DISASSEMBLY
27. Push A/T assembly harness connector.CAUTION:
Do not damage connector.
28. Remove oil pan and oil pan gasket. Refer to TM-199, "
Oil Pan".
29. Check foreign materials in oil pan to help determine causes of malfunction. If the A/T fluid is very dark, smells burned, or con-
tains foreign particles, the frictional material (clutches, band)
may need replacement. A tacky film that will not wipe clean indi-
cates varnish build up. Varnish can cause valves, servo, and
clutches to stick and can inhibit pump pressure.
• If frictional material is de tected, perform A/T fluid cooler
cleaning. Refer to TM-182, "
A/T Fluid Cooler Cleaning".
30. Remove magnets from oil pan.
31. Disconnect A/T fluid temperature sensor 2 connector (A). CAUTION:
Do not damage connector.
32. Straighten terminal clip to free terminal cord assembly and A/ T fluid temperature sensor 2 harness.
SCIA5022E
SCIA5199E
SCIA5200E
SCIA8124E
Revision: March 2010 2008 QX56
Page 3786 of 4083
DISASSEMBLYTM-239
< DISASSEMBLY AND ASSEMBLY >
CEF
G H
I
J
K L
M A
B
TM
N
O P
33. Disconnect output speed sensor connector (1). CAUTION:
Do not damage connector.
34. Straighten terminal clip ( ) to free output speed sensor har- ness.
35. Remove bolts (A), (B) and (C) from control valve with TCM. • : Front
36. Remove control valve with TCM from transmission case. CAUTION:
When removing, be careful with the manual valve notch and
manual plate height. Remove it vertically.
37. Remove A/T fluid temperature sensor 2 with bracket from con- trol valve with TCM.
JSDIA1319ZZ
JSDIA1320ZZ
Bolt symbol Length mm (in) Number of bolts
A 42 (1.65) 5
B 55 (2.17) 6
C 40 (1.57) 1
SCIA8077E
SCIA5260E
SCIA5301E
Revision: March 2010 2008 QX56
Page 3787 of 4083
TM-240
< DISASSEMBLY AND ASSEMBLY >
DISASSEMBLY
38. Remove bracket from A/T fluid temperature sensor 2.
39. Remove O-ring from A/T assembly harness connector.
40. Disconnect TCM connectors.CAUTION:
Do not damage connectors.
41. Remove A/T assembly harness connector from control valve with TCM using suitable tool.
42. Disconnect TCM connector (1) and transmission range position switch connector (2).
CAUTION:
Do not damage connectors.
SCIA5264E
SCIA5155E
SCIA5447E
SCIA5448E
JSDIA1317ZZ
Revision: March 2010 2008 QX56
Page 3788 of 4083
DISASSEMBLYTM-241
< DISASSEMBLY AND ASSEMBLY >
CEF
G H
I
J
K L
M A
B
TM
N
O P
43. Remove rear extension assembly (2WD models) or adapter case assembly (4WD models) according to the following procedures.
a. 2WD models
i. Remove bolts and brackets (1) From rear extension assembly and transmission case.
• Self-sealing bolts (2)
ii. Tap rear extension assembly with soft hammer.
iii. Remove rear extension assembly (with needle bearing) from transmission case.
WCIA0562E
SCIA5028E
SCIA5029E
Revision: March 2010 2008 QX56
Page 3789 of 4083
TM-242
< DISASSEMBLY AND ASSEMBLY >
DISASSEMBLY
b.4WD models
i. Remove adapter case to transmission case bolts and terminal brackets (1).
• Self-sealing bolt (2)
ii. Tap adapter case assembly using suitable tool.
iii. Remove adapter case assembly (with needle bearing) from transmission case.
iv. Remove gasket from transmission case.
WCIA0563E
SCIA5201E
SCIA5186E
SCIA5231E
Revision: March 2010 2008 QX56
Page 3790 of 4083
DISASSEMBLYTM-243
< DISASSEMBLY AND ASSEMBLY >
CEF
G H
I
J
K L
M A
B
TM
N
O P
44. Remove bearing race from output shaft.
45. Remove output shaft from transmission case by rotating left and right.
46. Remove parking gear from output shaft.
47. Remove seal rings from output shaft.
48. Remove needle bearing from transmission case.
SCIA5245E
SCIA5030E
SCIA5247E
SCIA5209E
SCIA5031E
Revision: March 2010 2008 QX56
Page 3791 of 4083

TM-244
< DISASSEMBLY AND ASSEMBLY >
DISASSEMBLY
49. Remove output speed sensor (1) from transmission case.
CAUTION:
• Do not subject it to impact by dropping or hitting it.
• Do not disassemble.
• Do not allow metal filings or any foreign material to get on
the sensor's front edge magnetic area.
• Do not place in an area affected by magnetism.
50. Remove reverse brake snap ring using two flat-bladed screw- drivers.
NOTE:
Press out snap ring from the transmission case oil pan side gap
using a flat-bladed screwdriver, and remove it using a another
screwdriver.
51. Remove reverse brake retaining plate from transmission case. • Check facing for burns, cracks or damage. If necessary,
replace the plate.
52. Remove N-spring from transmission case.
53. Remove reverse brake drive plates, driven plates and dish plate from transmission case.
•Check facing for burns, cracks or damage. If necessary,
replace the plate.
54. Remove snap ring using suitable tool.
JSDIA1321ZZ
SCIA5032E
SCIA5214E
SCIA2322E
SCIA2323E
Revision: March 2010 2008 QX56
Page 3792 of 4083
DISASSEMBLYTM-245
< DISASSEMBLY AND ASSEMBLY >
CEF
G H
I
J
K L
M A
B
TM
N
O P
55. Remove spring retainer and return spring from transmission case.
