Page 3185 of 4083

INFINITI QX56 2008 Factory Service Manual THIRD SEATSE-63 < ON-VEHICLE REPAIR > C DE F G H I K L M A B SE N O P 7. Remove the seat hinge rear bolt (A) and seat belt buckle bolt (B) from the seat assembly. CAUTION: Discard the seat belt buckl

Page 3186 of 4083

INFINITI QX56 2008 Factory Service Manual SE-64 < ON-VEHICLE REPAIR > THIRD SEAT 5. Remove the screws (2) from the power seat motor cover assem-bly. 6. Disconnect the wiring harness from the power seat motor cover clips. 7. Remove the power s

Page 3187 of 4083

INFINITI QX56 2008 Factory Service Manual THIRD SEATSE-65 < ON-VEHICLE REPAIR > C DE F G H I K L M A B SE N O P Installation 1. Install the cable into the drive motor and slide the conduit on the motor ferrule. 2. Install the cable into the R

Page 3188 of 4083

INFINITI QX56 2008 Factory Service Manual SE-66 < ON-VEHICLE REPAIR > THIRD SEAT 5. Snap the hinged strap retainer around the motor assembly. 6. Replace the power seat motor cover. 7. Install the seat harness to the power seat motor cover con

Page 3189 of 4083

INFINITI QX56 2008 Factory Service Manual THIRD SEATSE-67 < ON-VEHICLE REPAIR > C DE F G H I K L M A B SE N O P RH Side SeatINFOID:0000000001606225 REMOVAL 1. Remove the storage bin. Refer to INT-19, "Removal and Installation". 2. Remove the

Page 3190 of 4083

INFINITI QX56 2008 Factory Service Manual SE-68 < DISASSEMBLY AND ASSEMBLY > FRONT SEAT DISASSEMBLY AND ASSEMBLY FRONT SEAT Exploded ViewINFOID:0000000001606235 Driver Seat LIIA1578E Revision: March 20102008 QX56

Page 3191 of 4083

INFINITI QX56 2008 Factory Service Manual FRONT SEATSE-69 < DISASSEMBLY AND ASSEMBLY > C DE F G H I K L M A B SE N O P 1. Headrest 2. Headrest holder with multi-position lock 3. Seatback assembly 4. Lumbar switch bezel 5. Power seat switc

Page 3192 of 4083

INFINITI QX56 2008 Factory Service Manual SE-70 < DISASSEMBLY AND ASSEMBLY > FRONT SEAT Passenger Seat WIIA0476E 1. Headrest2. Headrest holder with multi-position lock 3. Seatback board 4. Armrest assembly 5. Lumbar switch bezel6. Fold fla
