Page 3793 of 4083

INFINITI QX56 2008 Factory Service Manual TM-246 < DISASSEMBLY AND ASSEMBLY > DISASSEMBLY 59. Remove D-rings from reverse brake piston. 60. Knock out retaining pin using suitable tool. 61. Remove manual shaft retaining pin using suitable tool

Page 3794 of 4083

INFINITI QX56 2008 Factory Service Manual DISASSEMBLYTM-247 < DISASSEMBLY AND ASSEMBLY > CEF G H I J K L M A B TM N O P 64. Remove manual shaft from transmission case. 65. Remove manual shaft oil seals using suitable tool. CAUTION: Do not scr

Page 3795 of 4083

INFINITI QX56 2008 Factory Service Manual TM-248 < DISASSEMBLY AND ASSEMBLY > DISASSEMBLY 69. Remove return spring from servo assembly. 70. Remove O-rings from servo assembly. 71. Remove needle bearing (1) from rear extension (2WD models)or a

Page 3796 of 4083

INFINITI QX56 2008 Factory Service Manual DISASSEMBLYTM-249 < DISASSEMBLY AND ASSEMBLY > CEF G H I J K L M A B TM N O P 74. Remove return spring (1) from parking pawl (2). 75. Remove rear oil seal from rear extension (2WD models) or adapter c

Page 3797 of 4083

INFINITI QX56 2008 Factory Service Manual TM-250 < DISASSEMBLY AND ASSEMBLY > REPAIR FOR COMPONENT PARTS REPAIR FOR COMPONENT PARTS Oil PumpINFOID:0000000004917896 COMPONENTS DISASSEMBLY 1. Remove oil pump housing from oil pump cover. 2. Remo

Page 3798 of 4083

INFINITI QX56 2008 Factory Service Manual REPAIR FOR COMPONENT PARTSTM-251 < DISASSEMBLY AND ASSEMBLY > CEF G H I J K L M A B TM N O P 3. Remove O-ring from oil pump housing. 4. Remove O-ring from oil pump cover. ASSEMBLY 1. Install new O-rin

Page 3799 of 4083

INFINITI QX56 2008 Factory Service Manual TM-252 < DISASSEMBLY AND ASSEMBLY > REPAIR FOR COMPONENT PARTS 3. Install new oil pump housing oil seal to the oil pump housinguntil it is flush with the face of oil pump housing using Tool. CAUTION:

Page 3800 of 4083

INFINITI QX56 2008 Factory Service Manual REPAIR FOR COMPONENT PARTSTM-253 < DISASSEMBLY AND ASSEMBLY > CEF G H I J K L M A B TM N O P 1. Remove snap ring from front sun gear using suitable tool. 2. Remove 3rd one-way clutch from front sun ge
