INFINITI QX56 2008 Factory Service Manual WW-20 < COMPONENT DIAGNOSIS > FRONT WIPER MOTOR LO CIRCUIT 1. Turn the ignition switch ON. 2. Select "FRONT WIPER" of IPDM E/R active test item. 3. While operating the test item, check voltage between

Page 4018 of 4083

INFINITI QX56 2008 Factory Service Manual FRONT WIPER MOTOR HI CIRCUITWW-21 < COMPONENT DIAGNOSIS > C DE F G H I J K M A B WW N O P FRONT WIPER MOTOR HI CIRCUIT Component Function CheckINFOID:0000000001735581 1. CHECK FRONT WIPER HI OPERATION

Page 4019 of 4083

INFINITI QX56 2008 Factory Service Manual WW-22 < COMPONENT DIAGNOSIS > FRONT WIPER MOTOR HI CIRCUIT 1. Turn the ignition switch ON. 2. Select "FRONT WIPER" of IPDM E/R active test item. 3. While operating the test item, check voltage between

Page 4020 of 4083

INFINITI QX56 2008 Factory Service Manual FRONT WIPER AUTO STOP SIGNAL CIRCUITWW-23 < COMPONENT DIAGNOSIS > C DE F G H I J K M A B WW N O P FRONT WIPER AUTO ST OP SIGNAL CIRCUIT Component Function CheckINFOID:0000000001735583 1. CHECK FRONT W

Page 4021 of 4083

INFINITI QX56 2008 Factory Service Manual WW-24 < COMPONENT DIAGNOSIS > FRONT WIPER AUTO STOP SIGNAL CIRCUIT Check continuity between IPDM E/R harness connector and front wiper motor harness connector. Does continuity exist? YES >> Replace fr

Page 4022 of 4083

INFINITI QX56 2008 Factory Service Manual FRONT WIPER MOTOR GROUND CIRCUITWW-25 < COMPONENT DIAGNOSIS > C DE F G H I J K M A B WW N O P FRONT WIPER MOTOR GROUND CIRCUIT Diagnosis ProcedureINFOID:0000000001735585 1. CHECK FRONT WIPER MOTO R (G

Page 4023 of 4083

INFINITI QX56 2008 Factory Service Manual WW-26 < COMPONENT DIAGNOSIS > WASHER SWITCH WASHER SWITCH DescriptionINFOID:0000000001735586 • Washer switch is integrated with combination switch. • Combination switch switches polarity between f

Page 4024 of 4083

INFINITI QX56 2008 Factory Service Manual WASHER SWITCHWW-27 < COMPONENT DIAGNOSIS > C DE F G H I J K M A B WW N O P 1. Turn the ignition switch OFF. 2. Disconnect combination switch. 3. Check continuity between the combination switch termina
