REMOVAL
1. Move the A/T select lever to the N position and release the parking brake.
2. Put matching marks on the rear propeller shaft flange yoke and the rear final drive companion flange as shown.
CAUTION:
For matching marks, use paint. Never damage the rear pro-
peller shaft flange yoke or the companion flange.
3. Remove the bolts, then remove the propeller shaft from the rear final drive and A/T or transfer.
INSPECTION
• Inspect the propeller shaft runout. If runout exceeds the limit, replace the propeller shaft assembly.
AWDIA0031ZZ
1. Propeller shaft tube 2. Snap ring3. Journal bearing
4. Sleeve yoke 5. Journal6. Flange yoke
⇐ : Front
WDIA0049E
Limit
Propeller shaft run out : Refer to DLN-199, "
Gen-
eral Specification"
LDIA0121E
Revision: March 2010 2008 QX56
Page 1226 of 4083
![INFINITI QX56 2008 Factory Service Manual DLN-196
< REMOVAL AND INSTALLATION >[PROPELLER SHAFT: 2S1410]
PROPELLER SHAFT
• While holding the flange yoke on one side, check axial play of the joint as shown. If the journal axial play
exceeds t INFINITI QX56 2008 Factory Service Manual DLN-196
< REMOVAL AND INSTALLATION >[PROPELLER SHAFT: 2S1410]
PROPELLER SHAFT
• While holding the flange yoke on one side, check axial play of the joint as shown. If the journal axial play
exceeds t](/manual-img/42/57030/w960_57030-1225.png)
DLN-196
< REMOVAL AND INSTALLATION >[PROPELLER SHAFT: 2S1410]
PROPELLER SHAFT
• While holding the flange yoke on one side, check axial play of the joint as shown. If the journal axial play
exceeds the specification, repair or replace the journal parts.
• Check the propeller shaft tube for dents or cracks. If damage is detected, replace the propeller shaft assembly.
INSTALLATION
Installation is in the reverse order of removal.
• After installation, check for vibration by driving the vehicle. Refer to DLN-192, "
NVH Troubleshooting Chart".
• If propeller shaft assembly of final drive assembly has been replaced, connect them as follows:
- Face companion flange mark (A) of the final drive (1) upward. With
the mark (A) faced upward, couple the propeller shaft and the final
drive so that the matching mark (B) of the propeller shaft (2) can be
positioned as close as possible with the matching mark (C) of the
final drive companion flange.
- Tighten propeller shaft and final drive bolts and nuts of the to spec-
ification. Refer to DLN-194, "
Removal and Installation".
CAUTION:
Do not reuse the bolts and nuts. Always install new ones.
Standard
Propeller shaft journal axi-
al play
: Refer to
DLN-199, "
Gen-
eral Specification"
LDIA0117E
PDIA0892J
Revision: March 2010 2008 QX56
Page 1227 of 4083
![INFINITI QX56 2008 Factory Service Manual PROPELLER SHAFTDLN-197
< DISASSEMBLY AND ASSEMBLY > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
DISASSEMBLY AND ASSEMBLY
PROPELLER SHAFT
Disassembly and AssemblyINFOID:0000000001604436
INFINITI QX56 2008 Factory Service Manual PROPELLER SHAFTDLN-197
< DISASSEMBLY AND ASSEMBLY > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
DISASSEMBLY AND ASSEMBLY
PROPELLER SHAFT
Disassembly and AssemblyINFOID:0000000001604436](/manual-img/42/57030/w960_57030-1226.png)
PROPELLER SHAFTDLN-197
< DISASSEMBLY AND ASSEMBLY > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
DISASSEMBLY AND ASSEMBLY
PROPELLER SHAFT
Disassembly and AssemblyINFOID:0000000001604436
DISASSEMBLY
Journal
1. Put matching marks on the rear propeller shaft and flange yoke as shown.
CAUTION:
For matching marks use paint. Never damage the rear pro-
peller shaft or flange yoke.
2. Remove the snap rings.
3. Push out and remove the journal bearings by lightly tapping the flange yoke with a hammer, taking care not to damage the jour-
nal or flange yoke hole.
NOTE:
Put marks on the disassembled parts so that they can be rein-
stalled in their original positions from which they were removed.
4. Push out and remove the remaining journal bearings at the opposite side by lightly tapping the flange yoke with a hammer,
taking care not to damage the journal or flange yoke hole.
NOTE:
Put marks on the disassembled parts so that they can be rein-
stalled in their original positions from which they were removed.
ASSEMBLY
SPD128
APD011
SPD732
SPD131
Revision: March 2010 2008 QX56
Page 1228 of 4083
DLN-198
< DISASSEMBLY AND ASSEMBLY >[PROPELLER SHAFT: 2S1410]
PROPELLER SHAFT
Journal
1. Assemble the journal bearings
. Apply multipurpose grease on
the bearing inner surface.
NOTE:
During assembly, use caution so that the needle bearings do not
fall down.
2. Select new snap rings that will provide the specified play in an axial direction of the journal, and install them. Refer to DLN-200,
