Page 1345 of 2057

FORD KUGA 2011 1.G Workshop Manual Action Possible Sources Symptom • ADJUST the parking brakecable or switch REFER to: Parking Brake Cable Adjustment (206-05 Parking Brake and Actuation, General Procedures). • Incorrectly adjusted

Page 1346 of 2057

FORD KUGA 2011 1.G Workshop Manual Action Possible Sources Symptom • INSTALL new brake shoes orbrake pads. REFER to: Brake Pads (206-03 Front Disc Brake, Removal and Installation). • Worn or damaged brake shoes or brake pads. • B

Page 1347 of 2057

FORD KUGA 2011 1.G Workshop Manual DETAILS/RESULTS/ACTIONS TEST CONDITIONS A2: CHECK FOR BRAKE SYSTEM LEAKS 1 Check for external brake and clutch system leaks. Refer to Brake Master Cylinder Component Test in this procedure. • Are an

Page 1348 of 2057

FORD KUGA 2011 1.G Workshop Manual DETAILS/RESULTS/ACTIONS TEST CONDITIONS B2: CHECK FOR BRAKE SYSTEM LEAKS 1 Check for external brake system leaks. • Are any leaks present? zYe s REPAIR as necessary. ADD fluid and BLEED the brake s

Page 1349 of 2057

FORD KUGA 2011 1.G Workshop Manual DETAILS/RESULTS/ACTIONS TEST CONDITIONS 2 Using a suitable vacuum gauge, check the vacuum pressure. • Is the vacuum pressure above 40.5 kPa (0.4 bar) with the brake booster non-operational? zYe s V

Page 1350 of 2057

FORD KUGA 2011 1.G Workshop Manual DETAILS/RESULTS/ACTIONS TEST CONDITIONS D2: CHECK THE BRAKE BOOSTER FOR LEAKS 1 Run the engine at approximately 1000 rpm, release the accelerator pedal and turn the engine off. Wait 90 seconds and app

Page 1351 of 2057

FORD KUGA 2011 1.G Workshop Manual DETAILS/RESULTS/ACTIONS TEST CONDITIONS 2 Using a suitable vacuum gauge, check the vacuum pressure. • Is the vacuum pressure above 40.5 kPa (0.4 bar) with the brake booster non-operational? zYe s G

Page 1352 of 2057

FORD KUGA 2011 1.G Workshop Manual DETAILS/RESULTS/ACTIONS TEST CONDITIONS E2: CHECK THE BRAKE BOOSTER 1 Check the brake booster push rod alignment and travel. • Is the push rod and pedal travel OK? zYe s BLEED the brake system. REF
