2. Instal l th e standar d shi m an d bearin g oute r rac e
int o th e transmissio n housin g usin g th e specia l
tools . Instal l th e bearin g oute r rac e squarely , an d
chec k tha t ther e i s n o clearanc e betwee n th e bear -
in g oute r race , shi m an d transmissio n housing .
CAUTION : D o no t us e mor e tha n on e shi m t o
adjus t th e bearin g preload .
DRIVER07749 - 001000 0
ATTACHMENT ,72 x 75 m m0774 6 - 001060 0
75 m m THRUS T SHIM : 3
. Lubricat e th e tapere d rolle r bearin g wit h transmis -
sio n oil , the n instal l th e differential .
4 . Instal l th e transmissio n housing . D o no t instal l th e
mainshaft , countershaft , an d revers e idl e gea r shaft .
Torque : 4 4 N- m (4. 5 kgf-m , 3 3 Ibf-ft )
5. Rotat e th e differentia l assembl y i n bot h direction s
t o sea t th e bearings .
6 . Measur e th e startin g torqu e o f th e differentia l
assembly wit h a specia l too l an d a torqu e wrench .
Measure th e bearin g preloa d a t norma l roo m tem -
peratur e in bot h directions .
Standard : 2. 0 - 3. 0 N- m (2 0 - 3 0 kgf-cm ,
17 - 2 6 lbf-in )
TORQU E WRENC H
DIFFERENTIA LINSPECTION TOOL S07MAJ - PR9010 0
7. I f th e bearin g preloa d i s no t withi n th e standard ,
selec t th e shi m tha t wil l giv e yo u th e correc t
preload , an d recheck .
Changin g on e o f th e shim s t o th e nex t siz e wil l
increas e o r decreas e preloa d abou t 0. 3 - 0. 4 N- m (3
- 4 kgf-cm , 2.6 0 - 3.4 7 Ibf-in) .
