Y
1B1J1J 1K A18A20
213*1
*2
A20
A20 A19
A19212
13 25W-B
W-B W-B W-B
IG
IEW-B
*2
NORMAL ABS (2JZ-GE Engine)
SPORT ABS (2JZ-GTE Engine)*1:
*2:
W
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
DI-475
703 Author: Date:
1997 SUPRA (RM502U)
DTC 41 IG Power Source Circuit
CIRCUIT DESCRIPTION
This is the power source for the ECU, hence the CPU and the actuators.
DTC No.DTC Detecting ConditionTrouble Area
41Voltage at ECU terminal IG1 is less than 9.5 V for more than
10 sec. while vehicle speed is 3 km/h (1.9 mph) or more.Battery
IC regulator
Open or short in power source circuit
Fail safe function:
If trouble occurs in the power source circuit, the ECU cuts off current to the ABS solenoid relay and prohibits
ABS control.
WIRING DIAGRAM
DI4VF-01
Page 767 of 1807
F02629F03331F03332F03333
ON
NORMAL ABS
(2JZ-GE Enegine):
SPORT ABS
(2JZ-GTE Enegine):IG1GND
GND
IG1 (+)
(-)
(+)
(-)
DI-476
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
704 Author: Date:
1997 SUPRA (RM502U)
INSPECTION PROCEDURE
1 Check battery positive voltage.
OK:
Voltage: 10 - 14 V
NG Check and repair the charging system.
OK
2 Check voltage between terminals IG1 and GND of ABS ECU connector.
PREPARATION:
Remove ABS ECU with connectors still connected.
CHECK:
(a) Turn ignition switch ON.
(b) Measure voltage between terminals IG1 and GND of ABS
ECU connector.
OK:
Voltage: 10 - 14 V
OK Check and replace ABS ECU.
NG
Page 768 of 1807
F02629F03334F03335F03336
NORMAL ABS (2JZ-GE Engine):
SPORT ABS (2JZ-GTE Engine):
LOCK
GND
(+)
(-)
(+)
(-)GND
GND
GND
- DIAGNOSTICSANTI-LOCK BRAKE SYSTEM
DI-477
705 Author: Date:
1997 SUPRA (RM502U)
3 Check continuity between terminal GND of ABS ECU connector and body
ground.
CHECK:
Measure resistance between terminals GND of ABS ECU con-
nector and body ground.
OK:
Resistance: 1 W or less
NG Repair or replace harness or connector.
OK
